Summary of Contents for Electrolux Professional HOBT11
- Page 1 Built-in Hood for Electric and Gas Oven 922733 HOBT11 Level 1 922734 HOBT21 Level 1 922735 HOBV11 Level 1 922736 HOBS21 Level 1 922737 HOBS11 Level 1 Installation manual* Original Instructions 231007 IM_HO_01_ELUX_EN.docx -...
- Page 2 922733 HOBT11 Hoods Installation Diagram 922734 HOBT21 922735 HOBV11 922736 HOBS21 922737 HOBS11 231007 IM_HO_01_ELUX_EN.docx -...
- Page 3 Foreword The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the machine (or “appliance“). The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to improper operating procedures.
-
Page 4: Table Of Contents
Contents WARNINGS AND SAFETY INFORMATION............................5 General information ................................... 5 Personal Protective Equipment ................................. 6 General safety ....................................6 Transport, handling and storage ................................ 7 Installation and assembly .................................. 7 Positioning ......................................7 Machine scrapping .................................... 7 APPLIANCE AND MANUFACTURER’S IDENTIFICATION DATA ......................8 Data plate position .................................... -
Page 5: Awarnings And Safety Information
A WARNINGS AND SAFETY INFORMATION General information To ensure safe use of the machine and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 6: Personal Protective Equipment
Personal Protective Equipment Summary table of Personal Protective Equipment (PPE) to be used during the various stages of the machine's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet — ● ○ — Transport — ● ○ — —... -
Page 7: Transport, Handling And Storage
Transport, handling and storage Protection devices installed on the machine • Due to their size, the machines can be stacked on top of each other during transport, handling and storage by complying with that specified on the slip placed on the packaging. •... -
Page 8: Bappliance And Manufacturer's Identification Data
B APPLIANCE AND MANUFACTURER’S IDENTIFICATION DATA IMPORTANT The hood is intended specifically work with the Electrolux Professional SkyLine and Magistar Oven only; the manufacturer declines any responsibility in case of different use. Data plate position This instruction manual contains information relevant to various appliances. -
Page 9: Cgeneral Information
This manual is intended solely for consultation by the hazards. operator and can only be given to third parties with Risk a combination of probabilities the permission of Electrolux Professional SpA. and risks of injury or harm to health in a hazardous situation. Keeping the manual Protection... -
Page 10: Dtransport, Handling And Storage
The Manufacturer declines any liability for damage The Manufacturer declines any liability for caused by arbitrary modifications and conversions inaccuracies contained in the manual, if due to carried out by the user or the Customer. printing or translation errors. The employer, workplace manager or service Any supplements to the installation, use and technician are responsible for identifying and maintenance manual the Customer receives from the... -
Page 11: Disposal Of Packaging Materials
Given below is the data required for calculating characteristics to ensure maximum efficiency of the appliance. Example: min. duct section 300 x 300 mm (118.11 x 118.11 inches). Exhaust air flow MODELS m3/h 922733 HOBT11 922734 HOBT21 922735 HOBV11 1.600 56.503... -
Page 12: Hood Dimensions
Hood dimensions Depth stacking Width Depth Height Tot. Height model MODELS inches inches inches inches inches 922733 HOBT11 34,45 1070 42,13 17,72 18,58 922734 HOBT21 1098 43,23 1266 49,84 17,72 18,58 922735 HOBV11 36,10 1085 42,72 17,72 18,58 922736 HOBS21... -
Page 13: Finstallation And Assembly
922733 HOBT11 922734 HOBT21 922735 HOBV11 922736 HOBS21 922737 HOBS11 •... -
Page 14: Hood Transport
F.3.2 On hood for ovens with left hinges 1. Unscrew to remove front panel of the hood; 2. remove the pre-cut parts; 3. assemble the front panel of the hood. FRONT Width MODELS inches 922733 HOBT11 34,45 922734 HOBT21 1098 43,23 922735 HOBV11 36,10... -
Page 15: On Hood For Stacked Ovens
F.4 Positioning F.4.1 Minimum distance For the overall space required and connection dimensions, refer to the Hood Installation Diagrams (see page 2) and chap. F of the oven “Installation Manual”; All sides of the appliance must be at least 50 mm from any surface. -
Page 16: Air Duct Connection
The following items are arranged for the assembled support (ref. F.3.1) using the connection of a 300x300 (118.11 x 118.11 inches) screws and toothed washers supplied, to duct: ensure mechanical fastening and the equipotential connection. 922733 HOBT11 922734 HOBT21 922735 HOBV11 922736 HOBS21 922737 HOBS11 To install the ducts refer to the “Hood Installation... -
Page 17: Gmachine Scrapping
MACHINE SCRAPPING G.3 Procedure regarding appliance WARNING dismantling macro operations Refer to Before scrapping the machine, make sure to “WARNINGS and carefully check its condition, and in particular any Safety Information “ parts of the structure that can give or break during scrapping. - Page 18 Electrolux Professional SpA Viale Treviso 15 33170 Pordenone www.electroluxprofessional.com 231007 IM_HO_01_ELUX_EN.docx -...
