- Page 1 CONVECTION SPEED OVEN OM24NDTDX1, OM24NMTDB1 & OM24NDTDB1 models INSTALLATION GUIDE US CA...
-
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Electric Shock Hazard To avoid hazard, follow these instructions carefully before installing or using this appliance. Failure to follow this advice may result in electric shock or death. Save these instructions for the local inspectors use. ●... - Page 3 SAFETY AND WARNINGS Grounding Instructions For all cord-connected appliances: This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
-
Page 4: Prior To Installation
PRIOR TO INSTALLATION INSTALLATION MILESTONES Ensure that: Milestone indicator The cavity ventilation has been set up correctly. Refer to page 7 for details. ● These milestones represent areas throughout The countertop and oven cavity are square and level, and are the required dimensions. ●... -
Page 5: Components Required
COMPONENTS REQUIRED PARTS TOOLS Not supplied Keep all packaging materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. -
Page 6: Product Dimensions
PRODUCT DIMENSIONS POWER OUTLET LOCATION OM24NDTDX1, OM24NMTDB1, OM24NDTDB1 models Product Dimensions inch a Overall height of oven B Overall width of oven 23 7/16 c Overall depth of oven (excludes handle and front metal trim) 22 1/4 d Depth of oven frame, control panel and door (excludes handle... -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS PROUD INSTALL 5/8–13/16” 16 -20mm PROFILE PLAN STACKED INSTALLATION ILLUSTRATED STACKED INSTALLATION ILLUSTRATED FLUSH INSTALL 5/8–13/16” OM24 16 -20mm CABINETRY DIMENSIONS A Minimum inside height of cavity 17 5/16 B Minimum inside width of cavity 22 1/16 C Minimum inside depth of cavity 21 5/8 D Overall height of cabinetry (cavity around front frame) 18 1/8... - Page 8 SERVICES This oven is not shipped with a power cord. VOLTAGE (V) AMPS (A) This oven must be connected to the mains power supply only by a suitably qualified person. 208/240 This oven must be earthed. Before connecting the oven to the mains power supply, check that: the domestic wiring system is suitable for the power drawn by the oven (as specified on the rating plate) the voltage corresponds to the value given on the rating plate.
- Page 9 CHECK CAVITY UNPACK PRODUCT Do not lift or move the product using the handle. Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you brought the product from to report the Measure cavity dimensions.
-
Page 10: Connect Power
REMOVE SHELVES CONNECT POWER Unclip and lift cover to access terminal Open the door and remove all packaging block. holding the oven shelves in place. Connect to terminal block as shown. Grip the shelves at the front. Lift Ensure oven is correctly Earthed and upwards and pull out from the cable clamp is tightened before closing microwave. - Page 11 CONNECT POWER FOUR WIRE CONNECTION Seperate the green and white oven cable Disconnect the power supply and wires. Connect the white oven cable wire remove the junction box cover. to the neutral (white) wire in junction box. Connect the green grounding oven cable wire to the (green) grounding Connect the oven cable to the junction box through the U.L - listed confuit...
- Page 12 POSITION OVEN INTO CAVITY ALIGN AND SECURE Some models only: For dark cabinetry, the supplied trim can Align oven with surrounding cabinetry be used to enhance clashing finish. and appliances. To install, remove the trim adhesive and press to secure to cavity. Using the product as a guide, pre-drill 2 x 3mm pilot holes.
- Page 13 REFIT SHELVES TEST OVEN Follow the guidance on screen to ensure Reposition shelves in the oven at the oven turns on and heats correctly. desired level. Refer to your User Guide for more information. Ensure shelves are level and correctly positioned with the guard rail at the back.
-
Page 14: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Open the oven door (lower) slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. - Page 15 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
