- Page 1 Web Guiding Systems ekrPro Com60 with CLS Pro 600 Translation of the Original Quick Reference Guide Quick Reference Guide EDV no.: MD.337.01.04 ekrPro Com60 with CLS Pro 600 Issue Date: 30.06.2011...
- Page 2 The detailed operating manual for the devices specified above are a part of the delivery. They can also be found in internet under the following address: http://www.bst-international.com BST eltromat International Bielefeld GmbH Heidsieker Heide 53 33739 Bielefeld, Germany Telefon: +49 5206 999-0...
-
Page 3: Table Of Contents
Quick Reference Guide Contents Contents ..................2 System overview ............... 1 Commissioning ekrPro Com ..........1 Actuator EMS 17 – EMS 22 ........... 4 2.1.1 Select actuator ..............4 2.1.2 Setting the actuator guiding direction ......... 5 2.1.3 Select servo-center component .......... 5 2.1.4 Setting the actuator path limits ........... -
Page 4: System Overview
Quick Reference Guide 1 System overview Use this Quick Reference Guide if the system you use has the following configuration: controller ekrPro Com connector X101 connector X71 electromotor powered actuator Line and contrast sensor CLS Pro 600 hydraulic powered actuator 2 Commissioning ekrPro Com ekrPro Com60 firmware >... -
Page 5: Contents
Quick Reference Guide Afterwards proceed as follows: 1. Wire in and switch on the ekrPro Com60 controller as stipulated in the operating manual of the controller. 2. Configure the ekrPro Com controller. For it select the standard system for use with the CLS Pro 600 as follows. - Page 6 Quick Reference Guide Type section 2.1 EMS 17 section 2.1 EMS18 EMS 21 section 2.1 EMS 22 section 2.1 section 2.2 EMS 3 section 2.2 EMS 4 SV 1-6; SV 1-10/xx section 2.3 Quick Reference Guide EDV no.: MD.337.01.04 ekrPro Com60 with CLS Pro 600 Issue Date: 30.06.2011 Seite: 3/22...
-
Page 7: Actuator Ems 17 - Ems 22
Quick Reference Guide Actuator EMS 17 – EMS 22 These actuators all have something in common; they are fitted with an integrated position feedback. 2.1.1 Select actuator Pre-adjustments are already carried out with the selection of the standard system when using the EMS 17/18 actuator. In this case you can continue with point 2.1.2. -
Page 8: Setting The Actuator Guiding Direction
Quick Reference Guide 2.1.2 Setting the actuator guiding direction 1. Select the sub-directory Direction from the sub-menu Actuator. Confirm the selection by pressing ENTER. The actuator guiding direction for manual mode can be reversed by activating the checkbox Mot. Dir. Inverted. The direction can be checked on the spot. -
Page 9: Setting The Actuator Path Limits
Quick Reference Guide left right 6. Press the ESC button to exit the window. 2.1.4 Setting the actuator path limits 1. Switch to the sub-directory SC-Transducer and select the position Pos. Limit. Confirm the respective selectuion by pressing ENTER. 2. Use the vertical arrow keys to deactivate the checkbox active. -
Page 10: Actuators Ems 3 / 4
Quick Reference Guide Actuators EMS 3 / 4 The EMS 17/18 has been entered as an actuator when selecting the standard system. As this is not connected in your system, the actual actuator fitted must be entered and the necessary settings must be carried out. -
Page 11: Setting The Actuator Guiding Direction
Quick Reference Guide 2.2.2 Setting the actuator guiding direction 1. Switch to the sub-directory Direction. The actuator guiding direction for manual mode can be reversed by activating the checkbox Mot. Dir. Inverted. The direction can be checked on the spot. Move the actuator using the F2 or F3 key. -
Page 12: Select The Servo-Center Component
Quick Reference Guide 2.2.4 Select the servo-center component 1. Select the sub-directory SC-Transducer from the sub- menu Actuator and then the position Type & Dir.. Confirm the respective selection by pressing ENTER. 2. Use the horizontal arrow keys left and/or right in the not connected newly opened window to select the servo-center component selection window and confirm it by pressing... -
Page 13: Setting The Actuator Guiding Direction
Quick Reference Guide Select an actuator type 3. The default actuator will be displayed on the screen. EMS 17 4. Press the ENTER button. The actuator option list will then be opened. Now use the vertical arrow keys to select the actual actuator that is connected to the system. - Page 14 Quick Reference Guide If a hydraulic actuator is used, then additional hydraulic settings must be made in the menu Hydraulics Add On. 1. Switch to the sub-directory Hydraulics Add-on. Confirm the respective selection by pressing ENTER. 2. This will open an inputting window, in which the settings for the connected hydraulic actuator have to be made.
-
Page 15: Select The Servo-Center Component
Quick Reference Guide 2.3.3 Select the servo-center component 1. Select the sub-directory SC-Transducer from the sub- menu Actuator and then the position Type & Dir.. Confirm the respective selection by pressing ENTER. 2. Use the horizontal arrow keys left and/or right in the not connected newly opened window to select the servo-center component selection window and confirm it by pressing... -
Page 16: Setting Up The Cls Pro 600
Quick Reference Guide 3 Setting up the CLS Pro 600 General The display area in the graphic display of the keypad has differently coloured borders. The different colours show which mode you are in at present. There are the following possibilities: Operating mode AUTOMATIC Operating mode MANUAL (green) -
Page 17: Adjust Password Level
Quick Reference Guide Adjust password level The password level Operator is set after switching on the sensor. You have to be logged in as Administrator to carry out sensor set- up and the sensor must be in set-up mode (blue border strip). The procedure for selecting the password levels is described in the following, e.g. -
Page 18: Configuration
Quick Reference Guide 3.4 Configuration Open the Mounting-Position in the Configuration sub-menu and \\configuration\mounting position\ teach-in the sensor’s mounting position. The system must be in operating mode MAN. This procedure consists of 4 sub-steps. Use the teach-in model shown in the operating manual (annex 5) to carry out the teach-in process. - Page 19 Quick Reference Guide 3b) The window for the second step is now open. Position the teach-in model line in the green field and then press ENTER to confirm the process: teach-in model Material to be scanned Laser line The line identification process will now be run. 3c) Move the line some millimetres to the left by hand in step 3 afterwards.
-
Page 20: Material Setup
Quick Reference Guide 4 Material Setup The set-up of the CLS Pro 600 sensor is only possible in the operating mode MAN. Switching the controller to the operating mode MAN You can switch on the MAN mode at the controller keyboard or via the sensor keyboard. -
Page 21: Edge Set-Up Mode
Quick Reference Guide Edge set-up mode 1. Press key SET-UP EDGE to call up the set-up mode. The LEDs inside the SET-UP key will illuminate. The LED inside the ENTER key will flash. The sensor light will be switched on and it will flash. The laser line will be visible simultaneously. -
Page 22: Line Setup Mode
Quick Reference Guide Line setup mode 1. Press key SET-UP LINE to call up the set-up menu. The LEDs inside the SET-UP key will illuminate. The LED inside the ENTER key will flash. The sensor light will be switched on and it will flash. The laser line will be visible simultaneously. -
Page 23: Job Administration
Quick Reference Guide 5 Job administration It might be necessary to enter different measuring settings due to the variety of materials and print images processed in the different applications. With the sensor CLS Pro 600 you get the option to save a relevant measuring parameter set, consisting of material and/or job specific parameters, so-called Jobs. -
Page 24: Selecting A Job
Quick Reference Guide 5.1 Selecting a job 1. Call up the \\parameter\jobs\choose job\load job menu. The select list of the existing jobs appears on the display. 2. Use the up / down arrow keys to select the desired job and press ENTER for confirmation. -
Page 25: To Show The Current Job
Quick Reference Guide 5.4 To show the current job Whereby you will see the current job? Change over to the set-up mode or press the set-up line or set-up edge keys again in the set-up mode, then the currently loaded job will be displayed on the screen for 2 seconds.
