Architectural Mailboxes MONTROSO MON00BPEC Assembly Instructions

CONTACT YOUR LOCAL POST OFFICE BEFORE INSTALLING THE MAILBOX TO ENSURE ITS CORRECT PLACEMENT AND HEIGHT AT THE
STREET. GENERALLY, MAILBOXES ARE INSTALLED AT A HEIGHT OF 41-45 INCHES FROM THE ROAD SURFACE TO INSIDE FLOOR OF THE
MAILBOX OR POINT OF MAIL ENTRY (LOCKED DESIGNS) AND ARE SET BACK 6-8 INCHES FROM THE FRONT FACE OF CURB OR ROAD
EDGE TO THE MAILBOX DOOR.
Video Instructions
(scan QR code with phone camera)
Parts/ Piezas
1
Turn the top post upside down and place on a flat
surface. Insert the bottom post into the top post by
lifting the post assembly up and pounding it on a
non-abrasive surface until the post assembly is
connected securely.
R
Parts (included)
Top Post
Bottom Post
x 8, Screw
x 2, Post Bracket x 2, L-Bracket
Mailbox Post | Model # MON00BPEC
Tools and Supplies (not included)
(8) Hex Nut
x 8, Hex Nut
recommended in
areas with loose soil.
2
Position the (2) post brackets and (2) L-brackets as
shown. Attach the (2) post brackets and the (2)
L-brackets to the post assembly using (4) screws and
(4) hex nuts.
ASSEMBLY INSTRUCTIONS
Level
Adjustable Wrench
Post Hole Digger
Phillips's Head Screwdriver
Use of concrete
Mailbox (not included)
MONTROSO™
