Summary of Contents for LG 27MQ70QC
- Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27BQ70QC 27MQ70QC www.lg.com Copyright 2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE ..................... 3 OPEN SOURCE SOFTWARE NOTICE INFORMATION ......4 ASSEMBLING AND PREPARING ............4 USING THE MONITOR ............... 13 USER SETTINGS ................16 TROUBLESHOOTING ................ 21 PRODUCT SPECIFICATION ..............22... -
Page 3: License
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. -
Page 4: Open Source Software Notice Information
It is recommended that use the supplied components. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing • Illustrations in this document represent typical procedures, so they may look different from the actual such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge. - Page 5 • The power cord provided may differ depending upon the region. Supported Software You can download and install the latest version from the LGE website (www.lg.com). • Monitor Driver/ OnScreen Control/ Dual Controller Button...
- Page 6 Moving and Lifting the Monitor CAUTION • Avoid touching the monitor screen as much as possible. When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or - This may result in damage to the screen or some of the pixels used to create images. damaged and to ensure safe transportation, regardless of its shape or size.
- Page 7 Installing on a Table CAUTION After folding the stand to secure it, lift the monitor and place it on the table in an upright position. • Make sure the table on which the product is installed is stable and solid. A table made of fragile materials such as glass may be damaged.
- Page 8 Adjusting the Angle Using the Kensington Lock The angle of the screen can be adjusted forward or backward from -5° to 10° for a comfortable viewing For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website experience.
- Page 9 Installing on the Wall NOTE • Secure at least a certain amount of vertical flat space in the partition to be installed. The stand can be unfolded by pushing the button on the back of the product. In addition, ensure that it is strong and sturdy enough to hold and use the product. B-Type C-Type B-Type...
- Page 10 NOTE CAUTION • The partition in which the product is installed must be sufficiently rigid. If it is made of fragile material such as glass, this may result in damage to the product. • If the partition surface is uneven or tilted, the product may tilt. •...
- Page 11 Webcam Installation When Installing on a Partition Insert the webcam according to the direction in which you wish the camera to shoot, and use it after connecting it to the monitor. When Installing on a Table CAUTION • Do not mount the webcam on the bottom of the monitor.
- Page 12 NOTE Adjusting the Angle • The USB-C port on the side of the monitor and the USB-C port on the PC must be connected with a USB-C The angle of the webcam can be adjusted from -15° to 10° (or 15°) front and back for comfortable use. cable in order for the webcam to function.
-
Page 13: Using The Monitor
(Menu) button on the side of the monitor and select the corresponding input from the [Input] menu. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion. •... - Page 14 Connecting to a PC USB-C connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the feature. NOTE : A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.
- Page 15 Connecting AV Devices Connecting Peripherals HDMI Connection Headset Connection HDMI transmits digital video and audio signals from your AV device to the monitor. Connect peripherals to the monitor via the headset port. CAUTION NOTE • • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. Peripheral devices are sold separately.
-
Page 16: User Settings
USER SETTINGS [Quick Settings] • [Brightness]: Adjusts the brightness of the screen. • [Contrast]: Adjusts the contrast of the screen. NOTE • [Volume]: Adjusts the volume level. • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. •... - Page 17 [Input] [Picture] • [Input List]: Selects the input mode. [Picture] > [Picture Mode] • [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide], • [Custom]: Allows the user to adjust each element. [Original], and [Just Scan] options at the recommended resolution (2560 x 1440).
- Page 18 [Picture] > [Picture Adjust] [Picture] > [Game Adjust] • • [Brightness]: Adjusts the brightness of the screen. [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is •...
- Page 19 [Picture] > [Color Adjust] [Picture] > [Picture Reset] • • [Gamma] Returns picture and color to the default settings. - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the [Sound] lower the gamma value, the lighter the image becomes. •...
- Page 20 [General] • [Deep Sleep Mode]: When [Deep Sleep Mode] is [On], power consumption is minimized while the monitor is in standby mode. • [Language]: Sets the menu screen to the desired language. - [On]: Enables [Deep Sleep Mode]. • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. - [Off]: Disables [Deep Sleep Mode].
-
Page 21: Troubleshooting
TROUBLESHOOTING Screen display is unstable and shaky. / Images displayed on the monitor leave shadow trails. • Did you select the appropriate resolution? - If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended resolution. -
Page 22: Product Specification
• 10-bit color is supported. • Have you installed the display driver? - Be sure to install the display driver from our web site: https://www.lg.com. Resolution • Max Resolution: 2560 x 1440 @ 60 Hz - Make sure to check if the graphics card supports function. - Page 23 AC/DC Adapter Power Sources • • Model: ADS-150KL-19N-3 190140E Power Rating: 19 V 7.0 A Manufacturer: Shenzhen Honor Electronic Co.,Ltd. • Power Consumption • - Operating Mode: 38 W (Typical)* Input: 100-240 V~ 50/60 Hz 2.0 A • Output: 19 V 7.37 A - Sleep Mode (Standby Mode): ≤ 0.5 W - Off Mode: ≤...
- Page 24 Support Mode (Preset Mode, USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024...
- Page 25 (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024...
- Page 26 HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480p 31.5 720p 1080p 67.5 2160p 67.5...
- Page 27 Beep Guide Menu Location Menu Location Picture - Picture Mode - Custom 3 1 1 Picture - Game Adjust - Response Time - Fast 3 3 1 2 Picture - Picture Mode - Vivid 3 1 2 Picture - Game Adjust - Response Time - Normal 3 3 1 3 Menu Location...
- Page 28 Menu Location Menu Location Menu Location Picture - Color Adjust - Six Color - Green Hue 3 4 6 3 1 Slider General - Language - English 5 1 1 General - DisplayPort Version Picture - Color Adjust - Six Color - Green Saturation 3 4 6 4 General - Language - German 5 1 2...
- Page 29 Supplier's Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com (27BQ70QC only) The model and serial number of the product are located on the back and on one side of the product.
