Toshiba Satellite A105-S2194 Specifications

Satellite A105-S2194 Detailed Product Specification
Model Name Description
A105-S2194 Genuine Windows® XP Media Center Edition 2005, Intel® Celeron® M Processor 430,
512MB DDR2, 80GB 5400rpm SATA, DVD-SuperMulit, 15.4" TruBrite™ (WXGA), ATI
RADEON® XPRESS 200M, Atheros® 802.11 b/g wireless-LAN, CD control buttons, 1
year limited Warranty
2
Operating System
• Genuine Windows® XP Media Center Edition 2005
• Windows Vista™ Capable
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
Processor and Chipset
• Intel® Celeron® M Processor 430
o 1.73GHz, 1MB L2, 533MHz FSB
• ATI Radeon® Xpress 200M Chipset
5
Memory
• Configured with 512MB DDR2 SDRAM (both memory slots may be
occupied)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB
PC4200 DDR2 533MHz SDRAM memory modules.
6
Hard Disk Drive
• 80GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, 8x), DVD-R (Double Layer, 2x), DVD-RW (4x),
DVD+R (Single Layer, 8x), DVD+R (Double Layer, 2.4x),
DVD+RW (4x), DVD-RAM (5x)
8
Display
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
9
Graphics
• ATI Radeon® Xpress 200M 64MB-128MB dynamically allocated
shared graphics memory
Sound
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
3
4
7
10
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A105-S2194 Rev. 1.0 2006-09-05 MCL T20060621 CB1.50
1
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• 10/100-TX Ethernet
• Integrated Wireless-LAN:
o Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o Universal Serial Bus (USB v2.0) – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
13
configuration
• Indicators: Power, DC-IN, HDD, CD/DVD, CapsLock, ArrowMode,
NumericMode, Battery, Sleep/Suspend, Wireless
• Chassis Description
o Case material: PC+ASB Plastic
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock; Yes
o Items protected by a screw: Memory, Main HDD, Built in
Modem/Lan
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Power Supply
• 65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.25" (108mm) x 1.85" (47mm) x 1.34"
(34.0mm)
• Weight: starting at .55 lbs (250 g)
14
Battery
• 6-cell (4000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.15" (207mm) x 0.91" (23mm) x 2.13"
(54mm)
• Weight: starting at 0.75 lbs (340 g)
• Battery Life (measured by MobileMark™)
Part Number UPC
PSAA5U-00Z01C 032017679269
11
12
15
Page 1 of 5
