Toshiba Satellite A100-ST3211 Specifications

Satellite A100-ST3211 Detailed Product Specification
Model Name Description
A100-ST3211 Genuine Windows® XP Professional, Intel Pentium® M Processor 740, 256MB
DDR2 SDRAM, 40GB (5400 RPM) Serial-ATA (SATA), CD-RW/DVD-ROM, 15.4"
widescreen WXGA, Intel® Graphics Media Accelerator 900, Intel® PRO/Wireless
2200BG, CD control buttons, 5-in-1 Bridge Media Adapter, ExpressCard™, 1-year
Limited Warranty
2
Operating System
• Genuine Windows® XP Professional
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
3
Processor and Chipset
Intel® Centrino® Mobile Technology featuring:
• Intel Pentium® M Processor 740
o 1.73GHz, 2MB L2, 533MHz FSB
• Mobile Intel 915GM Express Chipset
• Intel PRO/Wireless 2200BG (802.11b/g),
4
Memory
• Configured with 256MB DDR2 SDRAM
• 256MB(min)/2048MB (max) PC4200 DDR2 533MHz SDRAM, dual-
channel support requires two memory modules of same capacity
and clockspeed
5
Hard Disk Drive
• 40GB (5400 RPM); Serial-ATA (SATA) hard disk drive; 9.5mm
height; user removable
6
Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read)
7
Display
• 15.4" diagonal widescreen TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
8
Graphics
• Intel Graphics Media Accelerator 900 with 8MB-128MB dynamically
allocated shared graphics memory
Sound
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• Realtek 861 16-bit stereo software sound
o
Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Intel HD Audio
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
9
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A100-ST3211 BTS Rev. 1.02 2006-07-31 SK T20051031 CB 1.00
1
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• Marvell 10/100 Base-TX Ethernet
• Integrated Intel Pro/Wireless Network Connection 2200BG
11
(802.11b/g)
Expandability
• 2 main memory slots.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus™
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o Universal Serial Bus (USB v2.0) – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
12
configuration
• Indicators: Power, DC-IN, HDD, CD/DVD-ROM, CapsLock,
ArrowMode, NumericMode, Main Batt Charge, System Sleep,
Wireless, SD Card
• Chassis Description
o LCD Cover Color: Peacock Blue
• Physical Security
o Slot for cable lock; Yes
o Items protected by a screw: Memory, HDD, Built-in
Modem/LAN
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Part Number UPC
PSAA0U-02300R 032017526105
10
