CONTENTS General Safety Technical schedule Specification Installation Controls and Connections Remote Control Initial Setup VIDAA TV - Home Screen Setting Picture Setting Sound Setting Network Setting Channel Setting Accessibility Setting System Setting Support Setting Multi-Screen USB Device FAQs WEEE...
GENERAL SAFETY INSTRUCTIONS Read this instruction manual carefully as it contains important information on the safety, use and maintenance of the appliance. Keep the manual for future reference. 1. Disconnect the plug from the wall socket in case of a long period of disuse. Disconnect the plug and antenna cable even in severe thunderstorms.
Page 5
GENERAL SAFETY INSTRUCTIONS (Cont.) WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. IT DOES NOT CONTAIN USEFUL PARTS FOR THE USER. FOR ASSISTANCE REFER TO QUALIFIED STAFF. The cover (or back) of the unit should not be removed to prevent risk of electric shock. This unit must be serviced by a qualified service personnel only.
Page 6
GENERAL SAFETY INSTRUCTIONS (Cont.) IMPORTANT INFORMATION Use furniture or stands recommended by the manufacturer. The product must be installed on a surface that correctly supports its weight. Make sure that the product rests completely on the surface on which it is installed. Do not place the product on a tall cabinet without fixing neither the cabinet nor the product stably.
Page 7
GENERAL SAFETY INSTRUCTIONS (Cont.) Installation Please follow instruction when installing this product in accordance with the instruction manual. This product must be placed on a sufficiently stable surface; incorrect installation is potentially dangerous as the TV could fall and cause injury. Be extremely careful around children.
Page 8
GENERAL SAFETY INSTRUCTIONS (Cont.) Batteries should not be exposed to direct sunlight or heat. To clean the TV, do not use chemicals, detergents, or wet cloths, be sure to use a dry cloth to clean it of marks or dust and only after unplugging the product from the power outlet.
Page 9
GENERAL SAFETY INSTRUCTIONS (Cont.) Do not place small metal objects on top of the unit; if such objects penetrate the TV casing, this could cause short circuits, fire or electric shock. Do not use or store flammable or combustible materials near the unit. This could cause fire or explosion.
Page 10
GENERAL SAFETY INSTRUCTIONS (Cont.) Have repairs carried out by qualified service personnel only. Maintenance is required if the appliance has been damaged in any way, such as damage to the power cord or plug, if liquid has been spilled or objects have fallen into the appliance, appliance has been exposed to rain or moisture, if it does not operate normally or has been dropped.
Page 11
TV cabinet. Dear Customer Herewith the manufacturer AYONZ CENTRAL LTD declares that this device complies with the 2014/53 / EU Directives. The full text of the EU declaration of conformity is available at the following internet address: www.eko-entertainment.it...
TECHNICAL SCHEDULE Information Value and precision Unit Supplier’s name or trade mark K32HV Supplier’s model identifier Energy efficiency class for standard Dynamic Range (SDR) On mode power demand for Standard Dynamic Range (SDR) Energy efficiency class (HDR) On mode power demand in High Dynamic Range (HDR) mode Off mode, power demand ≤0.5...
SPECIFICATIONS Display Device 32” HD Smart TV Resolution 1366 x 768 Display Colours 16.7 Million Contrast ratio: 3500 : 1 Aspect Ratio 16 : 9 WIFI Working Frequency 2.4GHz 802.11 b - 16.5±2 dBm at 11Mbps Maximum Transmission 802.11 g - 14±2 dBm at 54Mbps Power of WIFI 802.11 n - 13±2dBm at MCS7 Software of Version...
INSTALLATION Install the stand as described below, or if you want to mount it to a wall, please contact a professional installer. Please ensure the TV is not plugged into the wall socket and furthermore we recommend to get another person to assist in the following task. Attaching the stand Step 1 Place a soft cushioned material on top...
Page 15
INSTALLATION (Cont.) Wall-Mounting Instructions Please ensure the TV is not plugged into the wall socket and furthermore we recommend to get another person to assist in the following task. • We recommend you use a professional installer as we assume no liability for any eventual damage to the product or injury to yourself if you mount the TV on your own.
CONTROLS AND CONNECTIONS 1. REMOTE CONTROL SENSOR / POWER INDICATOR: In standby mode the indicator light will display red color; when switching on the unit the indicator light will no light. 2. STANDBY BUTTON: TO TURN ON/OFF THE TV.
Page 17
CONTROLS AND CONNECTIONS POWER INPUT ETHERNET INPUT (RJ45) RF1 (S2) RF2 (T2) AV IN OPTICAL USB 1 & 2 HDMI 3 HDMI 2 HDMI 1 / ARC EARPHONE...
REMOTE CONTROL 1. STANDBY(POWER): Set the unit in standby mode; press it again to switch it on. 2. INPUT: Select the input source. 3. Number buttons (0-9): Select a TV channel. 4. GUIDE: Launch the Program Guide. 5. CH.LIST: Channel list. : Corresponds to various colour functions in the menu or teletext.
Page 19
REMOTE CONTROL (CONT.) 18. INFO: Display the avaiable program information. : Set up APP shortcut key. 20. FREE: Enter to the free video. 21. DEEZER: Enter to the deezer directly. 22. APPs: Open application. Universal Remote Control Code: 00BF...
Page 20
REMOTE CONTROL (CONT.) REMOTE CONTROL BATTERY INSTALLATION AND WARNINGS • Open the battery compartment cover on the back of the remote control • Insert 2 x 1.5V type AAA batteries placing them according to the correct polarity. • Open the battery compartment cover on the back of the remote control •...
INITIAL SETUP For the first initial setup, on screen setup wizard will guide you through setting up your TV. Please follow according to onscreen guide to setup your TV correctly. buttons to select system language, then press OK/SELECT to confirm. Use the...
Page 22
INITIAL SETUP (CONT.) buttons to select location, then press OK/SELECT to confirm. Use the Use the buttons to select channel scan, or skip to continue TV setup.
Page 23
INITIAL SETUP (CONT.) If select Auto Channel Scan, Create PIN will display as below, input 4 digits as password. (Note: 0000 would be invalid.) Press OK button to enter Channel Scan Setup.
Page 24
INITIAL SETUP (CONT.) Press to select your Wi-Fi you wish to connect to, enter the password and then confirm to connect. Press Up/Down button to highlight Select All, and press OK button to confirm the selection; then the cursor automatically jumps to OK & Go Next, and press OK to the next step.
Page 25
INITIAL SETUP (CONT.) Create your VIDDA account: Create an account or skip to the next step. Press Up/Down button to select a unique name for your TV, to help identify it when casting or connecting to it from other devices; Press OK button to confirm.
VIDAA TV - HOME SCREEN Once you have completed initial setup, you will now enter the VIDAA TV home screen. Press on remote control to enter Home Page. Manage apps: Select the item you want to move, and long press OK button to move or uninstall app.
SETTING - PICTURE To access SETTINGS menu, select SETTINGS (#5 on page 26) via the HOME screen. To access Picture menu, select Setting (#5 on page 26) menu and go down and select Picture. Picture Settings information on next page...
Page 28
SETTING - PICTURE Picture Mode You can select the Picture Mode that provides the best viewing experience. • Standard: The default mode, to make users experience high-quality images under normal light. • Cinema Day: Enhance the contrast, color and clarity of the screen to make the color more vivid.
SETTING - SOUND To access SOUND menu, select Setting (#5 on page 26) menu and go down and select SOUND. SOUND Settings information on next page...
Page 30
SETTING - SOUND You can select a favorite sound mode suitable for the content type or the listening environment. • Standard: Produced a balanced sound in all environment. • Theater: Increased the surround sound effect and provides a more prominent bass response. •...
SETTING - NETWORK To access NETWORK menu, select Setting (#5 on page 26) menu and go down and select NETWORK. NETWORK Settings information on next page...
Page 32
SETTING - NETWORK Network Configuration You set the TV network by selecting Configuration and press the button to enter the submenu. Automatically obtain an IP address 1. If you connect to the wired network, the TV will automatically obtain an IP address and connect to the network.
SETTING - CHANNEL To access CHANNEL menu, select Setting (#5 on page 26) menu and go down and select CHANNEL. CHANNEL Settings information on next page...
Page 34
SETTING - CHANNEL Auto Scan Press button into the submenu, select Change Setup and press button to select Satellite, Antenna or Cable. Channel List • In Live TV, press to display the channel list. Favorite • Adding channels to your ‘Favorites’ list •...
Page 35
SETTING - CHANNEL TV Guide • In Live TV, display the TV Guide. • Press GUIDE button on remote control, or press > Guide, to call out the Guide • Press Up/Down navigation button to select preferred channel. • Press Left/Right navigation button to select preferred programme of some channel. •...
SETTING - ACCESSIBILITY To access ACCESSIBILITY menu, select Setting (#5 on page 26) menu and go down and select ACCESSIBILITY. • High Contrast Menu: Turn High Contrast Menu On or Off. • Menu Transparency: Set the transparency of menu. (Optional: Off/Medium/High) •...
SETTING - SYSTEM To access SYSTEM menu, select Setting (#5 on page 26) menu and go down and select SYSTEM. SYSTEM Settings information on next page...
Page 38
SETTING - SYSTEM Time: Set the current time based on your location. • Time Format: Set the time to display in a 12 or 24-hour format. • Date/Time: Set the date and time. • Time Zone: Set the time zone. •...
Page 39
SETTING - SYSTEM HDMI & CEC You can use your TV remote to control the external devices that are connected to the TV by HDMI cable. The external devices need to support HDMI & CEC Function (HDMI-CEC). 1. Set HDMI Control to On. 2.
SETTING - SUPPORT To access SUPPORT menu, select Setting (#5 on page 26) menu and go down and select SUPPORT. SYSTEM Settings information on next page...
Page 41
SETTING - SUPPORT System Info View System information. Self Diagnosis Perform self diagnosis to test sound, picture and connections. E-Manual Launch the E-Manual and get to know more about your TV: First-Time Use, Enjoy Live TV, Benefits of Smart TV, Connecting to External Devices, Settings Overview, Entertainment, Accessibility Features, Troubleshooting.
MULTI-SCREEN Screen Sharing Mirror content from your device to the TV. Press enter Screen Sharing. 1. Turn on the casting function of your Android/Windows10 device. 2. Find the TV name in the searching list of your device and select it. Wait for the connection progress to complete and the content on your device will be displayed on the TV.
USB DEVICE Connect the USB devices such as hard drives, USB sticks and digital cameras for browsing photos, listening to music. Media Playing Media contents > Media By default, there are Content Sharing displayed on the Media screen. If your mobile device is connected to the TV, its name also appears on the Media screen.
FAQs GENERAL PROBLEMS WITH TV SET Symptoms Items to check and actions to follow This may be caused by obstruction to antenna due to high rise “ghost” or double image buildings or hills. Using a highly directional antenna may improve the picture.
