RAK3372 Quick Start Guide
This quick start guide shows how can you use the RAK3372 as a WisBlock Core module. It is a step-by-step guide
on how to prepare your hardware as well as how to set up the needed software.
There are more features and applications possible for RAK3372 WisBlock Core but this guide only demonstrates
LED Breathing
and
LoRaWAN OTAA
Following this guide successfully ensures that you have a working RAK3372 WisBlock Core.
This guide also includes instructions on how to perform
Prerequisite
What Do You Need?
Before going through each step in the installation guide of the RAK3372 WisBlock Core Module, make sure to
prepare the necessary items listed below:
Hardware
RAK3372 WisBlock Core
Your choice of
WisBlock Base
USB Cable
Li-Ion/LiPo battery (optional)
Solar charger (optional)
Software
Arduino IDE
Download and install the
⚠
WARNING
If you are using Windows 10:
Do NOT install the Arduino IDE from the Microsoft App Store. Instead, install the original Arduino IDE from
the Arduino official website. The Arduino app from the Microsoft App Store has problems using third-party
Board Support Packages.
Add
RAK3172 as a supported board in Arduino IDE
of Arduino IDE with the JSON URL below.
https://raw.githubusercontent.com/RAKWireless/RAKwireless-Arduino-BSP-Index/main/package_rakwirel
After that, you can then add RAKwireless RUI STM32 Boards via Arduino board manager.
Product Configuration
Hardware Setup
example.
Arduino IDE
.
firmware
update.
by updating Board Manager URLs in Preferences settings
json
