ReSound Smart Fit Manual

ReSound Smart Fit cable guide

Programming interface overview

ITEM NUMBER
1 20310800
2 21984000
3 21983900
4 19533900
5 19902500
6 19215000 Programming Kit, ENZO
ReSound OMNIA
TM
ReSound LiNX Quattro
ReSound ENZO Q
TM
NOTE: Strongly recommend to use fresh batteries for non-rechargeable models.

Cable connection for non-wireless programming

Custom models
With the battery door ajar, insert the flex strip
into the slot beside the hinge pin. The black dot
on the flex strip should be facing away from the
battery door. The flex strip is fully inserted when
the black dot abuts the hearing instrument case.
Close the battery door once the flex strip
is inserted.
RIE 61-DRW
Locate the programming slot below the push-
button. Open the battery door. With the black dot
on the flex strip facing the push button on the
hearing instrument, insert the flex strip into the slot
and close the battery door.
Mini BTE 67-DWT
Locate the programming slot below the
microphone port. With the black dot on
the flex strip facing the push button on the
hearing instrument, insert the flex strip
into the slot, until the black dot abuts the
hearing instrument case.
DESCRIPTION
1
Noahlink Wireless
CS44 – Red, Long
CS44 – Blue, Long
CS53 Flex Strip
PRG ADAPTER 2
Noahlink Wireless
CUSTOMS,
RIE, BTE
Customs, RIE,
TM
BTE
BTE
3
2 2
4
CS53 flex strip & CS44 socket cable
(R&L)
CIC
Customs, RIE 61-DRW, RIE 62-DRWT, BTE 77-DW,
BTE 67-DWT
-
RIE 62-DRWT,
BTE 77-DWT & BTE 88-DWHT
To connect the programming adaptor,
hold it at a 45° angle and insert the small
pins at the tip of the adaptor into the
square cut-out on the underside of the
hearing instrument. Once in place, move
the adaptor in the direction of the
battery compartment and then gently
click it into place.
BTE 98 -DWT
[1] Locate and push out the battery door pin using the pin
removal tool. [2] Pull out the battery door and [3] add the
ENZO programming adapter (19215000) and secure it with
the pin. [4] Insert a new size #675 battery and close the door.
[5] Connect CS44 socket cable.
1.
4.
3
6
5
Programming adapter & ENZO Programming adapter &
CS44 socket cable (R&L) CS44 socket cable (R&L)
-
BTE 88-DWT
BTE 88-DWHT
2. 3.
5.
2
-
-
BTE 98-DWT
