YUNZII YZ98 Manual

Tri-mode wireless customized mechanical keyboard

Advertisement

Quick Links

YZ98
Tri-Mode Wireless Customized
Mechanical Keyboard
Content List:
YZ98 Keyboard x 1
USB Cable for TYPE-C x 1
Keycap and Switch Puller x 1
Extra Keycaps and Switches x 1
Warranty Manual x 1
6. 2.4G Wireless Receiver x 1
7. PET Dust Cover x 1
2.4G Wireless Receiver Connection:
Switch the mode button to
Mode.
Then long press FN+R=2.4G, and the indicator light blinks blue.
Plug the 2.4G receiver into the computer USB port, then it will
pair and install the compatible program automatically.
The indicator light will stay on when paired successfully.
YZ98
Quick Start Guide:
USB Cable for TYPE-C 2.4G Wireless Receiver
YZ98 Mechanical Keyboard
USB Cable Connection:
Switch the mode button to the middle Wired Mode.
When the cable is plugged in.
The keyboard will connect with the computer automatically,
then it is ready for usage.
YUNZII YZ98 Keyboard On-Off Manual
Switch for MacOS and
Tri-Mode Switch Between Bluetooth,
Windows Mode
Wired and 2.4G Wireless
TYPE-C Port
2.4G Receiver Port
Charging:
Charge the keyboard by connecting the original charging
cable to the computer USB port, or using a DC-5V charger.
Note the direction of the TYPE-C cable and insert it
carefully. The RGB will light red when charged and will go
off when fully charged.
Compatible System:
The YZ98 keyboard supports Windows2000, WindowsXP,
Vista Win7, Win8, Win10, Win11, MacOS and mobile phone
systems.
Quick Start Guide of FN key combination:
Screen Brightness ↑
Stop
Screen Brightness ↓
Mute
Calculator
Volume Down
Computer
Volume Up
Player
Bluetooth Channel 1
Previous Song
Bluetooth Channel 2
Next Song
Bluetooth Channel 3
Pause/Play
2.4G
Bluetooth Connection:
Switch the mode button to
Mode. Then long press
FN+Q=BT1, and the indicator light blinks green. Press
FN+W=BT2, and the indicator light blinks pink. Press
FN+E=BT3, and the indicator light blinks yellow.
Quick Start Guide of RGB Settings:
Backlight Effects
Change Backlight
Effect
ON/OFF
Brightness Up
Reset
Right
Brightness Down
Battery Query
Blinking Speed ↑
INS
Change Side-light
Right
Blinking Speed ↓
Effect
White Light
Side light Speed
ON/OFF
Change Backlight
Side light Brightness
Color
Lock Win
www.yunzii.com
