Toastmaster RH36D1 Brochure

RH36D Series - Deck Oven Base
INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product, reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: 847-741-3300 - Fax: 800-635-4725 - www.toastmastercorp.com
Form 803 Rev 0 (02/05)
RH36D Series - Deck Oven Base
for power supply entrance. See
Application
electrical data for kW rating of range
You can saute, braise, pan fry, griddle,
tops. Oven kW rating is 6.0, 3.0 kW
boil, stew, simmer, bake, brown, roast
for each of the top and bottom heating
and reconstitute with the versatile
sections.
Toastmaster heavy-duty range.
Heating
General Information
Heating is accomplished with formed
Heavy-duty electric range with deck
tubular elements clamped underneath
oven base. Range is 36"W x 38-1/2"D
each griddle and rectangular hotplate.
x 38-1/4"H including legs.
The RH36D3 has 4 heating sections
for the 36" surface. The RH36D6 and
Construction
the RH36D7 have two heating
The frame of the range and oven is
sections under the 24" x 24" grid
welded aluminized steel with stainless
surface. Oven heating is
steel front, sides, top and back.
accomplished with top and bottom
Grease troughs are located at front
heating sections. Oven will preheat to
and rear for drainage, with grease
450 o F in 20 minutes.
chutes into two wide, drawer-type
receptacles. The RH36D3, RH36D6
Controls
and RH36D7 are furnished with
Range-top section controls are
splash guards surrounding back and
mounted in a central ventilated control
side of the griddle section. The deck
panel, hinged for easy service access.
oven is provided with aluminized steel
9" solid round hotplates are controlled
inner lining; removable deck of
by an indicating 3-heat switch. The
rigidized steel; vent with damper; and
12" x 24" hotplate sections on the
shelf-type, stainless steel lined door.
RH36D1 and RH36D2 are controlled
The oven is insulated on all sides.
by a thermostat with a temperature
Range is 100% front serviceable.
range of 250oF to 850oF. The griddle
sections on the RH36D3, RH36D6
Electrical
and RH36D7 are controlled by a
Wiring is connected at a terminal
thermostat with a temperature range
compartment in the base. Knockouts
of 150 o F to 450
are provided in the bottom and back
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: 847-741-3300 - Fax: 800-635-4725 - www.toastmastercorp.com
Form 803 Rev 0 (02/05)
Foodservice Equipment
Job ________ Item# ________
with a 2 hour timer adjustable from 6
to 120 minutes (timer has a bell
signal). The oven temperature is
controlled by a thermostat adjustable
from 200oF to 550oF. The top and
bottom heating elements are
independently regulated with a 3-heat
switch. Each thermostat is provided
with an "OFF" position. Each 9"
diameter hotplate is provided with a 4-
position, 3-heat switch "HIGH"/
"MEDIUM"/"LOW" and "OFF" settings.
An indicator light is associated with
each thermostat, indicating when
preset temperature is reached and
cycles on or off.
RH36D4
Capacity
The oven section is provided with a
slide out removable rack. Each rack
will accommodate (2) 12" x 20" #200
pans, (1) 18" x 26" roll pan, (1) 18" x
24" meat pan, (10) standard 1 lb. loaf
pans or (6) 9" pie tins. Oven has a
total meat capacity of 60 lbs. Oven
has a clearance height of 12-1/2".
Warranty
Warranted for one year covering parts
and labor.
Ordering Information
Basic Models - 208VAC or 240VAC or
480VAC (3 phase) voltage must be
specified.
Specify "assembled" or "hatchable".
Hatchable is packaged in two sections
that can pass through a 26" wide door
for assembly in kitchen.
Options At Extra Cost
!
480VAC, 3 Phase.
!
ACCS06K - Set of four, 6-1/4" high
caters.
!
ACRK36K - Extra intermediate
slide-out oven rack.
!
ACCCURBMH - Stainless steel sub-
base.
!
MH36KITA - Marine Kit, tops 1, 2
and 4
!
MH36KITB - Marine Kit, tops 6 & 7
!
MH36KITC - Marine Kit, tops 3
o F. Range is provided
