Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
General Safety Information
Only qualified personnel should install this array.
Personnel should have a clear understanding of these
instructions and should be aware of general safety
precautions. Improper installation can result in electric
shock, possible injury due to coming in contact with
moving parts, as well as other potential hazards. If more
information is needed, contact a licensed professional
engineer before moving forward.
1. Follow all local electrical and safety codes, as well as
the National Electrical Code (NEC), the National Fire
Protection Agency (NFPA), where applicable. Follow
the Canadian Electric Code (CEC) in Canada.
2. The rotation of the wheel is critical. It must be free
to rotate without striking or rubbing any stationary
objects.
3. Motor must be securely and adequately grounded.
4. Do not spin the wheel faster than max cataloged
RPM. Adjustments to fan speed significantly effects
motor load. If the fan RPM is changed, the motor
current should be checked to make sure it is not
exceeding the motor nameplate amps.
5. Do not allow the power cable to kink or come in
contact with oil, grease, hot surfaces or chemicals.
Replace cord immediately if damaged.
6. Verify that the power source is compatible with the
equipment.
Model OPA
DANGER
Always disconnect, lock and tag power source before
installing or servicing. Failure to disconnect power
source can result in fire, shock or serious injury.
CAUTION
When servicing the fan, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.
CAUTION
Precaution should be taken in explosive atmospheres.
DANGER
Pour écarter les risques d'incendie, de choc électrique
ou de blessure grave, veiller à toujours débrancher,
verrouiller et étiqueter la source de courant avant
l'installation ou l'entretien.
ATTENTION
Lors de toute intervention sur la soufflante, le moteur
peut être suffisamment chaud pour provoquer une
douleur voire une blessure. Laisser le moteur refroidir
avant toute maintenance.
ATTENTION
Faire preuve de précaution dans les atmosphères
explosives.
Document 484885
Model OPA
Open Plenum Array
Open Plenum Array
1
Advertisement
Table of Contents
Related Manuals for Greenheck OPA
Summary of Contents for Greenheck OPA
- Page 1 Document 484885 Model OPA Open Plenum Array ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage.
- Page 2 Receiving cause condensation and “sweating” of metal parts). All accessories must be stored indoors in a clean, dry Upon receiving the product check to ensure all items atmosphere. are accounted for by referencing the delivery receipt or Remove any accumulations of dirt or debris and packing list.
-
Page 3: General Information
General Information To ensure a successful installation, the instructions in this manual should be read and adhered to. Failure to comply with proper installation procedures may void the warranty. Unit and System Identification Tags Each array has a permanently affixed manufacturer’s engraved metal nameplate containing the model number and individual serial number. -
Page 4: Installation
Installation 1. Carefully remove any crate and packing materials. 2. Array ships from factory fully assembled unless width exceeds 12 feet. If greater than 12 ft wide, multiple sections are to be assembled at the job site. Lift each section into place and secure to one another. Example of 3. -
Page 5: Radial Gap, Overlap And Wheel Alignment
Radial Gap, Overlap and Wheel Alignment Efficient array performance can be maintained by having the correct radial gap, overlap and wheel alignment. These items should be checked after the array has been in operation for 24 hours and before start-up after the unit has been serviced. -
Page 6: Unit Start-Up
Wheel Removal / Installation (Continued) To Remove: Backward Curved Aluminum Wheel (Mill Finish) 1. Remove all screws. Oil threads and points of set screws or Fastener Screws threads and under heads of cap screws. TaperLock Torque Unit Size Bushing 2. Insert screws into holes that are threaded on the bushing side lb-ft (shown as on image). -
Page 7: Routine Maintenance
Additional Steps for Initial Start-Up Airfoil Wheel Rotation 1. Check for proper wheel rotation by momentarily energizing the fan. Rotation is always determined by viewing the wheel from the drive side and should correspond to the rotation decal affixed to the unit. Note: One of the most frequently encountered problems with centrifugal fans is motors which are wired to run in the wrong direction. -
Page 8: Troubleshooting
As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
