- Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27BQ65UB www.lg.com Copyright © 2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 OPEN SOURCE SOFTWARE NOTICE The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered INFORMATION .......... -
Page 3: Open Source Software Notice
Supported Drivers and Software LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. - Page 4 Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. Basic Functions Press the joystick button once with your finger Power on to turn on the monitor.
- Page 5 Moving and Lifting the Monitor Installing on a Table • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.94 When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or inches) away from the wall to ensure sufficient ventilation.
- Page 6 Adjusting the Stand Height Adjusting the Angle Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°...
- Page 7 Pivot Feature Rotate the monitor 90° clockwise and -90° counter clockwise as shown in the figure. The pivot feature allows the monitor to rotate 90° clockwise and -90° counter clockwise. Raise the monitor to the maximum height. Adjust the angle of the monitor in the direction of the arrow as shown in the figure. Complete the installation by rotating the monitor 90°...
- Page 8 WARNING NOTE • • Auto Pivot feature of the display is not supported. Take care when rotating the monitor if the cable is connected. • • To avoid injury when rotating the display, do not place your fingers between the display and the stand base. The screen can be rotated easily using the screenpivot shortcut key provided with your Windows operating system.
- Page 9 Swivel stand Using the cable holder Arrange the cables using the cable holder as shown in the illustration. Swivel (clockwise 45°) Rotate Set(Pivot) and put connectors. It is easy to put connectors and manage cables using cable holder. Swivel (counter clockwise 45°)
- Page 10 Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NOTE at http://www.kensington.com.
- Page 11 Wall Mount Plate Back of the Monitor NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. Wall Mount Plate •...
-
Page 12: Using The Monitor
USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from actual product. NOTE Press the tact key button, go to Settings Input, and then select the input option. •... - Page 13 Connecting LAN Connecting AV Devices LAN connection HDMI Connection Connect the router or switch to the monitor. HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE NOTE • • The LAN cable is sold separately. Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues.
- Page 14 CAUTION Cautions When Using a USB Device • A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. • Some USB devices may not be supported or may not work properly. •...
-
Page 15: User Settings
USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • When Beep Guide is activated, pressing the joystick button will take you to Settings right away. Activating the Main Menu Press the joystick button on the right back of the monitor. - Page 16 Main Menu Features Main Menu Description Input Sets input mode. Power Off Turns off the monitor. Settings Configures the screen settings. Picture Mode Sets the picture mode. Exit Exits the main menu. Menu Settings To view the OSD menu, press the joystick button on the right back of the monitor and then enter the Settings. Move the joystick up/down and left/right to set the options.
- Page 17 Quick Settings Settings > Quick Settings Description Brightness Adjusts the contrast and brightness of the screen. Contrast Adjusts the volume. Volume NOTE • You can adjust Mute / Unmute by Pressing the button in the Volume menu. The user can adjust it to red, green, or blue by customization. Custom Warm Sets the screen color to a reddish tone.
- Page 18 Input Settings > Input Description Input List Selects the input mode. When automatic input switch is set to On, display will automatically switch to new input when connected. Auto Input Switch Enables Auto Input Switch. Disables Auto Input Switch. Adjusts the aspect ratio of the screen. Full Wide Displays the video in widescreen, regardless of the video signal input.
- Page 19 Picture [Picture Mode] on SDR (Non HDR) signal Settings > Picture Description Custom Allows the user to adjust each element. Vivid Heightens contrast, brightness and sharpness to display vivid images. HDR Effect Optimizes the screen for high dynamic range. Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu. Reader Optimizes the screen to improve the visual effects of a video.
- Page 20 [Picture Mode] on HDR signal Settings > Picture Description Custom Allows the user to adjust each element. Vivid Optimized the screen for HDR vivid colors. Cinema Optimized the screen for HDR video. This HDR mode is optimized for FPS games. Picture Mode This HDR mode is optimized for RTS games.
- Page 21 Settings > Picture Description Brightness Adjusts the contrast and brightness of the screen. Contrast Sharpness Adjusts the sharpness of the screen. High Optimizes the screen for crystal clear images. Best for high-definition video or games. Optimizes the screen for comfortable viewing, with images at the middle level between the low and high modes. Best for UCC or SD Middle videos.
- Page 22 Settings > Picture Description Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use Fast. When there is a lot of motion, it is recommended that you use Faster. Setting to Faster may cause image sticking.
- Page 23 Settings > Picture Description Mode 1, Mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes. Gamma Mode 3 Mode 4 If you do not need to adjust the gamma settings, select Mode 4. Set your own color temperature.
- Page 24 Sound Settings > Sound Description Adjusts the volume level. Volume NOTE • You can adjust Mute / Unmute by pressing the button in the Volume menu. MaxxAudio® by waves, recipient of a Technical GRAMMY Award® is a suite of studio-quality sound tools for a superior listening experience. Waves MaxxAudio®...
- Page 25 General Settings > General Description Language Sets the menu screen to the desired language. USB Selection Select the USB upstream cable connection port to use USB hub of the monitor. Conserve energy by using luminance compensation algorithm. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. Saves energy using the low-efficiency SMART ENERGY SAVING feature.
- Page 26 Settings > General Description This feature disables the configuration and adjustment of menus. Enables OSD Lock. Disables OSD Lock. NOTE • The menus except the menus below are disabled. - Brightness OSD Lock - Contrast - Volume - Input List - Auto Input Switch - Aspect Ratio - OSD Lock...
-
Page 27: Troubleshooting
TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the No Signal message being displayed? This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check the cable and reconnect it. •... - Page 28 Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.
-
Page 29: Product Specification
PRODUCT SPECIFICATION LCD Screen Color Depth 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 100-240 V ~50/60 Hz 2.5A On mode: 45 W Typ. (Outgoing condition) * Power Sources Power Consumption Sleep Mode (Standby Mode) ≤... - Page 30 Factory Support Mode (Preset Mode, PC) DisplayPort/ USB-C Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 88.79 59.95 3840 x 2160...
- Page 31 HDMI Timing (Video) Factory support mode Horizontal Frequency(kHz) Vertical Frequency(Hz) Remarks (Preset Mode) 480p 31.5 720p 45.0 1080p 67.5 2160p When HDMI ULTRA HD Deep Color is set to ON...
- Page 32 Beep Guide Menu Location Menu Location Menu Location Quick Settings Input - Aspect Ratio - Full Wide 2 3 1 Picture - Picture Adjust - SUPER RESOLUTION+ 3 2 4 2 - Middle Quick Settings - Brightness Input - Aspect Ratio - Original 2 3 2 Picture - Picture Adjust - SUPER RESOLUTION+ Quick Settings - Brightness...
- Page 33 Menu Location Menu Location Menu Location Picture - Color Adjust - Gamma - Mode 4 3 4 1 4 Picture - Color Adjust - Six Color - Green Sound 3 4 6 4 1 Slider Saturation Picture - Color Adjust - Color Temp 3 4 2 Sound - Volume Picture - Color Adjust - Six Color - Blue Hue...
- Page 34 Menu Location Menu Location General - USB Selection General - Input Compatibility Version - DP: 1.2 / 5 6 2 HDMI : 1.4 General - USB Selection - HDMI 5 2 1 General - DP OUT 5 7 Toggle General - USB Selection - HDMI - USB-B 5 2 1 1 General - Buzzer 5 8 Toggle...
- Page 35 Supplier’s Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs,NJ 07632 E-mail lg.environmental@lge.com The model and serial number of the product are located on the back and on one side of the product.
