Toshiba Satellite A25-S279 Specifications

TOSHIBA
Satellite® A25 Series
Feature Model(s):
Satellite A25-S279
P4 2800/15.0"TFT/512MB/60GB/DVD-CDRW/Mdm/LAN/WiFi(802.11g)/WinXP Home
Satellite A25-S2791
P4 2800/15.0"TFT/512MB/60GB/DVD-CDRW/Mdm/LAN/WiFi(802.11g)/WinXP Pro

Product Highlights

Performance
•
Intel® Pentium® 4 processor 2.80GHz
•
512MB of Main Memory
•
60GB* hard disk drive
Great Features
•
15.0" XGA TFT screen
•
DVD-ROM/CDRW multi-function drive
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless (802.11g) LAN
System Characteristics
CPU (See CPU Performance Disclaimer)**
•
Intel® Pentium® 4 processor 2.80GHz**
•
Integrated co-processor
L2 Cache
•
512KB Level 2 Cache integrated on die
•
533MHz Processor System Bus Clock Speed
Memory
•
512MB (2 DIMM) DDR SDRAM (Expandable to 1024MB) (Both
slots may be occupied)
•
Expansion memory: 128MB/256MB/512MB PC2100 DDR,
SODIMM, 2.5V
•
Data/Address Bus Width; 64-bit/32-bit
•
Ali M1672 + M1535 Chipset
Mass Storage/Optical Drive
•
Primary Hard Disk Drive: 60GB* hard disk drive, Enhanced IDE
(ATA-5), 4200rpm, 9.7mm height, 0.2lbs, Service Removable
•
DVD-ROM/CDRW Multi-function drive: Max Speed: CD-R(24x),
CD-RW(10x), CD-ROM(24x), DVD-ROM(8x); Compatibility: CD-
ROM, CD-R(read/write), CD-RW(read/re-write), DVD-ROM, DVD-R
(read), DVD-RW(read); Service removable
•
Software Decoder: InterVideo® (WinDVD™)
Graphics/Video
•
15.0" XGA TFT**** active-matrix display; internal display supports up
to 16M colors at 1024 x 768
•
Trident CyberBlade XP2 graphics processor; 32MB shared video
memory
•
External Color Support/Refresh rate: Non-Interlaced@16M Colors
640 x 480 60/75/85/100Hz
800 x 600 60/75/85/100Hz
1024 x 768 60/75/85/100Hz
1280 x 1024 60/75/85/100Hz
1600x 1200 60/75/85/100Hz
1920 x 1440 60/75Hz
2048 x 1536 60Hz
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function; TouchPad pointing device
•
CD Control Function: Play/Pause, Stop, Previous, Next, Mode
Control Switch (CD/DVD)
Expandability
•
2 Memory slots (Both slots may be occupied)
•
PC Card slot supports 1 Type II (5mm)
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS satellite_A25-S279.doc
Ports
Physical Description
Sound
Power Supply
Battery life may vary depending on applications, power management settings
and features utilized. Recharge time varies depending on usage. Battery
may not charge while computer is consuming full power. After a period of
time, the battery will lose its ability to perform at maximum capacity and will
need to be replaced. This is normal for all batteries. To purchase a new
battery pack or see information on accessories shipping with your computer,
visit the Toshiba website at
Security
Bios
Operating System
Additional Software
AOL OFFER DETAILS: Availability may be limited, especially during peak
Created on 9/11/2003 5:08 PM
Part Numbers
PSA20U-0CH43V
PSA20U-0CH436
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless (802.11g) LAN (Atheros)
•
RGB (monitor) port
•
Parallel port
•
3 Universal Serial Bus ports (2.0)
•
TV-Out (S-Video)
•
RJ-45 LAN port
•
RJ-11 modem port
•
Secure Digital® (SD) slot
•
Dimensions (LxWxH): 13.4" x 11.6" x 1.9"
•
Weight: 7.9lbs
•
LED Indicators: HDD, CD/DVD, DC-IN, Caps Lock, Arrow, Numeric,
Main Battery Charging Status, System Sleep / Suspend status,
Wireless Communication switch (left side), SD Card (right side)
•
Analog Devices AD1981B Codec Chip, Software sound; 16-bit
stereo; Stereo Speakers
•
Direct 3D Sound (supported by sound driver); DirectSound and
DirectMusic (supported by sound driver); Full Duplex and MIDI (play
back) support, 32 voices
•
Sound Volume (by dial)
•
Ports: External Microphone port, headphone port, Line-in port
•
AC Adapter: 120W AC Adapter, 100-240V / 50-60Hz frequency
(Universal) input voltage, 15V x 8A Output.
Dimensions (LxWxH): 5.7" x 2.1" x 1.7"
Weight: 1.4lbs
•
Battery Pack: 12-cell, rechargeable, removable Lithium Ion
(Graphite) battery, 10.8V x 8400mAh
Dimension (LxWxH): 8.1" x 3.6" x 0.9"
Weight: 1.4lbs
•
Battery Saver (in Windows): Stand by, HDD Auto Off, Display Auto
Off, Hibernation
•
Battery life 2h41m***;
•
Recharge time(Off/On): Approx 3.5H/3.5~12.5H+
www.accessories.toshiba.com
•
Slot for Kensington Cable lock, HDD and memory (by screw only),
User Power-on password, Setup Security (by help of password
utility), HDD Password (by TSETUP), Screen Blank (by Hotkey),
Keyboard lock (by Hotkey), Screen Saver by software
•
TSETUP, ACPI, PnP, VESA, DPMS, DDC, SM BIOS, PCI BIOS
support
•
Microsoft® Windows XP Home pre-installed (A25-S279)
•
Microsoft® Windows XP Pro pre-installed (A25-S2791)
•
Windows 2000 component drivers on the web
•
Microsoft® Works
•
Toshiba Notebook Maximizer
•
Intuit® Quicken® New User Edition 2003
•
Norton® AntiVirus™ 2003- w/3 Month Subscription
•
AOL® (3.-month offer)
Rev. 1.0 Page 1 of 3
