RFM-C3 WMBUS Concentrator
User manual v1.5

Table of contents

1. Introduction ............................................................... 1
1.1 Package content ..................................................... 1
1.2 Interfaces ............................................................... 2
1.3 Installation .............................................................. 2
1.4 Mounting ................................................................ 3
2. Function and use ..................................................... 3
2.1 Device startup ....................................................... 3
2.3 Wireless M-BUS interface ................................... 3

1. Introduction

The RFM-C3 is a gateway/data concentrator that collects data sent from Wireless M-Bus devices and transmits them via GPRS signal or
via Ethernet/LAN/Wi-Fi network. It can also be used in conjunction with the mod.MB-MASTER in order to remotely send the data detected
from the wired MBUS modules. The consumption data and the information sent by the compatible devices, are collected by the RFM-C3
concentrator and sent via E-mail SMPT or using FTP/SFTP server connection by using the GPRS network or, alternatively, an Internet
connection via Ethernet/LAN/Wi-Fi network. The E-mail contains the file of the acquired telegrams in txt and csv format and it is forwarded
up to a maximum of five recipients, with hourly, daily, weekly, monthly frequency depending on the configuration set.

1.1 Package content

> RFM-C3
> Power supply +5VDC Output
> SMA antenna
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
> GPRS antenna
> "Quick User Guide" Instruction sheet
> Antenna Extension (bracket included)
3. Configuration and commissioning ......................... 3
3.1 Configuration from WEB browser ........................ 3
3.1.1 Configuration preparation .................................. 3
3.1.2 Access to the application .................................. 4
3.1.3 Configuration page use ..................................... 4
3.2 Device test ............................................................ 8
4. Accessories ............................................................. 8
4.1 Antenna extension ................................................ 8
B METERS srl
Via Friuli, 3
33050 Gonars (UD)
Italy
Tel: +39 0432 931415
Tel: +39 0432 1690412
Fax: +39 0432 992661
Sales/info: info@bmeters.com
Support: ticket@bmeters.com
www.bmeters.com
For further information, scan the
QR Code to visit the website
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFM-C3 and is the answer not in the manual?

Questions and answers

Related Manuals for B meters RFM-C3

Summary of Contents for B meters RFM-C3

  • Page 1: Table Of Contents

    1. Introduction The RFM-C3 is a gateway/data concentrator that collects data sent from Wireless M-Bus devices and transmits them via GPRS signal or via Ethernet/LAN/Wi-Fi network. It can also be used in conjunction with the mod.MB-MASTER in order to remotely send the data detected from the wired MBUS modules.

  • Page 2: Interfaces

    1.3 Installation > Install RFM-C3 in a safe and protected area, away from possible radio shielding that might affect the reception quality. > May not be operated on sites exposed to direct sunshine or in the nearby of heat sources.

  • Page 3: Function And Use

    2.3 Wireless MBUS interface The default mode of the RFM-C3 is the “listen all”. The device will save the telegrams received in a buffer file in the internal memory, up to a maximum of 1000 telegrams. The concentrator overwrites the obsolete telegrams with newer telegrams received from the WMBUS devices, so the buffer file will always contain the most updated reading for each module.

  • Page 4: Access To The Application

    Set the option button on “User Follow the next directory: Control Panel —> Network configured” and set: and Internet —> Network and sharing center A new window will > IP Address: 192.168.1.2 —> Change adapter settings. appear: select “alternative > Subnet Mask: 255.255.255.0 On this window, right click on the “Local Network configuration”.
  • Page 5 Ethernet settings: > Mode: It allows to set the IP assignment mode. Select Static if you want to assign a fixed IP address or Dynamic if you want the router to set all the net parameters automatically. > Static IP: this field allows to set the address assigned to the concentrator. In Dynamic mode, if the concentrator is not connected to a router it will maintain the Static IP address.
  • Page 6 Note: using of the default SMTP server (Use Default E-mail configuration: enabled) will only allow the pkfile.txt sending (therefore not of the csv file) containing the telegrams received from both wireless and wired MBUS devices. In addition, data sending with hourly frequency will not be available (maximum configurable frequency: 1 data transmission per day).
  • Page 7 Reading options settings > Read always: if this is selected the concentrator will read all the time. > Days of Week: select the reading day/s by ticking one or more checkboxes. > Start Reading Hour: the hour of reading start. >...

  • Page 8: Device Test

    As soon as all the devices in the network are given a primary address and are completerly set up, you can proceed with the primary address search and configuration with the RFM-C3 web page. This will speed up the commissioning process.
