Becker VTLF 2.200 Operating Instructions Manual page 5

VTLF 2.xxx SK
3000 h
5
V TL F 2 . 2 0 0 / V TL F 2 . 2 50 / V T LF 2. 3 6 0
H
19
21
A
MAX.
MIN.
VTLF 2.200/2.250 → No. 90136701005 (SET)
VTLF 2.360 → No. 90132500005 (SET)
23
F1: D: 218 mm
H: 122 mm
D
No.: 90951200000
F1: (polyester)
VTLF 2.xxx/6
No.: 90959600000
F2: D: 64 mm
H: 120 mm
2x No.: 90951000000
13
A = 65mm
MAX
A
= 41mm
MIN
A < 41mm
I 5
20
22
24
