- Page 1 MTS156 Monitor with Touch Screen Instructions for Use English For more translations (available in pdf), please visit www.medicapture.com/support MTS156-IFU01-EN-230809-MC Version 1.0...
- Page 2 MediCapture MTS156 Instructions for Use – English ® Precautions for Use Symbols in the manual Warning This image indicates the manufacturer Indicates a potentially hazardous situation and appears next to the manufacturer’s or improper use that could result in serious name and address.
- Page 3 MediCapture MTS156 Instructions for Use – English ® WARNING Do not modify this equipment without authorization of the manufacturer. To reduce the risk of fire or shock hazard, do not expose this equipment to rain or moisture, this device is designed for indoor use only.
- Page 4 MediCapture MTS156 Instructions for Use – English ® (CANADA ONLY) Note régionale pour le Canada Précautions d’utilisation Symboles utilisés dans le manuel AVERTISSEMENT Cette image désigne le fabricant ; elle apparaît Indique une situation potentiellement à côté du nom et de l’adresse du fabricant.
- Page 5 MediCapture MTS156 Instructions for Use – English ® (CANADA ONLY) Note régionale pour le Canada MISE EN GARDE Ne pas modifier cet équipment sans autorisation expresse du fabricant Afin de réduire les risques d’incendie ou d’électrocution, n’exposez pas cet équipement à la pluie ou à l’humidité. Cet équipment est exclusivement destiné...
-
Page 6: Table Of Contents
MediCapture MTS156 Instructions for Use – English ® Table of Contents Technical Support ................................6 Residual Risks ...................................7 Important Safety Instructions to avoid residual risks....................7 Data Protection ..................................8 Intended Use: ..................................8 General Functional Description: ..........................8 First installation / General preparations for safe operation and performance: ..............8 Checks before you operate the device: ........................9... -
Page 7: Residual Risks
MediCapture MTS156 Instructions for Use – English ® Residual Risks Important Safety Instructions to avoid residual risks. 1. Read all of these instructions and Instructions for Use of the host device. 2. Keep these instructions. 3. Heed all warnings in these instructions. -
Page 8: Data Protection
USB-type C video connections from the host device may also be able to transmit graphical information. 3. Connect a USB cable with the USB port (Type C) of MTS156 to a USB-A port (Type A) of the host device, for example an MVR recorder. MTS156 requires about 5V, 1.5 A power from the USB port of the host device. -
Page 9: Checks Before You Operate The Device
Standby Mode: MTS156 automatically enters standby mode 65 seconds after video input signal is interrupted (no video input signal). Note: If you want to turn off (terminate) the MTS monitor permanently, please disconnect the USB cable from the host device. -
Page 10: Back Panel - Connections
Back Panel - Connections MediCapture MTS156 Instructions for Use – English ® Back - Connections Backside, side connections and buttons + Button ① – Button ② Menu button ③ USB (type A) ④ For external devices. Example: Power for active loudspeakers. -
Page 11: Back Panel - Vesa Mount
2. If this measure is not sufficient, or you cannot see the settings menu clearly, please connect the external USB power adapter, included with the MTS156 monitor, to the second USB (type C) port of the monitor. (Number in the ⑥... -
Page 12: Appendix A: Mts156 Specifications
MediCapture MTS156 Instructions for Use – English ® Appendix A: MTS156 Specifications Function Monitor with touchscreen function. Case Aluminum Alloy Touch function Capacitive Touch Screen Size 15.6” diagonal (w x h: 344,2 x 193,6 mm) Screen Resolution 1920 x 1080... -
Page 13: Compliance / Certification / Classification
MediCapture MTS156 Instructions for Use – English ® Compliance / Certification / Classification Compliance and Medical Equipment Safety: Certification EU: EN 60601-1: 2006+A1:2012+A12:2014+A2:2021 UK: BS EN 60601-1: 2006+A1:2012+A12:2014+A2:2021 US: AAMI ES60601-1:2005+A1:2012+A2:2021 Electromagnetic Compatibility EMC: EN 60601-1-2:2015+A1:2021 Low Voltage Directive: (2014/35/EU) -
Page 14: Appendix B: Medicapture Limited Warranty
MediCapture MTS156 Instructions for Use – English ® Appendix B: MediCapture Limited Warranty MediCapture Inc. (“MediCapture”) warranties the product(s) listed below to be free of defects in materials and workmanship for a period of one (1) year. Should warranty service be required, the warranty period will be extended by the number of days required to restore normal operation and return the product(s).
