- Page 1 CONVECTION SPEED OVEN OM60NDTX1 & OM60NDLX1 models INSTALLATION GUIDE NZ AU UK IE...
-
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! WARNING! To avoid hazard, follow these instructions carefully before installing or using this appliance. Electric Shock Hazard Save these instructions for the local inspectors use. Failure to follow this advice may result in electric ●... - Page 3 SAFETY AND WARNINGS Grounding Instructions For all cord-connected appliances: This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
-
Page 4: Prior To Installation
PRIOR TO INSTALLATION INSTALLATION MILESTONES Ensure that: Milestone indicator The cavity ventilation has been set up correctly. Refer to page 6 for details. ● These milestones represent areas throughout The countertop and oven cavity are square and level, and are the required dimensions. ●... -
Page 5: Components Required
COMPONENTS REQUIRED PARTS TOOLS Not supplied Keep all packaging materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. -
Page 6: Product Dimensions
PRODUCT DIMENSIONS POWER OUTLET LOCATION OM60NDTX1, OM60NDLX1 Product Dimensions a Overall height of oven B Overall width of oven c Overall depth of oven (excludes handle and front metal trim) d Depth of oven frame, control panel and door (excludes handle... -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS The oven can be installed under a cooktop, in a column, or combined with the companion warmer drawer. ● The cabinet material must be able to withstand heat. ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... - Page 8 SERVICES This oven must be connected to the mains power supply only by a suitably qualified TYPE AND MINIMUM DIAMETER OF THE CABLES person. SASO This oven must be earthed. H05RR-F 3x1,5 mm H05RR-F 3x2,5 mm Before connecting the oven to the mains power supply, check that: H05VV-F 3x1,5 mm H05VV-F...
- Page 9 CHECK CAVITY UNPACK PRODUCT Do not lift or move the product using the door handle. Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you brought the product from to report the Measure cavity dimensions.
-
Page 10: Connect Power
REMOVE SHELVES CONNECT POWER Open the door and remove all packaging Unclip and lift cover to access terminal holding the oven shelves in place. block. Connect to terminal block as shown. Grip the shelves at the front. Lift Ensure oven is correctly Earthed and upwards and pull out from the cable clamp is tightened before closing microwave. - Page 11 POSITION OVEN INTO CAVITY ALIGN AND SECURE Some models only*: For dark cabinetry, the supplied trim can Align oven with surrounding cabinetry be used to enhance clashing finish. and appliances. To install, remove the trim adhesive and press to secure to cavity. Using the product as a guide, pre-drill 2 Lift product into cavity.
- Page 12 REFIT SHELVES TEST OVEN Follow the guidance on screen to ensure oven turns on and heats correctly. Reposition shelves in the oven at the desired level. Refer to your User Guide for more information. Ensure shelves are level and correctly positioned with the guard rail at the back.
-
Page 13: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Open the oven door (lower) slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. - Page 14 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
