Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.

Table of Contents

General Safety Information . . . . . . . . . . . . . 2-3
General Information . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . 5-20
Electrical Connections . . . . . . . . . . . . . . . . .21
Unit Start-Up . . . . . . . . . . . . . . . . . . . . . .21
Vibration . . . . . . . . . . . . . . . . . . . . . . . .22
Parts List . . . . . . . . . . . . . . . . . . . . . . . .23
Routine Maintenance . . . . . . . . . . . . Backcover
Our Commitment. . . . . . . . . . . . . . . Backcover
®
DANGER
Always disconnect, lock and tag power source before
installing or servicing. Failure to disconnect power
source can result in fire, shock or serious injury.
CAUTION
When servicing the fan, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.
CAUTION
Precaution should be taken in explosive atmospheres.
DANGER
Pour écarter les risques d'incendie, de choc électrique
ou de blessure grave, veiller à toujours débrancher,
verrouiller et étiqueter la source de courant avant
l'installation ou l'entretien.
ATTENTION
Lors de toute intervention sur la soufflante, le moteur
peut être suffisamment chaud pour provoquer une
douleur voire une blessure. Laisser le moteur refroidir
avant toute maintenance.
ATTENTION
Faire preuve de précaution dans les atmosphères
explosives.
Document 486411
Model MOA
Modular Open Array
Modular Open Array
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Greenheck MOA

Summary of Contents for Greenheck MOA

  • Page 1: Table Of Contents

    Document 486411 Model MOA Modular Open Array ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage.

  • Page 2: General Safety Information

    General Safety Information Only qualified personnel should install this array. Personnel should have a clear understanding of these instructions and should be aware of general safety precautions. Improper installation can result in electric shock, possible injury due to coming in contact with moving parts, as well as other potential hazards. If more information is needed, contact a licensed professional engineer before moving forward.
  • Page 3 Inspection & Maintenance during Storage While in storage, inspect array once per month. Keep a record of inspection and maintenance performed. If moisture or dirt accumulations are found on parts, the source should be located and eliminated. At each inspection, rotate the wheel by hand ten to fifteen revolutions to distribute lubricant on motor. Machined parts coated with rust preventive should be restored to good condition promptly if signs of rust occur.

  • Page 4: General Information

    This instruction manual should be read in its entirety prior to installing the MOA or any of the related controls. Safety first, always follow safe work practices including proper PPE and electrical safety.

  • Page 5: Installation

    Installation Locate and identify parts as listed on the Parts List. See exploded views at the end of this manual for assistance in identifying parts. CAUTION When installing an array, ensure the proper protective devices are used to protect personnel from moving parts and other hazards.
  • Page 6 Step 3: Install first horizontal panel mount angle (K) to the floor of the opening. Push tab tight against the wall. Step 4: Install remaining horizontal panel mount angles (K) to the floor. a. Connect pieces together using the tabs. b.
  • Page 7 Step 6: Install end panel (E) to the left side of the array. a. Set into the horizontal panel mount angle (K) and tight to the vertical panel mount channel (I) and make plumb/level along the array plane. 416081 - 1/4 x 1/2 in. long screws b.
  • Page 8 Step 7: Set in place, fan panel (A) and loosely fasten to end panel (E), then secure bottom to horizontal panel mount angle (K). a. Set in place, spacer panel (F) and loosely fasten to fan panel (A), then secure bottom to horizontal panel mount angle (K).
  • Page 9 b. Complete the layer by repeating the spacer panel (F), fan panel (A), and finally, end panel (E), as in the image below. Secure each panel at the bottom to horizontal panel mount angle (K). NOTE If you do not use the middle layer channel section, skip to step 12. Modular Open Array ®...
  • Page 10 Step 8: Assemble end cap layer channel (N) to layer channel (L) and join sections together loosely with PN 416081 screws. Then set on top of panels. a. Connect with screws through the top of end panel (E), then fan panel (A), and spacer panel (F) and into layer channel (L).
  • Page 11 Step 9: Install the remaining layer channel (L) for this layer as dictated from step 6 to step 8. a. Finish bottom section with end cap layer channel (N) on the right side of array. Secure the end cap layer channel (N) to the wall from the back side.
  • Page 12 Step 10: When lower section is complete, set the upper left side vertical panel mount channel (I). You may want to temporarily put up the first end panel (E), along with the vertical panel mount channel (I) and mark the wall with a marker so you have the exact location to secure (I) before securing it to the wall.
  • Page 13 Step 11: After both vertical panel mount channels (I) are up and secure to the wall, install the first end panel (E) to the far left side of the array. a. Set end panel (E) into the layer channel (L) and tight to the vertical panel mount channel (I) and make plumb/level along the array plane.
  • Page 14 Step 12: Continue with fan panels (A) and (B) and spacer panels (F). a. As you go, install horizontal panel mount angles (K) to the ceiling using the same customer supplied hardware as the floor horizontal panel mount angles (K). Modular Open Array ®...
  • Page 15 Modular Open Array ®...
  • Page 16 Step 13: When all panels and screws are installed, go back around to all the screws and check that they are tight. Step 14: Fasten layer channel (L) to the top and bottom of opening through to the fan panels (A) and (F) and end panels (E) using the 1/4 x 1/2 inch screws PN 416081.
  • Page 17 Step 16: Install Fans into the designated locations in the array. Modular Open Array ®...
  • Page 18 a. Fasten all motors in place using supplied hardware, Part 415419 - BOLT, HSF, .313-18X.75, GR5, ZP b. Trim tubing to length and connect Sure-Aire tubes to the fans. c. Plug the motors into the power cable plug going to the junction box. Modular Open Array ®...
  • Page 19 d. Connect motors to each other using the ethernet cables working in a snake pattern from the bottom left, to the right. Step 17. Install power panel and control panel within X inches of each other and within X feet from the array. a.
  • Page 20 Modular Open Array ®...

  • Page 21: Electrical Connections

    Electrical Connections Before electrical connections are made, the supply voltage, phase and ampere capacity must be checked for compatibility with the fan motor. In addition, the supply wiring must be properly fused and conform to local and national electrical codes. If the unit is supplied with a safety disconnect switch, ensure proper wiring to the fan motor.

  • Page 22: Vibration

    • For rigidly mounted fans, recommended in-situ vibration velocities of less than .250 in./sec in accordance with AMCA 204 and BV-3 grades. Vibration Measurement on MOA Fan Array An appropriate method is measurement at the motor fastening diameter on the motor support plate in the direction of the motor axis of rotation and perpendicular to this.

  • Page 23: Parts List

    Layer channel connector End cap layer channel Horizontal reinforcement 415419 Bolt, HSF, .313-18X.75,GR5, ZP 416081 TRS,SHWH,.25-20X.5,ZP/WAX,TRI-LOBE Go to https://www.greenheck.com/ or call your local sales representative for questions or inquiries. To look up parts, go to https://www.greenheck.com/parts. Modular Open Array ®...

  • Page 24: Routine Maintenance

    As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
