Getz Equipment Innovators HR-1L Operation Manual

Halon 1211 recovery / recharge system
Hide thumbs

Advertisement

Quick Links

Download this manual
U/L LISTING NO. 58X5
MEETS OR EXCEEDS REQUIREMENTS
OF U/L STD. 2006 AND
NFPA 1990 PAMPHLET # 10
GETZ EQUIPMENT INNOVATORS
HALON 1211 RECOVERY / RECHARGE SYSTEM
MODEL HR-1L
PART NUMBER: 59304
OPERATIONS MANUAL
(Revised 5/29/18)
GETZ EQUIPMENT INNOVATORS
PEKIN, ILLINOIS, U.S.A.
PHONE: 888-747-4389
FAX:
(309)-495-0625

Advertisement

loading
Need help?

Need help?

Do you have a question about the HR-1L and is the answer not in the manual?

Questions and answers

Related Manuals for Getz Equipment Innovators HR-1L

Summary of Contents for Getz Equipment Innovators HR-1L

  • Page 1 GETZ EQUIPMENT INNOVATORS HALON 1211 RECOVERY / RECHARGE SYSTEM MODEL HR-1L PART NUMBER: 59304 OPERATIONS MANUAL (Revised 5/29/18) U/L LISTING NO. 58X5 GETZ EQUIPMENT INNOVATORS MEETS OR EXCEEDS REQUIREMENTS PEKIN, ILLINOIS, U.S.A. OF U/L STD. 2006 AND PHONE: 888-747-4389 NFPA 1990 PAMPHLET # 10...
  • Page 2 All implied warranties, including, but not limited to, warranties of fitness for purpose and merchantability, are limited to the time periods as stated above. In no event shall Getz Equipment Innovators be liable to incidental or consequential damages. Some states do not allow limitations on how long an implied warranty lasts or the exclusions or limitation of incidental or consequential damages, so that the above limitations or exclusions may not apply to you.

  • Page 3: Recommended Spare Parts

    MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM OPERATIONS MANUAL - - TABLE OF CONTENTS PAGE NO.: DESCRIPTION: BASIC SYSTEM BILL OF MATERIALS / OPTIONAL EQUIPMENT SYSTEM OPERATION REQUIREMENTS / AREA REQUIRED SYSTEM SPECIFICATIONS / SYSTEM CAPABILITIES SYSTEM SCHEMATIC ITEM NUMBER / DESCRIPTION SET-UP PROCEDURE SET-UP PROCEDURE (CONT.)

  • Page 4: Optional Equipment

    MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM BASIC SYSTEM BILL OF MATERIALS: RECEIVER TANK WITH DUAL PORT VALVE RECEIVER TANK GAUGE ASSEMBLY AIR POWERED HALON 1211 PUMP CONTROL CONSOLE AND STAND REQUIRED HOSES AND ADAPTERS OPTIONAL EQUIPMENT: PART #52402 AIR COMPRESSOR 5 HORSEPOWER...
  • Page 5 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM SYSTEM OPERATION REQUIREMENTS: 1. AIR COMPRESSOR DELIVERING 65 - 80 PSI AT 13 CFM MINIMUM. NOTE: CUSTOMER SUPPLIED AIR COMPRESSOR MUST HAVE AN ADJUSTABLE PRESSURE REGULATOR AND AN AIR LINE FROM COMPRESSOR TO THE HR-1 SYSTEM.
  • Page 6 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM SYSTEM SPECIFICATIONS: VACUUM - 28 INCHES MAXIMUM SYSTEM PRESSURE - 250 PSI MAXIMUM HALON LIQUID PER MINUTE - 16.5 LBS. MAXIMUM MOISTURE EYE - 20 PPM (GREEN = DRY) 65 PPM (YELLOW = WET)
  • Page 7 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM PAGE 4. GETZ EQUIPMENT INNOVATORS - - PEKIN, ILLINOIS HR-1L/0518...
  • Page 8 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM ITEM NUMBERS / DESCRIPTION: ITEM NUMBERS / DESCRIPTION: MOISTURE INDICATOR – 3G59055 28. CONTROL CONSOLE – 1G51245 PRESSURE / VACUUM GAUGE – 1G0440 29. NITROGEN SUPPLY HOSE ASSEMBLY – 3G59676 DISCHARGE PRESSURE GAUGE – 1G0439 30.
  • Page 9 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM SET-UP PROCEDURE: AFTER ALL CARTONS AND BOXES HAVE BEEN OPENED AND ALL PARTS AND COMPONENTS UNWRAPPED, LAY OUT ALL ITEMS FOR EASE OF ASSEMBLY. CAREFULLY CHECK ALL PARTS FOR EVIDENCE OF CONCEALED DAMAGE. NOTIFY THE DELIVERING CARRIER IMMEDIATELY IF ANYTHING APPEARS TO HAVE SHIPPING DAMAGE.
  • Page 10 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM SET-UP PROCEDURE: (CONT.) 10. PLACE THE RECEIVER TANK (ITEM 18) ON THE SCALE AND LOCATE YOUR HALON 1211 BULK LIQUID SUPPLY CYLINDER TO THE RIGHT HAND SIDE OF THE CONTROL CONSOLE. YOUR HALON 1211 SUPPLY CYLINDER SHOULD BE PRESSURIZED WITH NITROGEN TO APPROXIMATELY 60 PSI.
  • Page 11 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM RECOVERY PROCEDURE: REMOVE NOZZLE OR HOSE ASSEMBLY FROM EXTINGUISHER VALVE AND INSTALL PROPER RECHARGE ADAPTER, TIGHTENING SECURELY. CONNECT THE FEMALE QUICK COUPLER (ITEM 20) TO THE EXTINGUISHER RECHARGE ADAPTER AND PLACE EXTINGUISHER (ITEM 32) ON THE SCALE PLATFORM.
  • Page 12 ALL LIQUID RESIDUE OUT OF THE VALVE AND WIPE EXTINGUISHER TO DRY THE EXTERIOR. REINSTALL THE HOSE OR NOZZLE, SAFETY PULL PIN AND LOCKWIRE SEAL. 12. CONTINUE EXTINGUISHER RECHARGE PROCEDURE, PROCEED TO THE NEXT OPERATING PROCEDURE OR CLOSE ALL VALVES. PAGE 9. GETZ EQUIPMENT INNOVATORS - - PEKIN, ILLINOIS HR-1L/0518...
  • Page 13 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM PROCEDURE FOR ADDING NITROGEN TO RECEIVER TANK: INSTALL A NITROGEN PRESSURE REGULATOR TO THE SUPPLY VALVE OF YOUR NITROGEN SUPPLY CYLINDER. ATTACH THE 1/4" NPT MALE HOSE COUPLING ON THE NITROGEN SUPPLY HOSE (ITEM 29) TO THE REGULATOR ON YOUR NITROGEN SUPPLY CYLINDER.
  • Page 14 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM RECYCLE PROCEDURE: ( FOR REMOVAL OF MOISTURE, PARTICULATE AND/OR COLOR ) CAUTION: IF THE MOISTURE INDICATOR ON THE CONTROL CONSOLE (ITEM 1) IS YELLOW OR THE HALON 1211 IS ANY COLOR EXCEPT CLEAR, THE HALON MUST BE RECYCLED THROUGH THE SYSTEM BEFORE YOU REFILL THE EXTINGUISHER.
  • Page 15 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM RECYCLE PROCEDURE: (CONT.) 11. CLOSE THE BLUE HANDWHEEL (ITEM 10) ON THE DUAL PORT VALVE (ITEM 8) AND ALLOW THE SYSTEM TO CYCLE UNTIL THE PRESSURE/VACUUM GAUGE (ITEM 2) READS 5 INCHES OF VACUUM.
  • Page 16 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM PROCEDURE FOR FILTER REPLACEMENT AND CLEANING BRASS STRAINER: CLOSE THE 1/4" RED AND BLUE BALL VALVES (ITEMS 19 & 21) ON THE DUAL HOSE ASSEMBLY (ITEM 25). TURN THE SELECTOR VALVE (ITEM 4) ON THE CONTROL CONSOLE TO THE RECEIVER POSITION. OPEN THE BLUE AND RED HANDWHEELS (ITEMS 10 &...
  • Page 17 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM RECOMMENDED PERIODIC MAINTENANCE: ( MINIMUM RECOMMENDATIONS - PERFORM MORE FREQUENTLY IF REQUIRED ) LUBRICATE ALL MALE QUICK CONNECTS (ITEMS 9, 16 & 33) AND RECHARGE ADAPTERS (ITEM 38, 39, 40 & 41) WITH A LIGHT COAT OF HIGH QUALITY O-RING LUBRICANT WHEN FEMALE QUICK COUPLERS (ITEMS 7, 15, 17 & 20) ARE DIFFICULT TO DISCONNECT.

  • Page 18: Troubleshooting Guide

    MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM TROUBLE SHOOTING GUIDE: PROBLEM: SOLUTION: A. HALON FLOWS SLOWLY OR NOT A. 1. MAKE SURE ALL LIQUID VALVES (BLUE) ARE OPEN AT ALL THROUGH SYSTEM. AND SELECTOR VALVE IS IN THE PROPER POSITION. CHECK OR CHANGE FILTERS INSIDE OF FILTER HOUSING (ITEM 22) AND CLEAN BRASS STRAINER (ITEM 46).
  • Page 19 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM TROUBLE SHOOTING GUIDE: (CONT.) PROBLEMS: SOLUTIONS: G. RED, BLUE OR GREEN BALL VALVES G. REPLACE WITH NEW BALL VALVE/S. LEAK HALON. H. RELIEF VALVE EXHAUSTS HALON. H. REFER TO "OPERATIONS MANUAL" ON THE PROCEDURE YOU ARE PERFORMING.
  • Page 20 MODEL HR-1L HALON 1211 RECOVERY/RECHARGE SYSTEM RECOMMENDED SPARE PARTS: QUANTITY ITEM CODE DESCRIPTION 1 EACH 1G51908 PUMP VALVE ( 2 WAY - BRASS ) 1 EACH 1G51902 LIQUID/VAPOR VALVE ( 3 WAY - BRASS ) 1 EACH 1G51432 MOISTURE EYE...
