EN - 6
FAQ
Q: TV display "Waiting for connection" on the right corner?
A: Please check if the power supply of TX (Sender) and switcher (if
used) is connected, and make sure connecting cable is firmly.
Q: TV display "Please check the TX input signal" ?
A: 1) please check if there is a HDMI signal input of TX.
2) Try to connect the signal source directly to display device to
see if there is signal output from source device or change the
signal source, HDMI wire and try again.
Q: Display not fluent, not stable?
A: 1) Please check the cable length between the TX to switch, the
switch to the RX and the connection between each level is within
the required range.
2) Click the "reset" button on the TX/RX front panel, reset and
reconnect.
SPECIFICATION
Items
HDMI signal
Support resolutions
Network cable
Transmission distance
Transmission rate
Working temperature
Power Supply
Power consumption
Protection
Dimensions
Weight
Color
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: no guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is marked
with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products
in compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
With the CE sign, Techly
to the basic European standards and directives.
WWW.TECHLY.COM
HDMI EXTENDER OVER IP
Specifications
HDMI1.3 compatible with HDCP1.4
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz
UTP/STP Cat5E/6
Up to 120m transmission distance
for 1080p 60Hz Full HD over single
CAT6
Cat5 80m/ Cat5E 100m/ Cat6 120m
18 Mbps
0°C – 60°C
DC5V/1A
TX: 3.5W; RX: 3W
Lightning protection, surge
protection, ESD protection
110 (W) x 58 (D) x 26 (H) mm * 2pcs
TX: 125g RX: 120g
Black
ensures that the product is conformed
®
