- Page 1 GETZ EQUIPMENT INNOVATORS PART NO: 4G58589 MODEL: EP 303 FH TRIPLE HOSE TESTER (Revised 5/17/07)
- Page 2 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To obtain performance to the obligation of the warranty, write to Getz Equipment Innovators, 2320 Lakecrest Drive, Pekin IL 61554, USA for instructions.
- Page 3 THE GETZ ELECTRIC HYDROTEST PUMP OPERATION AND PARTS MANUAL MODEL #EP-303-FH TABLE OF CONTENTS PAGE # 1............INSTRUCTIONS 2............PARTS LIST 3............PARTS LIST (Cont.) 4............TOP VIEW DRAWING 5............FRONT VIEW DRAWING 6............HOSE ADAPTER DRAWING 7.………………..……………………. MAINTENANCE...
- Page 4 INSTRUCTIONS FOR HOSE HYDROTEST PUMP FOLLOW NFPA 1962 GUIDE LINES WHEN TESTING FIRE HOSES THIS TESTER IS TO BE POWERED ONLY BY A PROPERLY INSTALLED AND TESTED 120V AC GFCI ELECTRICAL RECEPTICAL 1. Connect a garden hose to a clean water source and purge the line to remove air and dirt. 2.
- Page 5 PARTS LIST DRAWING # PART # DESCRIPTION 1G51321 FRAME HOSE HYDRO 1G53371 MOTOR 60 HZ SINGLE 1 HP 1G0102 PIPE TEE BR 1/2 ST 1G0309 FTNG SWIVEL WATER 1G51948 WATER FILTER N 107 1G0084 VLV BALL BR 1/2 X 1/2 FMLE 1G0217 PIPE NIP BR 1/2 X CLOSE 1G0291...
- Page 6 PARTS LIST (Continued) DRAWING # PART # DESCRIPTION 1G52492 AD 1/4 FMLE X 9/16 FL ML 1G51325 CPLG 3/8 HOSE X 9/16 SWIVEL 1G51412 HOSE 3/8 SYNFLEX 2250 PSI 1G51864 SWIVEL MECH 1/2 (9205) 1G51253 CPLG 1/2 ML SYNFLEX 1G51562 MTL SYNFLEX 1/2 2000 PSI 1G51253 CPLG 1/2 ML SYNFLEX...
- Page 10 MAINTENANCE SAE 30 W NON DETERGENT Change after first 50 hours of use, and every 200 hours thereafter. WINTER STORAGE If possible store this unit in a warm dry area when not in use. In conditions where the temperature may drop below freezing, all water must be drained from the system. WATER LEFT IN THIS SYSTEM CAN CAUSE SEVERE DAMAGE 1.
