Toshiba Satellite A35-S209 Specifications

TOSHIBA
Satellite® A35 Series
Feature Model(s):
Satellite A35-S209
P4 2800/15.0"XGA/512MB/60GB/DVD-CDRW/Mdm/LAN/WiFi/WinXP Home

Product Highlights

Performance
•
Intel® Pentium® 4 processor at 2.80GHz
•
512MB expandable to 1024MB
•
60GB* hard disk drive
Great Features
•
15.0" TFT active matrix display
•
DVD-ROM/CDRW multi-function drive
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Integrated 802.11g Wireless LAN module

System Characteristics

CPU (See CPU Performance Disclaimer)**
•
Intel® Pentium® 4 processor at 2.80GHz**
•
Integrated co-processor
L2 Cache
•
512KB Level 2 Cache integrated on die
•
533MHz Processor System Bus Clock Speed (PSB)
Memory
•
512MB (2 DIMM) expandable to 2048MB; SODIMM expansion
memory
•
128/256/512/1024MB PC2100 DDR SDRAM, 2.5V
•
Data/Address Bus Width; 64-bit/32-bit
•
Intel 852GME + ICH4-M Chipset
Mass Storage
•
Primary Hard Disk Drive: 60GB* hard disk drive; Enhanced IDE
(ATA-5); 4200rpm drive rotation; 9.5mm height, 0.2lbs, service
removable
•
DVD-ROM/CDRW multi-function drive: ATAPI Interface;
Maximum Speed: READ- CD-R(24x), CD-RW(12x), DVD-
ROM(8x), DVD-R(4x), DVD-RW(4x), DVD-RAM(1x), CD-
ROM(24x); WRITE- CD-R(24x), CD-RW(4x); Compatibility: CD-
ROM, CD-R(read/write), CD-RW(read/re-write), DVD-ROM, DVD-
R (read only), DVD-RW(read only), DVD-RAM(read only).
•
Software Decoder: InterVideo® (WinDVD™)
Graphics/Video
•
15.0"TFT active-matrix display****; Internal display supports up to
16M colors at 1024 x 768
•
32MB internal Integrated Intel® 852GM video memory
•
Direct 3D Support; OpenGL Support; DirectVideo and DirectMPEG
(supported by software only)
•
External Color Support/Refresh rate (Depending on CRT):
800 x 600; 60/70/72/75/85/100/120Hz
1024 x 768; 60/70/72/75/85/100/120Hz
1280 x 800: 60/70/72/75/85/100/120Hz
1280 x 1024; 60/70/72/75/85/100/120Hz
1440 x 900; 60/70/72/75/85/100Hz
1600 x 1200; 60/70/72/75/85/100Hz
1680 x 1050: 60/70/72/75/85/100Hz
1920 x 1200; 60Hz
1920 x 1440: 60Hz
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function; TouchPad pointing device
•
CD Control Functions: Play/Pause, Stop/Eject, Previous,
Skip/Next, Mode Control switch (CD/DVD/Digital Audio) – (Does
not function with the unit powered off)
•
Toshiba Console Button
•
Instant Access Internet Button
•
One touch TV-Out Button
Expandability
•
1 Memory slot (including main memory slot)
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS satellite_A35-S209.doc Created on 9/22/2003 9:23 AM
Part Number
PSA30U-035JXV
•
1 PC Card slot supports 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless LAN (IEEE 802.11b) module
Ports
•
ECP Parallel printer port
•
RGB Port (Monitor)
•
2 Universal Serial Bus ports (2.0)
•
TV-Out (S-Video)
•
RJ-45 LAN port
•
RJ-11 modem port

Physical Description

•
Dimensions (LxWxH): 13.0" x 11.0" x 1.7"
•
Weight: 7.72lbs
•
LED Indicators: Power, HDD, CD/DVD-ROM, DC-IN, Caps Lock,
Arrow, Numeric, Main Battery Charging Status, System Sleep /
Suspend status, Wireless Communication (left side)
Sound
•
Realtek ALC202 Codec Chip; Software Sound Chip
•
Built-in Stereo Speakers
•
16-bit stereo, Windows Sound System V2.0; SoundBlaster® Pro
compatible (in DOS box only)
•
Direct 3D Sound (supported by sound driver); DirectSound and
DirectMusic (supported by hardware acceleration); Full Duplex
and MIDI support; 3D Sound Support (HRTF 3D positional audio)
•
Sound Volume Control Dial
•
Ports: Microphone port, headphone port, Line-in port

Power Supply

•
AC Adapter: 120W external AC Adapter, 100-240V / 50-60Hz
frequency (Universal) input voltage, 19V x 6.3A Output.
Dimensions (LxWxH): 5.8" x 2.5" x 1.4
Weight: 1.37lbs
•
Battery Pack: 12-cell, rechargeable, removable Li-Ion battery,
14.8V x 6450mAh
Dimension (LxWxH): 5.2" x 4.9" x 0.8"
Weight: 1.38lbs
•
Up to 2.0H battery life
•
Recharge Time (Main Battery On/Off): 4.0Hrs / 4.0 – 12.0Hrs
•
Battery life may vary depending on applications, power
management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is
consuming full power. After a period of time, the battery will lose
its ability to perform at maximum capacity and will need to be
replaced. This is normal for all batteries. To purchase a new
battery pack or see information on accessories shipping with your
computer, visit the Toshiba website at
www.accessories.toshiba.com
Security
•
Slot for computer lock, HDD and memory (by screw only), Main
Battery Pack (sliding latch), Main Module Bay (by screw), Built-in
Modem (screw only), User Power-on password, Setup Security,
Keyboard lock (by Hotkey), Screen Blank (by Hotkey), Screen
Saver by software
Bios
•
ACPI, PnP, VESA, DPMS, DDC, SM BIOS, PCI BIOS support
Operating System
•
Microsoft® Windows XP Home (A35-S209) pre-installed
•
Windows 2000 component drivers on the web
Additional Software
•
Microsoft® Works
•
Toshiba Notebook Maximizer
•
Intuit® Quicken® New User Edition 2003
Rev. 1.1a
.
Page 1 of 3
