CAUTION:
1. CONDITIONS FOR USE
This micro abrasive blaster may only be operated:
• Indoors;
• Below 1981 m (6500 ft) above sea level altitude;
• Ambient air temperature between 40°-105°F (5-40°C);
• Maximum relative humidity of 80% at 31°C (88°F);
• Power supply current fluctuations does not exceed 10% of nominal value;
• Under level 2 contamination conditions;
• Supply cool, dry air only, at a maximum pressure of 10.3 Bar (150 PSI).
2. SAFETY
WARNING:
with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/
or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
BATTERY-operated (cordless) power tool.
1. Work area safety:
a.
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c.
Keep children and bystanders away while operating this power tool. Distractions can
cause you to lose control.
2. Electrical Safety:
a.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed
or grounded.
c.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com
ORIGINAL INSTRUCTIONS
Read the instructions before using this equipment
Read all safety warnings, instructions, illustrations and specifications provided
MASTER PROBLAST 3 ESD
MASTER PROBLAST3 ESD 08/23 Page 1

Advertisement

Table of Contents
loading

Summary of Contents for Vaniman MASTER PROBLAST 3 ESD

  • Page 1 Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD 08/23 Page 1...
  • Page 2: Personal Safety

    Store idle power tools out of the reach of children and do not allow persons unfamiliar 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 2...
  • Page 3 Maintain equipment and accessories. Check for breakage of parts and any other condition that may affect the equipment’s operation. 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 3...
  • Page 4: Liability Exclusion

    The product is repaired by anybody other than an authorized facility or if any parts other than Vaniman OEM parts are used. • The product continues to be employed, despite obvious safety faults. 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 4...
  • Page 5: Packing List

    (This “off” position should be used when filling the abrasive storage tanks.) 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 5...
  • Page 6: Maintenance

    -220V Abrasive-Vac Dust Collector P/N 10664 MAINTENANCE Vaniman blasters are designed to be low maintenance. However, as the materials used in a microblaster are abrasive by design, components do wear out. A few minor areas should be maintained regularly for a long product life.
  • Page 7: Glass Window

    Replace when necessary. Moisture: Vaniman blaster regulators include a filter for small amounts of oil and moisture. If moisture causes the media to clump or cake in the tanks, improper media flow will result. Be sure the air supply is relatively oil and moisture free.
  • Page 8: Replacement Parts

    Not Shown Cuff (black cloth) 2033XL Not Shown Blow Off Gun 2285 Not Shown Window Protector Shield 97951 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 8...
  • Page 9 MASTER PROBLAST 3 ESD PLUMBING Air Supply In Regulator Power Supply Foot Pedal 25799 Jefferson Ave.  Murrieta, CA 92562  1-800-VANIMAN (826-4626) USA  www.vaniman.com  sales@vaniman.com MASTER PROBLAST3 ESD - 08/23 Page 9...
  • Page 10 MASTER PROBLAST 3 ESD PROPER GROUNDING PROCEDURE When setting up your Vaniman ESD Blaster, it is important to correctly ground your system to provide the best posibible protection against ESD damage to the parts you are blasting. To properly ground your system, complete the following steps: 1.
