Summary of Contents for Tegeler Creme
- Page 1 Creme User Manual...
- Page 2 Page 2 Creme Manual Tegeler.com...
- Page 3 Creme User Manual Page 3 Table of Contents Table of Contents Safety Instructions Connections Power and Fuse Output Input Page 3 Page 5 Page 7 Controls Equalizer Bypass Low Boost Output Low Freq EQ→Comp/Comp→EQ High Freq Power High Boost Page 7...
-
Page 4: Safety First
Page 4 Page 4 Creme User Manual Creme User Manual Safety first Tegeler.com... -
Page 5: Safety Instructions
Creme User Manual Page 5 Safety Instructions Read carefully before using the device. 1. Only use the device in permitted cord can create a fire risk or risk not continue to use the device. and functional outlets. of electric shock. - Page 6 Page 6 Page 6 Creme User Manual Creme User Manual Connections —————————————————————————————————————————-—–—— The device is equipped with an IEC socket. Use a compatible cable only. Read the Safety Instructions section for use before connecting the power cord. POWER AND FUSE Please see the Technical Data section for the appropriate fuse.
- Page 7 Creme User Manual Creme User Manual Page 7 Page 7 Controls —————————————————————————————————————————-—–—— When in bypass mode, the signal is passed directly unprocessed from the input to the output. BYPASS Also, when switched off, the cream is in hard bypass mode due to the relays.
- Page 8 Creme User Manual Equalizer —————————————————————————————————————————-—–—— The Creme is equipped with two broadband equalizer bands. The filter circuit was taken from the Classic Equalizer EQP-1. Parameters not so relevant for the master bus were set to a fixed value of 0. And the control range was limited to a value that makes sense for the mix bus.
- Page 9 Creme User Manual Page 9 —————————————————————————————————————————-—–—— This low-shelving filter increases the level of the frequency band below the selected frequency up to 5dB. LOW BOOST LOW FREQ Hz 20 30 ———————————————————————————————————————-———–—— This high-shelving filter increases the level of the frequency band above the selected frequency up to 5dB.
- Page 10 Page 10 Page 10 Page 10 Creme User Manual Creme User Manual Creme User Manual Compressor —————————————————————————————————————————-—–—— The second important component is the bus compressor. A mix-bus compressor, sometimes also known as a master bus compressor or 2-bus compressor, is used to apply compression to the entire mix as a whole.
- Page 11 Creme User Manual Creme User Manual Creme User Manual Page 11 Page 11 Page 11 ——————————————————————————————————-————————–—— Activates a 6dB high-pass filter in the sidechain. A low-cut filter in a compressor's side-chain is useful for prevent- ing the compressor from being overly triggered by low-frequency content.
- Page 12 Page 12 Creme User Manual trol that. By cutting the problematic frequencies before they reach the compressor, you ensure that the compressor responds more to the overall performance rather than just the problematic frequencies. Compression before EQ: This method is beneficial when you want to control the dynamics of a signal first, then color or shape the tone afterwards.
- Page 13 A good start with a complete mix is that the needle moves just a little. METER If the Creme is on a drum bus, a good start would be for the needle to move up to the 4dB point. In the end, the ear decides.
-
Page 14: Technical Data
Additional Information ——————————————————————————————————-———————————————————————————————-—————–——————— In order to always ensure the highest audio quality, devices manufactured the Tegeler Audio Manufaktur GmbH are always adapted to match the current state of the art and technology. Changes in design, circuits, and controls are made without prior notice. For this reason, it is possible that the specifications and appearance of the device may differ slightly from those described in this document. -
Page 15: Ce Declaration Of Conformity
Page 15 Conformity CE Declaration of Conformity We, Tegeler Audio Manufaktur GmbH, of Weststr.1, 13405 Berlin, Germany, under the management of CEO Michael Krusch, certify and declare under our sole responsibility that the following product Description: Audio Compressor/Equalizer Manufacturer: Tegeler Audio Manufaktur GmbH... - Page 16 Contact Tegeler Audio Manufaktur GmbH Weststr. 1, 13405 Berlin, Germany +49.30.49 79 26 74 contact@tegeler.com www.tegeler.com...
