Model # 976256-24V · Timed PF Entryway MV Foam Sanitizer - 24VAC
REQUIREMENTS
Ready-to-Use Chemical Solution
Temperature
Pressure
Flow
Supply Line
Compressed Air
Hose
Nozzle
Electric
OPTIONS
Central Pump Systems (AODD)
Mini-Central Pump System (1/2" PP)
Central Pump System (1" SS)
Level Masters Provide an Automatic Supply
of Ready-to-Use Chemical
Level Master (Various Tank Sizes)
Gemini Level Master (Various Tank
Sizes)
High Flow Level Masters Provide an
Automatic Supply of Ready-to-Use Chemical
60/10 High Flow Level Master
60/20 High Flow Level Master
OVERVIEW
The Timed PF Entryway MV Foam Sanitizer is an automated foam applicator for projecting sanitizing chemicals on to floors of 6' wide double doors to prevent cross
contamination. This system receives ready-to-use chemical from a user-supplied central chemical feed system. Rich, clinging foam is created by injecting compressed
air into the solution to greatly increase volume and coverage ability. Foam is then projected through the discharge hose and Spreader™ nozzle. The system timer is
user-programmable to meet the needs of any facility. This unit requires 24VAC electrical input - a locally sourced standard step-down transformer is required.
Lafferty Equipment Manufacturing, LLC • 5614 Oak Grove Road • North Little Rock, Arkansas 72118
Lafferty Equipment Manufacturing, LLC
Installation & Operation Instructions
up to 160°F
35 to 75 PSI
2.45 GPM @ 40 PSI
1/2"
up to 3 CFM
1" ID x 25'
MV Entryway Spreader
24V
# 919050
# 919060SS
# 989304
# 989316
# 989106
# 989108
www.laffertyequipment.com
501-851-2820
W A R N I N G ! R E A D A L L
I N S T R U C T I O N S B E F O R E
U S I N G E Q U I P M E N T !
Advertisement
Table of Contents
Related Manuals for CFS Lafferty 976256-24V
Summary of Contents for CFS Lafferty 976256-24V
- Page 1 Lafferty Equipment Manufacturing, LLC Installation & Operation Instructions Model # 976256-24V · Timed PF Entryway MV Foam Sanitizer - 24VAC REQUIREMENTS Ready-to-Use Chemical Solution Temperature up to 160°F Pressure 35 to 75 PSI Flow 2.45 GPM @ 40 PSI Supply Line 1/2"...
- Page 2 976256-24V • Timed PF Entryway MV Foam Sanitizer - 24VAC SAFETY & OPERATIONAL PRECAUTIONS UNIT FLOW RATES See Additional Safety Precautions included with the Electrical Control Box Installation Information Always consider electrical shock hazard when working with and handling electrical equipment. If 2.29 uncertain, consult an Electrician.
- Page 3 976256-24V • Timed PF Entryway MV Foam Sanitizer - 24VAC - Page 3 -...
- Page 4 976256-24V • Timed PF Entryway MV Foam Sanitizer - 24VAC Troubleshooting Guide Possible Cause / Solution Problem Startup Maintenance A) Foam surges. 1, 2, 3, 4, 6, 7, 8, 9, 10, 11 13, 15, 16 B) Foam output too wet. 2, 3, 4, 6, 7, 8, 9, 10, 11 13, 14, 15, 16 C) Foam output too dry.
