- Page 1 PI01 Aluminum case for Raspberry Pi 3 Model B/B+ 2 Model B 1 Model B+...
-
Page 2: Special Features
INTRODUCTION o fulfill the needs of Raspberry Pi users, SilverStone created PI01, an aluminum case compatible with Raspberry Pi 3B+/3B/2B/1B+ version. It’s easy to install and includes two heatsinks and thermal pads to help conduct heat from CPU to aluminum casing. -
Page 3: Specifications
SPECIFICATIONS Model No. SST-PI01B Color Black Material Aluminum Support Raspberry Pi Version Raspberry Pi 3B+/3B/2B/1B+ version Net weight 55 g Dimension 90 mm (W) x 28 mm (H) x 62 mm (D) Heatsink Material Aluminum Net Weight and dimension Heatsink 1 : 9 mm (W) x 15.2 mm (H) x 9 mm (D), 2.6 g Heatsink 2 : 14 mm (W) x 15.2 mm (H) x 14 mm (D), 6.5 g... -
Page 4: Package Content
3. Case screw x 5 pieces 8. Blue thermal pad x 4 pieces 4. Screwdriver x 1 pcs 9. Foot pad x 4 pieces 5. Heatsink x 2 pieces INSTALLATION GUIDE Place Raspberry Pi PCB on bottom half of PI01 case... - Page 5 Secure with PCB screws Adhere corresponding thermal pads on top and bottom of heatsinks...
- Page 6 Place heatsinks on Raspberry Pi’s CPU and IC Place and align aluminum case cover over the bottom half and secure with screws...
- Page 7 Adhere foot pads to complete installation *Note: If using Raspberry Pi 3 B+, please use the blue thermal pad on CPU heatsink,...
-
Page 8: Warranty Terms And Conditions
WARRANTY ll SilverStone retail products have from the date of purchase, a minimum of 1 year limited warranty (select products listed below have 2, 3 or 5 year warranty) WARRANTY TERMS & CONDITIONS Product component defects or damages resulted from defective production is covered under warranty. - Page 9 Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand purchaser. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone http://www.silverstonetek.com.
- Page 10 All products should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology in USA by first downloading the “USA RMA form for end-users” form from the below link and follow its instructions.
- Page 11 ©2019 SilverStone Technology Co., Ltd. All Rights Reserved ALL trademarks are registered to their respective owners...
