Toshiba Satellite A105-S2071 Specification Sheet

Satellite A105-S2071 Detailed Product Specification
Model Name Description
A105-S2071 Microsoft® Windows® XP Home, Intel® Celeron® M Processor 390, 512MB DDR2,
80GB 5400rpm SATA, DVD-SuperMulti, 15.4" TrueBrite™ (WXGA), ATI RADEON®
XPRESS 200M, Atheros® 802.11 b/g wireless-LAN, CD control buttons, 1 year limited
Warranty
2
Operating System
• Microsoft® Windows® XP Home Edition
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
4
Processor and Chipset
• Intel® Celeron® M Processor 390
o 1.70GHz, 1MB L2, 400MHz FSB
• ATI RADEON® XPRESS 200M Chipset
5
Memory
• Configured with 512MB DDR2 SDRAM (both memory slots may be
occupied)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
1024MB or 2048MB PC4200 DDR2 533MHz SDRAM, dual-
channel support requires two memory modules of same capacity
and clockspeed
6
Hard Disk Drive
• 80GB (5400 RPM); Serial-ATA (SATA) hard disk drive; 9.5mm
height; user removable
7
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
8
Display
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
9
Graphics
• ATI RADEON® Xpress X200M 64MB-128MB dynamically allocated
shared graphics memory
Sound
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• Realtek 861 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
o HD Audio
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
3
10
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A105-S2071 Rev.1.10 2005-02-27 MCL T20060113 CB1.20
1
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
Communications
• Toshiba V.92 software modem
• 10/100 Base-TX Ethernet
• Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o Universal Serial Bus (USB v2.0) – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
13
configuration
• Indicators: DC-IN, HDD, CD/DVD-ROM, CapsLock, Arrow Mode,
Numeric Mode, Battery, System Sleep, Wireless
• Chassis Description
o Case material: PC-ABS Plastic
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock; Yes
o Items protected by a screw: Memory, HDD, LAN
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank, Key Board Lock, Screen
Saver
Power Supply
• 65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.25" (108mm) x 1.85" (47mm) x 1.34"
(34.0mm)
• Weight: starting at .55lbs (250 g)
Part Number UPC
PSAA2U-04U019 032017540378
11
12
Page 1 of 5
