CFS Lafferty 976250-24V Installation & Operation Instructions

Model # 976250-24V · Timed PF Entryway Foam Sanitizer - 24VAC

REQUIREMENTS

Ready-to-Use Chemical Solution
Temperature
Pressure
Flow
Supply Line
Compressed Air
Hose
Nozzle
Electric

OPTIONS

Central Pump Systems (AODD)
Mini-Central Pump System (1/2" PP)
Central Pump System (1" SS)
Level Masters Provide an Automatic Supply
of Ready-to-Use Chemical
Level Master (Various Tank Sizes)
Gemini Level Master (Various Tank
Sizes)
High Flow Level Masters Provide an
Automatic Supply of Ready-to-Use Chemical
60/10 High Flow Level Master
60/20 High Flow Level Master

OVERVIEW

The Timed PF Entryway Foam Sanitizer is an automated foam applicator for projecting sanitizing chemicals on to floors of 3' wide employee walk doors to prevent
cross contamination. This system receives ready-to-use chemical from a user-supplied central chemical feed system. Rich, clinging foam is created by injecting
compressed air into the solution to greatly increase volume and coverage ability. Foam is then projected through the discharge hose and Spreader™ nozzle. The
system timer is user-programmable to meet the needs of any facility. This unit requires 24VAC electrical input - a locally sourced standard step-down transformer is
required.
Lafferty Equipment Manufacturing, LLC • 5614 Oak Grove Road • North Little Rock, Arkansas 72118
Lafferty Equipment Manufacturing, LLC
Installation & Operation Instructions
up to 160°F
35 to 75 PSI
1.34 GPM @ 40 PSI
1/2"
up to 3 CFM
3/4" ID x 25'
Entryway Spreader
24V
# 919050
# 919060SS
# 989304
# 989316
# 989106
# 989108
www.laffertyequipment.com
501-851-2820
W A R N I N G ! R E A D A L L
I N S T R U C T I O N S B E F O R E
U S I N G E Q U I P M E N T !
