MORITEX MLEP-B070W2LR Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents

1. Introduction
Basic System Configuration
Equipment Control
Installation
1. Introduction
Please read this instruction manual carefully, before starting operation. Keep this book for the whole
product lifetime, and store it in a place easily accessible.
Meanings of Warning Symbol
WARNING
MCEP/MSPP Dedicated LED Controller
MLEP-B070W2LR
INSTRUCTION MANUAL
-
Table of Contents
13
13
14
14
15
15
16
16
16
17
The following warning symbol is used in this manual.
Be sure to fully understand the contents of the warning.
This warning marking indicates a potentially hazardous situation, which can
result in hazard to the operator or damage to the unit, if the directions of this
Instruction Manual are not followed.
-
External Signal Connector
Troubleshooting
13
17
17
19
19
19
20
21
22
23
24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLEP-B070W2LR and is the answer not in the manual?

Questions and answers

Related Manuals for MORITEX MLEP-B070W2LR

Summary of Contents for MORITEX MLEP-B070W2LR

  • Page 1: Table Of Contents

    MCEP/MSPP Dedicated LED Controller MLEP-B070W2LR INSTRUCTION MANUAL Table of Contents Table of Contents 4. Connections 1. Introduction External Signal Connector Precautions for Correct Use Connector for Illuminator Warranty 5. Maintenance Confirming Package Contents Troubleshooting 2. Features 6. Specifications 3. Installation...

  • Page 2: Precautions For Correct Use

    ・ This product needs periodical inspection and exchange of maintenance parts. ・ Whenever trouble occurs, please request repair to MORITEX, and do not dismantle the product by your own. Other precautions ・ When a customer wants to scrap the product, the whole equipment has to be disposed as industrial waste, according to laws and ordinances of the customer’s area.

  • Page 3: Confirming Package Contents

    2. Features Applicable Illuminators ※1 Requirements for applicable MCEP/MSPP series Illuminators (made by MORITEX) : 3pin type: Illuminator of 0.35/0.70 [A] Output Number of output channels: 2 channel ※ Each output channel is controlled separately.
  • Page 4 3. Installation Basic System Configuration ・ This Unit is dedicated for use with/for connection to the MCEP/MSPP Illuminator. Refer to Page 3: Features ・ For external control, it is possible to connect an external apparatus via the External Signal Connector. Connector for Illuminator.

  • Page 5: Installation

    Installation Install horizontally on the rubber feet at the bottom of the unit. ※ Install the unit in such a way, that adequate space is left free for ventilation. Keep space of at least 10mm around the main body. ※ Be sure to install the unit in such a way that the Power Switch can be operated easily and the Mains Plug can be pulled out without hindrance, in case of emergency.
  • Page 6 ※2 Input to EXT_VR(9) conforms to only a signal of variable resistor of 10KΩ connected to 2.5 Vref(13P) and GND(11P). ・Input 0V (GND) : Min / Input 2.5V : Max ・Please do not use 2.5 Vref besides a designated usage. ※3 Circuited to GND with 10KΩ...

  • Page 7: Connector For Illuminator

    Connector for Illuminator (for MCEP/MSPP Illuminator: OUT1, OUT2) Model Output Connector of the Unit Connector of the Illuminator SMP-03V-BC (made by JST) SMR-03V-B (made by JST) or its equivalent Pin assignment: Connector for Illuminator Function/Identification ※1 0.70A Output Current (+) ※1 0.35A Output Current (+) Output Current (-)

  • Page 8: Specifications

    ※5 MLEP-B070W2LR, except stated explicitly do comply to these European Standards upon which CE marking is declared. Additionally, please use a Class Ⅰ power supply cord set which confirms to CE marking in order to...

  • Page 9: Optional Items

    ○ MC-EXC-02 (length:2m,output side unattached) (optional sales) Installation bracket － LBK-001 (Bottom type) (optional sales) ※1 Please inquire to MORITEX about cable different in length. ※2 Please inquire to MORITEX about 10m or more. ※3 ※4 ※5 Adaptor (for Japan only) <PS>E/UL/CSA...

  • Page 10: Dimensions

    Dimensions...

  • Page 11: Memo

    1. Do not dispose equipment and/or parts of the equipment as unsorted municipal waste but collect them separately. 2. Before disposal of the equipment and/or parts of it, please contact MORITEX for any return or disposal methods/systems. 3. This symbol indicates separate collection of electrical and electronic equipment. Do not dispose equipment and/or parts of the equipment as unsorted municipal waste.

  • Page 12: Appendix

    《Appendix》 ・If there are any unclear points or if you have any questions, please feel free to inquire MORITEX. For repair or after sales service, please contact any MORITEX office or the sales office where you have purchased the unit.
