Ironwood SLR330
User Manual
general information.
technical specifi cations. safety considerations.
facility preparation.
delivery and installation. inspection.
pre-operation cleaning.
install saw blade.
operation and adjustments.
machine controls. machine operation.
maintenance.
work space.
connect dust collection system.
replace saw arbor motor belt.
features.
power.
assembly.
rip sawing tips.
Advertisement
Table of Contents
Related Manuals for Stiles Ironwood SLR330
Summary of Contents for Stiles Ironwood SLR330
- Page 1 Ironwood SLR330 User Manual general information. features. technical specifi cations. safety considerations. facility preparation. power. work space. delivery and installation. inspection. assembly. pre-operation cleaning. connect dust collection system. install saw blade. operation and adjustments. rip sawing tips. machine controls. machine operation.
-
Page 2: Table Of Contents
Troubleshooting ..............24 9.1 Electrical Diagrams PLEASE REVIEW AND OBSERVE ALL SAFETY INFORMATION / DIRECTIVES BEFORE INSTALLING, OPERATING, OR PERFORMING MAINTENANCE ON THIS MACHINERY. Ironwood SLR330 | User Manual... -
Page 3: General Information
Thank you for your purchase of the Ironwood SLR330 straight • Cast iron machined feed chain block and guide track line rip saw. At Stiles Machinery, our goal is to ensure that you are • 18" ripping width capacity fully satisfied with your purchase. This manual is provided so that you may properly assemble, operate, and maintain your SLR330. -
Page 4: Technical Specifications
600 cfm @ 4,500 feet/min Motor Power 230v (3-phase) Amperage 40 amps Shipping Dimensions (h x w x l) 68" x 45.3" x 70.9" (1720mm x 1150mm x 1800mm) Shipping Weight 3370 lbs (1530 kg) Ironwood SLR330 | User Manual... -
Page 5: Safety Considerations
These warning labels are very important and should be kept clean and never removed. If warning labels become damaged or lost, • The principles of machine operation. contact Stiles Machinery immediately for replacements. • The safe handling of the workpiece when cutting. Label 1: Hazardous voltage label •... -
Page 6: Facility Preparation
2.0 Facility Preparation Prior to uncrating your machine confirm that your location can 2.3 Power accommodate the Ironwood SLR330. Follow these guidelines: WaRninG 2.1 Floor A licensed electrician must connect the SLR330 to the building power source. • The floor must be flat and level. -
Page 7: Delivery And Installation
Remove and save all paperwork attached to the outside of the damage on the bill of lading, take pictures of potential damage, and crate. contact Stiles Machinery immediately at 616.698.7500 and ask to Remove the crating, starting with the top, then remove the four speak with the traffic department. -
Page 8: Inspection
Be sure the access doors are closed and secured before machine is damaged after you’ve signed for delivery, immediately transporting. call Stiles Customer Service at 616.698.7500. TOOLS REQUIRED: When you are completely satisfied with the condition of your • Fork lift equipment, you should inventory its parts. -
Page 9: Remove Machine From Pallet
When the machine has been placed at its final location, carefully remove the machine from the pallet. The machine is bolted to the pallet for transport. Use a fork lift to move the machine to its nal position. Ironwood SLR330 | User Manual... -
Page 10: Level
Before installing the saw blade, clean its contact faces, saw arbor, and lock washer with a clean cloth. NOTE: Make sure the saw arbor flanges are completely clean when installing the saw blade. Be sure to level the machine Ironwood SLR330 | User Manual... -
Page 11: Connect To Power
To connect power source to the machine: Open the electrical cabinet Place cable through electrical fitting on the bottom of the cabinet. Remove the clear plastic insulator that covers the main incoming power terminals. Ironwood SLR330 | User Manual... -
Page 12: Safety
Like all power equipment, there is danger associated with the Make certain the machine is either unplugged or electrically Ironwood SLR330. Use caution and follow all safety instructions. disconnected and locked out when performing all maintenance, Take every precaution to protect yourself, others around you, and cleaning, or machine adjustments. -
Page 13: Assembly
Loosen the wing nuts on the small pressure rollers and move them away from the saw blade position. Ironwood SLR330 | User Manual... -
Page 14: Attach Rip Fence Assembly
To lock the rip fence in place, push the handle away from you. To release it, pull the handle toward you. The rip fence should glide easily on the linear guideway for quick and easy ripping width adjustment. lower saw arbor Lock Ironwood SLR330 | User Manual... -
Page 15: Connect Dust Collection System
600 cfm. NOTE: Flex hose length should not exceed 30 feet or suction velocity will decrease, causing inadequate dust collection. Dust collection outlet The dust collection outlet is located in the top of the machine. Ironwood SLR330 | User Manual... -
Page 16: Operation And Adjustments
When cutting a thicker workpiece, the indicator scale can be adjusted 2-4mm less than the workpiece thickness to increase pressure. Tighten the pressure roller locking lever to secure the pressure rollers before running the saw. Ironwood SLR330 | User Manual... - Page 17 Open the electrical cabinet and test power leads to ensure power is off. Switch two of the power legs (e.g., L1 and L2). Close the electrical cabinet. Activate power to the machine. Test rotation again. Ironwood SLR330 | User Manual...
-
Page 18: Rip Sawing Tips
CORRECT WRONG Stand at the side of the machine. Never stand behind the ripping line. The danger zone includes an angle of 30 degrees on both sides of the ripping line. Ironwood SLR330 | User Manual... -
Page 19: Adjust Oil Supply To Feed Chain
NOTE: The oil pump in the central lubrication device is not intended for continuous pumping for an extended time. Pressing the manual lubrication button for more than 3 minutes may damage the oil pump motor. Oil inlet Oil level gauge Ironwood SLR330 | User Manual... -
Page 20: Adjust Hold-Down Pressure For Pressure Rollers
RED/LEFT BLUE/RIGHT Manual pumping CONDITION ACT. TIME CONDITION ACT. TIME switch 5 sec 3 min Int. time key 10 sec 15 min Act. time key 15 sec 20 min 20 sec 30 min Adjustment points Ironwood SLR330 | User Manual... -
Page 21: Maintenance
When pouring oil into the tank, be sure impurities and Oil discharge debris do not get inside. screw-point To order oil for the central lubrication device, call Stiles Machinery at 1-800-727-8780. The central lubrication device uses the following oil: Viscosity Ambient Temp. -
Page 22: Inspection
To order oil for the reduction gear box, call Stiles Machinery at 1-800-727-8780. The reduction gear box uses the following oil. Lubrication points are indicated on the accompanying drawing. Load Ambient Temp. Shell Oil Mobil Oil ISO VG 0~5ºC Omala 150... -
Page 23: Replace Saw Arbor Motor Belt
Blow out the bottom of the chain to free up loose debris. Manually jog the chain to clean each chain section until the chain is completely clean. 10. Reattach the feed chain safety cover. Ironwood SLR330 | User Manual... -
Page 24: Troubleshooting
Check connections and tighten if necessary power terminals Motor will not run Motor damaged Check and replace motor Magnetic switch damaged Replace switch If you cannot resolve your issue, contact Stiles Technical Support at 616.698.6615. Ironwood SLR330 | User Manual... -
Page 25: Electrical Diagrams
9.1 Electrical Diagrams Ironwood SLR330 | User Manual... - Page 26 9.2 Electrical Diagrams (Continued) Ironwood SLR330 | User Manual...
- Page 28 Stiles Machinery Inc. 3965 44th St. SE Version A Grand Rapids, MI 49512 September 2013 p. 616.698.7500 f. 616.698.9411 © 2013 Stiles Machinery Inc. www.stilesmachinery.com...
