EDGE THEORY LABS Edge Tub Setup Instructions

Edge Tub Setup and Takedown Instructions

Setup

Detailed setup videos can be found here.
1. Unbox your Chiller and Tub. We recommend keeping the Chiller box for future
transportation needs.
2. Choose your location. Select a flat and smooth surface for the Tub and Chiller that is free
from objects that could potentially puncture or damage the bottom of the tub. A water
source and 120v power source should be accessible. Our optional protection mat can be
used to protect the bottom of the tub and our containment mat can capture any spillage
when getting in or out of the tub. We recommend setting the tub up in a sheltered area
if being set up outdoors for an extended period of time for longevity of your product.
If using the optional protection or containment mat, first place the mat down in the
desired location and set the deflated Tub on top. Remove the Storage Straps and set
aside. Unfold the Tub in the desired orientation.
3. Install the Valve Fittings to the Tub. Ensure there is an O-Ring in place on the elbow side
of the fitting. Replace if not present or leaking will occur. The Connection Ring should be
screwed onto the Tub Fitting by rotating it clockwise until hand tight. Do not tighten with
tools. The Valve Fittings should be oriented as shown (see image).
4. Inflate the Tub. Inflate the Tub using the included Double Action Air Pump, ensuring that
the Inflation Hose is connected to the "Inflate" side of the pump (see image). Open the
Inflation Valve Cap on the Tub by rotating counterclockwise. When inflating the Tub,
check to ensure that the Inflation Valve Pin is in the depressed (out) position or the air
will be released after the Inflation Hose is detached (see image). The Inflation Hose
connects to the Inflation Valve with a quarter turn clockwise to attach, and a quarter
turn counterclockwise to detach. Inflate until the gauge reads 10 PSI. Do not over inflate
or product damage will occur. When done inflating, replace the Inflation Valve Cap with
a clockwise turn.
5. Install the External Water Strainer. First remove the protective Chiller Fitting Caps by
rotating counterclockwise. Then, install the Inner Water Strainer by turning clockwise
onto the red "Inlet" fitting on the Chiller. Ensure the Strainer O-ring near the Chiller body
is in place (see image). The Water Strainer Enclosure fits over the Inner Water Strainer
and should be tightened until hand tight and the enclosure is flush with the Chiller body.
6. Connect the Chiller to the Tub. Connect the water hoses to the Tub Valve Fittings. Ensure
that there is a Hose Gasket in place inside each end of the four threaded hose
connections; if there is not, place a gasket to avoid leaking (this will need to be done on
first setup and if gasket becomes lost or damaged). The green "Water In" fitting on the
