COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis : KS3A(P)_50Hz(REV. 4)
Model : CW21C33WS8XXEG
CW25D83NS8XXEC
CW25D83NS8XXEU
CW28D83NS8XXEC
CW28D83NS8XXEU
CW28D85VS8XXEC
WS32V54NS8XXEC
WS32V54NS8XXEU
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS
Exploded Views and Parts List

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CW21C33WS8XXEG and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung CW21C33WS8XXEG

Summary of Contents for Samsung CW21C33WS8XXEG

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : KS3A(P)_50Hz(REV. 4) Model : CW21C33WS8XXEG CW25D83NS8XXEC CW25D83NS8XXEU CW28D83NS8XXEC CW28D83NS8XXEU CW28D85VS8XXEC WS32V54NS8XXEC WS32V54NS8XXEU COLOR TELEVISION RECEIVER CONTENTS Precautions Reference Information Specifications Alignment and Adjustments Troubleshooting Exploded Views and Parts List Electrical Parts List Block Diagrams Wiring Diagram...

  • Page 2: Precautions

    Heed the high voltage limits. These include not exceed 0.5 milliamp. Reverse the power- the X–ray Protection Specifications Label, and plug prongs in the AC outlet and repeat the the Product Safety and X-ray Warning Note on test. the service data schematic. Samsung Electronics...
  • Page 3 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheating, and correct any potential hazards. Samsung Electronics...
  • Page 4 Make sure that the portion around 8. Always connect a test instrument’s ground the serviced part has not been damaged. lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last. Samsung Electronics...
  • Page 5 4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...

  • Page 6: Reference Information

    Millimeter Hour Millisecond Inches Per Second Millivolt Kilowatt-hour Nanofarad Ω Kilogram Kilohertz Picofarad kΩ Kilohm Pound Kilometer Revolutions Per Minute km/h Kilometer Per Hour Revolutions Per Second Kilovolt Second (Time) Kilovolt-ampere Volt Kilowatt Volt-ampere Liter Watt Megahertz Watt-hour Samsung Electronics...
  • Page 7 Fail Safe Voltage Controlled Oscillator Ground VCXO Voltage Controlled Crystal Oscillator Green-Y Very High Frequency High Video Intermediate Frequency High-Frequency Variable Resistor HI-FI High Fidelity Video Tape Recorder Inductance-Capacitance VTVM Vacuum Tube Voltmeter Integrated Circuit Transistor Intermediate Frequency Samsung Electronics...
  • Page 8 IC802 D805 FML-G12S D806 Rectifier Diode HC801 D807 FMG-G2CS D802 IC201 KA78RM33 3.3V Regulator IC804 KA7806 6V Regulator IC803 KA78R08 8V Controlled Regulator IC903 KA78RM33 3.3V Regulator MICOM Reset IC IC904 KIA7025AP Q909 IIC Level Shifter 2N700 Q910 Samsung Electronics...
  • Page 9 50Hz, 2H Comb Filter, Horizontal Scaler VDP3120B 50Hz, 2H Comb Filter, DVD Input VDP3130Y Table 2-3-2 SOUND IC (IC601) REMARK SPEC FUNCTION MSP3400D Multistandard, A2 Stereo MSP3410D Multistandard, A2 Stereo, Nicam MSP3411G Multistandard, A2 Stereo, Nicam, Vitual Dolby Samsung Electronics...
  • Page 10 CS with LNA Function TCLS3101PD09A(S) Main(Old) TCPS3000P TCPS3001PD09E(S) India TCPW3001PD09A(S) CZ, CW TCL3101PD16A Main(New) Note TCPS3001PD09A(S) is out-of-date, TCPS3001PD09D(S) which is up-to-date has the same function. Table 2-3-5 2’nd TUNER (TU02S) REMARK SPEC FUNCTION TCPS3000PC09B(S) Sub(Old() TCPS3000PC16B Sub(New) Samsung Electronics...
  • Page 11 MEMO Samsung Electronics...

  • Page 12: Specifications

    2 TUNER PIP, NICAM, TTX 2 TUNER PIP, A2 STEREO, TTX “NICAM” means that A2 STEREO + NICAM 2 TUNER PIP, A2 STEREO 2 TUNER MULTI PIP, A2 STEREO, NICAM, TTX A2 STEREO, TTX 1 TUNER PIP, A2 STEREO, TTX Samsung Electronics...
  • Page 13 MEMO Samsung Electronics...

  • Page 14: Alignment And Adjustments

    2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 32 KV under any conditions. Samsung Electronics...
  • Page 15 1. Input Toshiba Pattern 2. Enter “Service Mode”.(Refer to “Service Mode”) 3. Select “G2-Adjust”. 4. Set the values as example(Refer to page4-24). ex) IBRM = 220 WDRV = 35 = 220 COLR G B = 150 150 150 Samsung Electronics...
  • Page 16 For example, when the value of “Red Cutoff” is 127, change the value to 128 and restore the value to 127. If you do not follow this procedure, the picture may be abnormal. For example, when the TV set is on, the picture becames brighter gradually. Samsung Electronics...
  • Page 17 8. Use the Channel Up/Down (L/M) buttons to move the cursor on the adjustment modes. 9. Use the Volume +/- buttons to change the adjustment value. I SMPS Controller differentiol List 1265RB 1265RD LOC. SPEC LOC. SPEC DZ808 MTZ8.28 DZ808 MTZ8.28 C811 47NF C811 47NF C828 221.50V C828 221.50V Samsung Electronics...
  • Page 18 2. Using CRT Socket PCB for Double Focus at CRT for Single Focus (1) Change the CRT Socket in PCB(Double → Single). (2) Cut the red-colored focus wire of FBT in set like picture #2. ❈ You mus tape the isolation parts for safety. Samsung Electronics...
  • Page 19 PROM (sometimes MICOM) is replaced, the adjustment values should be controlled. - After the Service adjustment is completed, Do not select “Reset” in the service mode menu. (After above procedure is done, power is on initially and the “Plug and Play” will be operated.) Samsung Electronics...
  • Page 20 Adjusts Vertical position of PIP in NTSC system. PIP NTSC V.Pos Adjusts Horizontal Position of the PIP. PIP H.Pos PIP blanking level green(PIP low light white balance). PIP BLKLG It is used to control low light white balance in PIP Samsung Electronics...
  • Page 21 0 ~ 255 Wide-Zoom Para 0 ~ 255 Wide-Zoom2 Para 0 ~ 255 Zoom1 Amp 0 ~ 255 Zoom2 Amp 0 ~ 255 TTX Position 0 ~ 255 D-TTX Posi 0 ~ 255 RGB Shift 0 ~ 255 Samsung Electronics...
  • Page 22 V Slope GEOM V SC H EW GEOM H Trapizium GEOM H Parabola GEOM H Symmetry 10/13 H Corner GEOM H Shift GEOM PIP Contrast PIP Tint PIP V.Move(VSPDEL) PIP PAL V.Pos PIP NTSC V.Pos PIP H.Pos PIP BLKLG Samsung Electronics...
  • Page 23 Alignment and Adjustments 4-8-2(B) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT) V Shift V Amp V Slope V SC H EW H Trapizium H Symmetry H Parabola H Corner 10 H Shift 4-10 Samsung Electronics...
  • Page 24 P.YC Delay External SECAM Y/C Delay S.YC Delay External NTSC Y/C Delay N.YC Delay P.M.YC Delay PAL-M Y/C DELAY N.MYC Delay NTSC-M YC DELAY Beam Control Limit Characteristic Note 4. beam 1.8mA 1.6mA BCL GAIN BCL THESHOLD WDRGB Samsung Electronics 4-11...
  • Page 25 0 ~ 8 S.L.YC Delay 0 ~ 8 P.BG.YC Delay 0 ~ 8 P.YC Delay 0 ~ 8 S.YC Delay 0 ~ 8 N.YC Delay 0 ~ 8 S.I YC Delay 0 ~ 8 0 ~ 255 TTX Contrast 4-12 Samsung Electronics...
  • Page 26 0 ~ 8 P.I YC Delay 0 ~ 8 S.BG YC Delay 0 ~ 8 S.DK YC Delay 0 ~ 8 S.I YC Delay 0 ~ 8 P.M.YC Delay 0 ~ 8 N.MYC Delay 0 ~ 8 Samsung Electronics 4-13...
  • Page 27 Electronics high tension time. According to change of Beam, EHT vertical EHT Time 0 ~255 correction time. EHT compensation coefficent vertical. EHT Vertical 0 ~255 EHT compensation Characteristic Note 5. L max L out [kv] EHT compensation L tr BTLT L min 1000 average beam current EHT_THRES 4-14 Samsung Electronics...
  • Page 28 B stretch-BAM 0 ~ 31 Coring 0 ~ 10 NR Off Value 0 ~ 20 Melody Volume 0 ~ 255 RGB Bright 0 ~ 80 RGB Contrast 0 ~ 255 EHT Time EHT Compesation 96 ~ 111 Samsung Electronics 4-15...
  • Page 29 Coring 0 ~ 10 NR Off Value 0 ~ 20 Melody Volume 0 ~ 255 RGB Bright 0 ~ 80 RGB Contrast 0 ~ 255 EHT Time EHT Compesation 96 ~ 111 0 ~ 255 EHT Vertical 4-16 Samsung Electronics...
  • Page 30 2 bit more than descrbed here) Y Input 16...235(ITUR) range=256...511 Black Level 16(constant) Contrast Dig. Brightness Slope 2 [0...15] Peaking Limiter input signal. (Yin-Black Level) . Contr/32+Brightn. (235-16) . 63/32+20=451 tilt 1 [0...511] tilt 2 [0...511] 1023 Samsung Electronics 4-17...
  • Page 31 Peak Video Gain 0 ~ 5 ACC Ref=(PAL/NTSC) 0 ~ 40 0 ~ 39 ACCR(SECAM) 0 ~ 31 Gain1(Video) 0 ~ 15 Delay1(Video) Velocity Limit 0 ~ 127 Velocity Delay 0 ~ 15 Velocity Coring 0 ~ 15 4-18 Samsung Electronics...
  • Page 32 Velocity Coring 0 ~ 255 RGB Shift 0 ~ 3 HB START 0 ~ 255 HB STOP 0 ~ 1 2H CombFilter 0 ~ 10 NR Off Value 0 ~ 255 Color hys(SECAM) 0 ~ 255 Color hys(PAL) Samsung Electronics 4-19...
  • Page 33 On :If it happened 'Sound click' Noise cause that the input signal from TV Station has been over High Deviate modulated,Set 'ON'. Off : Normal input Signal Select TTX On/Off TTX On/OFF Note 6. Sound IC & System Sound IC601 MSP3400D, MSP3410D A2/NICAM MSP3411G V-DOLBY Mono Not used this mode for KS3A Chassis L-Stereo 4-20 Samsung Electronics...
  • Page 34 Sound 2RCA+S+D 2RCA+S+D 2Scart+S 2RCA+S+D 2RCA+D 2RCA+S+D AV Mode X-Ray Tilt Control Auto FM 2-Tuner 2-Tuner 1-Tuner 1-Tuner Txt Language Arabic Farsi Arabic East Euripe West Europe Arabic Equalizer High Deviate TTX On/Off AV by CH Key Samsung Electronics 4-21...
  • Page 35 A2/Nicam V.Dolby Sound AV Mode 2RCA+S+D 2RCA+S+D 2RCA+S+D 2Scart+S 2Scart+S 2RCA+S+D X-Ray Tilt Control Auto FM 2-Tuner 2-Tuner 2T-D/W 2T-D/W 2-Tuner Txt Language West West West Russian Russian Equalizer High Deviate TTX On/Off AV by CH Key 4-22 Samsung Electronics...
  • Page 36 GreenUses the same register as the GREEN cutoff in Video adjust-1. Cutoff Level COL(B) BlueUses the same register as the BLUE cutoff in Video adjust-1. After setting COL/CDL/WDRV/IBRM to each spec of models, adjust the screen VR till the color of MRCR/MRCG/MRCB/MRWDG becomes green Samsung Electronics 4-23...
  • Page 37 0 ~ 255 0 ~ 255 COL(R) 0 ~ 255 COL(G) 0 ~ 255 COL(B) 0 ~ 255 After setting COL/CDL/WDRV/IBRM to each spec of models, adjust the screen VR till the color of MRCR/MRCG/MRCB/MRWDG becomes green 4-24 Samsung Electronics...
  • Page 38 PIP peak white level Red. Adjusts high lignt white balance of PIP. PIP PKLR PIP PKLG PIP peak white level Green. Adjusts high lignt white balance of PIP. PIP peak white level Blue. Adjusts high lignt white balance of PIP. PIP PKLB Samsung Electronics 4-25...
  • Page 39 TTX List Prior On/Off Main Newlin 40 ~ 100 Main PFGHB 146 ~ 206 PIP BLKLR 0 ~ 15 PIP BLKLB 0 ~ 15 PIP PKLR 155 ~ 255 PIP PKLG 155 ~ 255 PIP PKLB 155 ~ 255 4-26 Samsung Electronics...
  • Page 40 29" Flat DVD 29" Flat DVD India 29" 29" Flat CS29A6MT 34" Flat 29" Flat (VDP3130Y B1) (VDP3130Y B2) Flat DVD H-BOW H-ANGLE H-DSCC DVD TINT CONTROL DVD SUB TINT EHT OFFSET EHT HORIZONTAL VDPY 32 Version Samsung Electronics 4-27...
  • Page 41 OSD-B OSD-G OSD-R Scart1 Ident VDD 2.5V Scart2 Ident Key 1 X-TAL Out H-Sync X-TAL In V-Sync MICOM Reset Key 3 N.C. Key 2 N.C. X-Ray Protect VDD 3.3V IR Input Stand-By LED N.C. Time LED Relay 4-28 Samsung Electronics...
  • Page 42 Scart1 Ident SC1-ID Scart2 Ident SC2-ID Key1 Input Key1 H-Sync Horizontal Sync Input Vertical Sync Input V-Sync Key3 Key3 Input Key2 Key2 Input X-Ray Protection X-Ray IR-In Remocon Signal Input STD-LED LED Drive Output(Red) TIM-LED LED Drive Output(Green) Samsung Electronics 4-29...
  • Page 43 VDD 2.5V VDD 3.3V PX.Y When The Caption Function Adopted, Used. PX.Y N.C. Not Used (Programmed Gound Level) N.C. Sound Amp Mute S-Mute High Picture On/Off Control Power Not Used (Programmed Gound Level) N.C. Tilt Tilt Control Output 4-30 Samsung Electronics...

  • Page 44: Troubleshooting

    Troubleshooting 5. Troubleshooting 5-1 No Power Samsung Electronics...
  • Page 45 Troubleshooting 5-2 No Picture Samsung Electronics...
  • Page 46 Sound is mute) Normal Check D816, Q906 Check Abnormal IC601 #24, #25 Normal Replace IC602 Check Abnormal IC601 Input Voltages (5V,8V) Normal Check the coils around IC601 Check Abnormal IC601 Input Signal Normal Check Replace the Tuner IC601 Samsung Electronics...
  • Page 47 MEMO Samsung Electronics...
  • Page 48 1-11 AA64-02868A KNOB CONTROL;25D8,HIPS,HB,GRY 1-12 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR CF+KC 1-13 3001-001072 SPEAKER;5W,16ohm,90dB,180Hz 1-14 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR CF+SPK HA94-50008A ASSY-CRT;A59EEQ15X98,-,59cm,0.80 mm,-,I AA65-30007A CLAMPER CORE-D,COIL;-,NYLON-66,V0,-,NTR, AA60-10050Q SCREW-ASSY;-,SWRCH18A,M5,L26.5,HH,+,WC,- CRT+CF 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- V999S HA64-02346B CABINET-BACK;25D8(SEH),VL-1823,GRY 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR CB+CF AA96-01128A ASSY POWER CORD;DP,AA39-00290A,EP3, UK,H P/CORD Samsung Electronics...
  • Page 49 KNOB CONTROL;25D8,HIPS,HB,GRY 1-11 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR CF+KC 1-12 3001-001092 SPEAKER;10W,8ohm,87dB,150Hz 1-13 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR CF+SPK 1-14 HA61-00995A HOLDER-PFC;ALLMODELL,HIPS HA94-500023 ASSY-CRT;A66EHJ13X38,+450MG,28,ITC,NORM AA65-30007A CLAMPER CORE-D,COIL;-,NYLON-66,V0,-,NTR, AA60-10050Q SCREW-ASSY;-,SWRCH18A,M5,L26.5,HH,+,WC,- CRT+CF 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- V999S HA64-02313B CABINET-BACK;28D8(SEH),VL-1823,GRY 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR CB+CF AA96-01128A ASSY POWER CORD;DP,AA39-00290A,EP3, UK,H P/CORD Samsung Electronics...
  • Page 50 1-14 AA95-01752B ASSY SUB-PCB CONTROL;29M6,KS3A,AA95-0140 1-15 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR CF+PCB 1-16 3001-001005 SPEAKER;10W,8OHM,91DB,140HZ 1-17 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR CF+SPK HA94-01694A ASSY CRT;W76EGX023X215,+380MG,32,ITC,- AA65-30113A CLAMPER CORE-D,COIL;-,NYLON 66,V2,-,BLK, AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z CRT+CF 3704-000114 SOCKET-CRT;14P,29.1,35.5,SN,ISH09S/BK VA999 HA64-02529C CABINET-BACK;32M6,VL-1823,GRY 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR CB+CF AA96-01126B ASSY POWER CORD;DP,AA39-10001G,CP2,H/C40 Samsung Electronics...

  • Page 51: Electrical Parts List

    Electrical Parts List 7. Electrical Parts List 7-1 CW21C33WS8XXEG Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY PCB MAIN(OPT) AA62-30197D HEAT SINK-ES;DP,-,-,-,AA62-30181H,-,-,- 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE AA94-12410A ASSY PCB MAIN(OPT);CW2144-C3-C7W,KS3A/H, 0205-000129 GREASE-SILICON;SC102,JAPAN...
  • Page 52 AA60-40014A PIN-GT,ASSY;AUTO C805 2201-000332 C-CERAMIC,DISC;2.2nF,20%,250V,Y5U,TP,9x4 GT302 AA60-40014A PIN-GT,ASSY;AUTO C807 2301-001397 C-FILM,PPF;2.2nF,5%,1.2kV,TP,15x8.5x13.5 GT401 AA60-40014A PIN-GT,ASSY;AUTO C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3 GT402 AA60-40014A PIN-GT,ASSY;AUTO C816 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5 GT801 AA60-40014A PIN-GT,ASSY;AUTO C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT802 AA60-40014A PIN-GT,ASSY;AUTO C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT803 AA60-40014A PIN-GT,ASSY;AUTO Samsung Electronics...
  • Page 53 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J705 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J611 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J707 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J614 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J127 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J615 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J605 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics...
  • Page 54 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY853 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY442 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY854 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY443 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY855 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY444 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY856 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY445 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY857 AA60-40011A K EYELET;ID2.0,OD2.8,BST Samsung Electronics...
  • Page 55 R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R527 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 R955 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM RY801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x R426 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x R434 2003-000664 R-METAL OXIDE(S);33ohm,5%,2W,AF,TP,4x12m VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP R614 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 56 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5 HIC204 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C301 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 R302 2004-001984 R-METAL(S);26.7Kohm,1%,1/2W,AA,TP,2.4x6. C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 R409 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R410 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x R808 2001-001079 R-CARBON(S);15OHM,5%,1/2W,AA,TP,2.4X6.4M R424 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10 C248 2202-000210 C-CERAMIC,MLC-AXIAL;270pF,10%,50V,Y5P,TP Samsung Electronics...
  • Page 57 AA94-11633A ASSY CRT;,+450MG,21,ITC,A51EFS83X191,9 HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB AA03-00354A CRT COLOR;A51EFS83X191,450MG,2.0MH,23.0M HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA27-20003Z COIL DEGAUSSING;-,21,13.5ohm,25T,L2380,E AA64-40500B WINDOW-REMOCON;-,533C,-,PC,VO,VIOLET,- AA63-10002A BAND-TIE;NYLON66 V2,L100,NTR AA64-40238A INDICATOR-LED;62.7202,ACRYL,-,-,-,-,- AA98-70030A ASSY TBC WIRE(P);DP,21,AA98-70014C,1P,TV AA64-70010B BADGE-BRAND;-,AL,-,-,L50,-,SILVER,SS R20 AA65-30113A CLAMPER CORE-D,COIL;-,NYLON 66,V2,-,BLK, Samsung Electronics...
  • Page 58 ASSY POWER CORD AA96-01126A ASSY POWER CORD;DP,AA39-10001G,CP2,H/C25 AA39-10001G CBF POWER CORD;-,KKP-419C,KLCE-2F,2.286m AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 ASSY PACKING AA90-01120B ASSY PACKING;533C AA60-40006A PIN-STAPLE;33X17.8X2.4,H18,33X17.8X2.4 HA69-01491A CUSHION-SET;533C,PS,C=0.02 HA83-00058A LP-RESIN-EPS;,CHEIL SF-301V,WHT HA69-01520A PACKING CASE;533C,35BC HA68-02178A LABEL-BOX;250MM,89MM,WHITE AA69-00744C BAG-SHEET;-,HDPE PE FOAM,T0.015,W1050,H9 HA83-00046A LP-TAPE INK;,WIDTH 105 MM Samsung Electronics...
  • Page 59 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10 C909 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5 Samsung Electronics...
  • Page 60 AA60-40014A PIN-GT,ASSY;AUTO C913 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT805 AA60-40014A PIN-GT,ASSY;AUTO C915 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT806 AA60-40014A PIN-GT,ASSY;AUTO C918 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT103 AA60-40014A PIN-GT,ASSY;AUTO C210 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT409 AA60-40014A PIN-GT,ASSY;AUTO D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, GT501 AA60-40014A PIN-GT,ASSY;AUTO D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, GT502 AA60-40014A PIN-GT,ASSY;AUTO 7-10 Samsung Electronics...
  • Page 61 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L107 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J618 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J902 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J619 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D407 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J620 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) R427 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-11...
  • Page 62 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY857 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY446 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY858 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY447 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY859 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY448 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY860 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY449 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY861 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-12 Samsung Electronics...
  • Page 63 RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP R421 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP R432 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm R426 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m 0203-001123 TAPE-PAPER;#53131,T0.15,W6.0,L200000,YEL R434 2003-000664 R-METAL OXIDE(S);33ohm,5%,2W,AF,TP,4x12m Samsung Electronics 7-13...
  • Page 64 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm DZ803 0403-001167 DIODE-ZENER;MTZJ30D,30V,29.02-30.51V,500 C835 2401-002289 C-AL;470uF,20%,35V,WT,TP,10x20,5 FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS C840 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5 HIC202 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5 HIC203 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C301 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 HIC204 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 7-14 Samsung Electronics...
  • Page 65 CN05A AA39-20069C LEAD CONNECTOR-ASSY;,5P,YBNH025-05,67096 SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP AA63-10002A BAND-TIE;NYLON66 V2,L100,NTR SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RA01 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP RA02 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP CA06 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 D408 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L CA07 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 HC401 HA96-00275A ASSY-H/S;-,COMPLEX,AA62-00051A,KSD5703, Samsung Electronics 7-15...
  • Page 66 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-01309E INLAY AV;PS SHEET,29D7,T0.3,-,-,-,KS2A S AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 3001-001072 SPEAKER;5W,16ohm,90dB,180Hz AA39-00102C LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,3 holder HA83-00049A LP-ADHESIVE-HM;12MM,NTR 0203-001290 TAPE-OPP MASKING;ANT 100C,T0.073,W30,L50 ASSY-CRT HA94-50008A ASSY-CRT;A59EEQ15X98,-,59cm,0.80 mm,-,I AA03-00162A CRT COLOR;A59EEQ15X98,+450mG,1.825mH,12. 7-16 Samsung Electronics...
  • Page 67 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST C235 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T C907 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10 C909 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x C237 2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5 Samsung Electronics 7-17...
  • Page 68 AA60-40014A PIN-GT,ASSY;AUTO C913 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT805 AA60-40014A PIN-GT,ASSY;AUTO C915 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT806 AA60-40014A PIN-GT,ASSY;AUTO C918 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT103 AA60-40014A PIN-GT,ASSY;AUTO C210 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 GT409 AA60-40014A PIN-GT,ASSY;AUTO D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, GT501 AA60-40014A PIN-GT,ASSY;AUTO D202 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, GT502 AA60-40014A PIN-GT,ASSY;AUTO 7-18 Samsung Electronics...
  • Page 69 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L107 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J618 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J902 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J619 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D407 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J620 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) R427 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-19...
  • Page 70 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY857 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY446 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY858 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY447 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY859 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY448 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY860 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY449 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY861 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-20 Samsung Electronics...
  • Page 71 RY802S 2002-001013 R-COMPOSITION;4.7Mohm,5%,1/2W,AA,TP,3.7x R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP R421 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP R432 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. X901 2801-003728 CRYSTAL-UNIT;6MHz,30ppm,28-AAM,20pF,40oh R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM L103 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm R426 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m 0203-001123 TAPE-PAPER;#53131,T0.15,W6.0,L200000,YEL R434 2003-000664 R-METAL OXIDE(S);33ohm,5%,2W,AF,TP,4x12m Samsung Electronics 7-21...
  • Page 72 C840 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5 FA802S 3601-001086 FUSE-AXIAL LEAD;125V,5A,FAST-ACTING,GLAS C827 2401-002212 C-AL;10uF,20%,25V,WT,TP,5x11,5 HIC202 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C301 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 HIC203 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP C106 2401-000611 C-AL;1uF,20%,50V,WT,TP,5x11,5 HIC204 AA13-00093A IC HYBRID;-,DRGB001A,SIP,5P,-,TP DZ602 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 R302 2004-001984 R-METAL(S);26.7Kohm,1%,1/2W,AA,TP,2.4x6. R808 2001-001079 R-CARBON(S);15OHM,5%,1/2W,AA,TP,2.4X6.4M 7-22 Samsung Electronics...
  • Page 73 SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP JP02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP AA41-00403A PCB-PFC;CS2939,CEM-1,1L,A,1.6T,245x245,K SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP CNP02 AA39-00236A LEAD CONNECTOR-ASSY;,3(2)P,YHL500-03A BL SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP PFT01 AA27-00116A COIL CHOKE;CODE_NO,-,35mH,-0, +5%,-,2.8O D408 0402-000493 DIODE-RECTIFIER;1R5GU41,400V,1.5A,DO-15L HA61-00995A HOLDER-PFC;ALLMODELL,HIPS HC401 HA96-00275A ASSY-H/S;-,COMPLEX,AA62-00051A,KSD5703, Samsung Electronics 7-23...
  • Page 74 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-02316A KNOB-POWER;28D8(SEH),HIPS,HB,GRY HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-01309E INLAY AV;PS SHEET,29D7,T0.3,-,-,-,KS2A S AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 3001-001072 SPEAKER;5W,16ohm,90dB,180Hz 7-24 Samsung Electronics...
  • Page 75 HA96-50371C ASSY H/S;-,-,AA62-30181H,KA3A1265R,- C220 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA13-00101A IC HYBRID;KA3S1265RD,CN5039,5PIN,-50TO12 C221 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA61-10386A BRACKET-IC;-,SECC 100,T1.0,-,-,-,KA2S068 C222 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA62-30197D HEAT SINK-ES;DP,-,-,-,AA62-30181H,-,-,- C223 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW C901 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE C921 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 0205-000129 GREASE-SILICON;SC102,JAPAN C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP Samsung Electronics 7-25...
  • Page 76 AA60-40014A PIN-GT,ASSY;AUTO C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3 GT301 AA60-40014A PIN-GT,ASSY;AUTO C816 2401-000293 C-AL;100uF,+30-10%,200V,GP,TP,16x25 GT302 AA60-40014A PIN-GT,ASSY;AUTO C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT401 AA60-40014A PIN-GT,ASSY;AUTO C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT402 AA60-40014A PIN-GT,ASSY;AUTO C822 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT801 AA60-40014A PIN-GT,ASSY;AUTO C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5 GT802 AA60-40014A PIN-GT,ASSY;AUTO 7-26 Samsung Electronics...
  • Page 77 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J944 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J606 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J705 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J607 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J707 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J611 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J127 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-27...
  • Page 78 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY849 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY438 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY850 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY439 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY851 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY440 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY852 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY441 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY853 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-28 Samsung Electronics...
  • Page 79 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R228 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M J920 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R301 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4 J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R423 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4 R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R303 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM R955 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R828 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm RR430S 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M R522 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm Samsung Electronics 7-29...
  • Page 80 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,- C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,- CN602 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH R945 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M CW901 2503-000156 C-NETWORK;100pFx4,20%,50V R946 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M D203 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP C104 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 D204 0404-000156 DIODE-SCHOTTKY;RB441Q,10V,100mA,DO-34,TP C512 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 7-30 Samsung Electronics...
  • Page 81 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- R944 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M 3001-001092 SPEAKER;10W,8ohm,87dB,150Hz R916 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2M AA39-00102C LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,3 L910 2701-000215 INDUCTOR-AXIAL;8.2uH,10%,2.5x3.4mm holder HA83-00049A LP-ADHESIVE-HM;12MM,NTR C926 2202-000154 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP 0203-001290 TAPE-OPP MASKING;ANT 100C,T0.073,W30,L50 C904 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP Samsung Electronics 7-31...
  • Page 82 3722-001031 JACK-PIN;3P,3.6mm,#18,AU CN06A AA39-00070A LEAD CONNECTOR-ASSY;,4P,YBNH250-04,35184 CN01A AA39-20068E LEAD CONNECTOR-ASSY;,8P,YBNH025-08,67096 CN05A AA39-20069C LEAD CONNECTOR-ASSY;,5P,YBNH025-05,67096 AA63-10002A BAND-TIE;NYLON66 V2,L100,NTR RA01 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 RA02 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 CA06 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 CA07 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 JA101 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) AA41-11017D PCB-A/V SIDE;CT-29U1,FR-1,1L,D,1.6T,245X 7-32 Samsung Electronics...
  • Page 83 HA96-50371C ASSY H/S;-,-,AA62-30181H,KA3A1265R,- C220 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA13-00101A IC HYBRID;KA3S1265RD,CN5039,5PIN,-50TO12 C221 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA61-10386A BRACKET-IC;-,SECC 100,T1.0,-,-,-,KA2S068 C222 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP AA62-30197D HEAT SINK-ES;DP,-,-,-,AA62-30181H,-,-,- C223 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW C901 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE C921 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 0205-000129 GREASE-SILICON;SC102,JAPAN C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP Samsung Electronics 7-33...
  • Page 84 AA60-40014A PIN-GT,ASSY;AUTO C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3 GT301 AA60-40014A PIN-GT,ASSY;AUTO C816 2401-000293 C-AL;100uF,+30-10%,200V,GP,TP,16x25 GT302 AA60-40014A PIN-GT,ASSY;AUTO C817 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT401 AA60-40014A PIN-GT,ASSY;AUTO C819 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT402 AA60-40014A PIN-GT,ASSY;AUTO C822 2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5. GT801 AA60-40014A PIN-GT,ASSY;AUTO C818 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5 GT802 AA60-40014A PIN-GT,ASSY;AUTO 7-34 Samsung Electronics...
  • Page 85 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J944 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J606 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J705 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J607 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J707 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J611 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J127 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-35...
  • Page 86 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY849 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY438 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY850 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY439 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY851 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY440 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY852 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY441 AA60-40011A K EYELET;ID2.0,OD2.8,BST EY853 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-36 Samsung Electronics...
  • Page 87 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R708 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM D507 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R723 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R902 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R816 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R228 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4M J920 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R301 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4 J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R423 2004-001397 R-METAL(S);4.7Kohm,1%,1/2W,AA,TP,2.4x6.4 Samsung Electronics 7-37...
  • Page 88 2401-002267 C-AL;2.2uF,20%,250V,GP,TP,8x11.5,5 L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm C507 2401-002267 C-AL;2.2uF,20%,250V,GP,TP,8x11.5,5 L210 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm C833 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 L801 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,- C229 2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5 L806 3301-001223 CORE-FERRITE BEAD;AA,62ohm,3.5x0.8x5mm,- CN602 3711-002644 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGH R945 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM CW901 2503-000156 C-NETWORK;100pFx4,20%,50V R946 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-38 Samsung Electronics...
  • Page 89 L910 2701-000215 INDUCTOR-AXIAL;8.2uH,10%,2.5x3.4mm JP02 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C926 2202-000154 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP AA41-00403A PCB-PFC;CS2939,CEM-1,1L,A,1.6T,245x245,K C904 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 CNP02 AA39-00236A LEAD CONNECTOR-ASSY;,3(2)P,YHL500-03A BL R917 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM PFT01 AA27-00116A COIL CHOKE;CODE_NO,-,35mH,-0, +5%,-,2.8O R918 2001-000009 R-CARBON;20KOHM,5%,1/8W,AA,TP,1.8X3.2MM HA61-00995A HOLDER-PFC;ALLMODELL,HIPS SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP Samsung Electronics 7-39...
  • Page 90 AA64-02316A KNOB-POWER;28D8(SEH),HIPS,HB,GRY HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-01309E INLAY AV;PS SHEET,29D7,T0.3,-,-,-,KS2A S AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 3001-001092 SPEAKER;10W,8ohm,87dB,150Hz AA39-00102C LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,3 holder HA83-00049A LP-ADHESIVE-HM;12MM,NTR 7-40 Samsung Electronics...
  • Page 91 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C642 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP C630 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C644 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP C631 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C638 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP C645 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C639 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP C652 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C249 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP C603 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm C632 2202-000806 C-CERAMIC,MLC-AXIAL;220pF,10%,50V,Y5P,TP C207 2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm Samsung Electronics 7-41...
  • Page 92 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) DZ204 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO J603 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) DZ205 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO J604 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) DZ805 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL J606 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) GT101 AA60-40014A PIN-GT,ASSY;AUTO J607 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-42 Samsung Electronics...
  • Page 93 AA60-40011A K EYELET;ID2.0,OD2.8,BST J943 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) EY439 AA60-40011A K EYELET;ID2.0,OD2.8,BST J944 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) EY440 AA60-40011A K EYELET;ID2.0,OD2.8,BST J705 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) EY441 AA60-40011A K EYELET;ID2.0,OD2.8,BST J707 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) EY442 AA60-40011A K EYELET;ID2.0,OD2.8,BST Samsung Electronics 7-43...
  • Page 94 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM EY850 AA60-40011A K EYELET;ID2.0,OD2.8,BST R907 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM EY851 AA60-40011A K EYELET;ID2.0,OD2.8,BST J904 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM EY852 AA60-40011A K EYELET;ID2.0,OD2.8,BST R925 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM EY853 AA60-40011A K EYELET;ID2.0,OD2.8,BST J920 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM EY854 AA60-40011A K EYELET;ID2.0,OD2.8,BST R955 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-44 Samsung Electronics...
  • Page 95 R411 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2.4X6.4 R413 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10 R412 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M R424 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10 R422 2001-000020 R-CARBON(S);22OHM,5%,1/2W,AA,TP,2.4X6.4M R304 2008-001018 R-FUSIBLE(S);0.47ohm,10%,2W,AF,TP,3.9x10 R421 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. R827 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M R415 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6. R829 2008-001029 R-FUSIBLE(S);5.6ohm,5%,2W,AF,TP,3.9x10mm R913 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M R835 2003-002181 R-METAL OXIDE(S);68Kohm,5%,2W,AG,TP,3.9x Samsung Electronics 7-45...
  • Page 96 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,- C425 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5 0204-000442 SOLVENT;1M-1000,C3H70H,96,- C622 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 T801S AA26-00046B TRANS SWITCHING;CODE-NO,CW6844N8X/XEF,-, C625 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 IC804 HA96-00243C ASSY-H/S;-,REGULATOR,AA62-00045A,KA7806 C626 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 1203-000284 IC-POSI.FIXED REG.;7806,TO-220,3P,-,PLAS C628 2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW C104 2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, 7-46 Samsung Electronics...
  • Page 97 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C523 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 C516 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 D502 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 D507 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 D508 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 D509 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 D510 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 Samsung Electronics 7-47...
  • Page 98 R543 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB R544 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY R546 2001-000832 R-CARBON;510OHM,5%,1/8W,AA,TP,1.8X3.2MM HA98-600020 ASSY-SUB,PART;KS4A,PFC PCB L501 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm 0202-001222 SOLDER-WIRE FLUX;RS-107,RS60-1.2AA,D1.2, R521 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb R504 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,- 7-48 Samsung Electronics...
  • Page 99 HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-01309E INLAY AV;PS SHEET,29D7,T0.3,-,-,-,KS2A S AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 3001-001092 SPEAKER;10W,8ohm,87dB,150Hz AA39-00102C LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,3 holder HA83-00049A LP-ADHESIVE-HM;12MM,NTR 0203-001290 TAPE-OPP MASKING;ANT 100C,T0.073,W30,L50 Samsung Electronics 7-49...
  • Page 100 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 C919 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST C924 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T C232 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP C815 2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,10 C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 7-50 Samsung Electronics...
  • Page 101 J108 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C915 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J110 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C918 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J111 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C210 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J112 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, J113 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-51...
  • Page 102 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J804 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J632 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J211 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J703 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J241 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J704 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L410 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-52 Samsung Electronics...
  • Page 103 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL805 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY604 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL806 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY701 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL807 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY702 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL808 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY703 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL809 AA60-40011B K EYELET;ID2.2,OD3.2,BSP Samsung Electronics 7-53...
  • Page 104 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L108 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L109 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L222 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-54 Samsung Electronics...
  • Page 105 R718 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM R436 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x R105 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM R607 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF, R608 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF CN903 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC C409 2301-001268 C-FILM,PPF;33nF,5%,630V,TP,20x11x17,7.5 AA41-00168H PCB-MAIN;CS29A6,FR-1,1L,H,1.6T,330X245,K CN502 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH Samsung Electronics 7-55...
  • Page 106 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, SCR10 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb H/S10 AA62-30013A HEAT SINK-ES;-,A6063 EXTR,-,-,45(21) T02 0204-001024 FLUX;DF-98TVS,-,20%,- IC501 HA96-50151A ASSY-H/S;-,TR,AA61-10060A,TDA6101Q,- 0204-000442 SOLVENT;1M-1000,C3H70H,96,- IC502 HA96-50151A ASSY-H/S;-,TR,AA61-10060A,TDA6101Q,- IC503 HA96-50151A ASSY-H/S;-,TR,AA61-10060A,TDA6101Q,- 1201-000539 IC-VIDEO AMP;6101,ZIP,9P,-,SINGLE,-,PLAS 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 6021-000154 NUT-HEXAGON;2C,M3,ZPC(YEL),SM20C BRC501 AA61-10060A BRACKET-TR;W3220,CUS-1 1/2H,T0.5,-,-,-,- 7-56 Samsung Electronics...
  • Page 107 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM R525 2003-001043 R-METAL OXIDE(S);510ohm,5%,1W,AF,TP,2.5x RF11 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM R518 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x R521 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- R526 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- RF08 2001-000313 R-CARBON;11KOHM,5%,1/8W,AA,TP,1.8X3.2MM LF04 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- Samsung Electronics 7-57...
  • Page 108 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 AA41-00345A PCB-SIDE A/V;CS29K1,FR-1,1L,A,1.6T,245x2 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-03001A DECORATION-POWER;28/32V5,HIPS,HB HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY CF+SPK 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR 3001-001005 SPEAKER;10W,8OHM,91DB,140HZ 7-58 Samsung Electronics...
  • Page 109 HA69-01702A PACKING CASE;32V5,D-4 AB,A1,985,665,670, HA83-00057B LP-TAPE-CELLULOSE;,HA02-030010,T0,046,W7 ASSY ACCESSORY AA94-05820A ASSY ACCESSORY;50HZ,KS3A,XEC 4301-000120 BATTERY-MN;1.5V,-,AA,14.5x50mm,- HA83-00047A LP-TAPEACETATE;T0.1MM,W20MM,L200MM HA69-00276A BAG VINYL;HDPE,T0.025,L400,W240,-,W/O LO HA68-00335A LABEL CAUTION;A/P100(G),S51A,HUN,POL,-,- REMOCON AA59-00104K REMOCON;-,TM59,DREAM,29,L/GRAY,PAL-TTX,E ASSY POWER CORD AA96-01126B ASSY POWER CORD;DP,AA39-10001G,CP2,H/C40 AA39-10001G CBF POWER CORD;-,KKP-419C,KLCE-2F,2.286m AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 Samsung Electronics 7-59...
  • Page 110 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK C922 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP Q402 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 C919 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP PC801S 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST C924 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T C232 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP C815 2401-003602 C-AL;220uF,20%,160V,GP,BK,22x25mm,1 C233 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm CY802S 2201-002002 C-CERAMIC,DISC;4.7nF,20%,400V,Y5U,TP,16x C234 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm 7-60 Samsung Electronics...
  • Page 111 J108 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C915 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J110 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C918 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J111 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) C210 2401-000287 C-AL;100uF,20%,16V,WT,TP,6.3x11,5 J112 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, J113 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics 7-61...
  • Page 112 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J804 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J632 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J211 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J703 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J241 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) J704 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) L410 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-62 Samsung Electronics...
  • Page 113 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL805 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY604 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL806 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY701 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL807 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY702 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL808 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EY703 AA60-40011A K EYELET;ID2.0,OD2.8,BST EL809 AA60-40011B K EYELET;ID2.2,OD3.2,BSP Samsung Electronics 7-63...
  • Page 114 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM L907 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM L711 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R701 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L108 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R702 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L109 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm R703 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm R704 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM L222 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-64 Samsung Electronics...
  • Page 115 R718 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM R436 2003-002008 R-METAL OXIDE(S);18Kohm,5%,2W,AF,TP,3.9x R105 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM R607 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM X201 2801-003432 CRYSTAL-UNIT;20.25MHZ,30PPM,28-AAM,13PF, R608 2001-000007 R-CARBON;3KOHM,5%,1/8W,AA,TP,1.8X3.2MM X601 2801-003903 CRYSTAL-UNIT;18.432MHz,25ppm,28-AAM,12pF CN903 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH IC904 1203-001943 IC-VOL. DETECTOR;7025,TO-92,3P,-,PLASTIC C409 2301-001268 C-FILM,PPF;33nF,5%,630V,TP,20x11x17,7.5 AA41-00168H PCB-MAIN;CS29A6,FR-1,1L,H,1.6T,330X245,K CN502 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH Samsung Electronics 7-65...
  • Page 116 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb GT503 AA60-40014A PIN-GT,ASSY;AUTO 0202-001046 SOLDER-WIRE FLUX;CF-110VH-2A,-,-,-,- GT504 AA60-40014A PIN-GT,ASSY;AUTO 0204-000442 SOLVENT;1M-1000,C3H70H,96,- GT505 AA60-40014A PIN-GT,ASSY;AUTO EL81 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EL82 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EL83 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EL84 AA60-40011B K EYELET;ID2.2,OD3.2,BSP EL85 AA60-40011B K EYELET;ID2.2,OD3.2,BSP 7-66 Samsung Electronics...
  • Page 117 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM SG503 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M SG504 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm R520 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM SG505 AA27-00084A COIL;S-23,-,-,-,-,-,-,S-23,5000Mohm RF06 2001-000989 R-CARBON;820KOHM,5%,1/8W,AA,TP,1.8X3.2M R501 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM R517 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 R506 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM RF14 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,TP,2.4X6.4 R511 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-67...
  • Page 118 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY EYP12 AA60-40011A K EYELET;ID2.0,OD2.8,BST CF+SPK 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR EYP13 AA60-40011A K EYELET;ID2.0,OD2.8,BST 3001-001005 SPEAKER;10W,8OHM,91DB,140HZ EYP14 AA60-40011A K EYELET;ID2.0,OD2.8,BST AA39-00102A LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,9 EYP15 AA60-40011A K EYELET;ID2.0,OD2.8,BST 0203-001290 TAPE-OPP MASKING;ANT 100C,T0.073,W30,L50 EYP16 AA60-40011A K EYELET;ID2.0,OD2.8,BST EYP17 AA60-40011A K EYELET;ID2.0,OD2.8,BST 7-68 Samsung Electronics...
  • Page 119 HA69-01646A CUSHION-SET;32V5,PS FOAMED,C=0.02 HA83-00058A LP-RESIN-EPS;,CHEIL SF-301V,WHT AA69-00744F BAG-SHEET;-,HDPE PE FOAM,T0.015,W1400,H1 HA68-02178A LABEL-BOX;250MM,89MM,WHITE HA83-00046A LP-TAPE INK;,WIDTH 105 MM HA69-01702A PACKING CASE;32V5,D-4 AB,A1,985,665,670, HA83-00057B LP-TAPE-CELLULOSE;,HA02-030010,T0,046,W7 ASSY POWER CORD AA96-01128B ASSY POWER CORD;DP,AA39-00290A,EP3, UK,H AA39-00290A CBF POWER CORD;UK,H03WH2-F,AC250V,10A,2. AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 HA61-01063A CAP-CORD;PP,1MM,40MM,30MM,RED Samsung Electronics 7-69...
  • Page 120 MEMO 7-70 Samsung Electronics...

  • Page 121: Block Diagrams

    Block Diagrams 8. Block Diagrams 8-1 Power Diagram Samsung Electronics...
  • Page 122 Block Diagrams 8-2 Block Diagram Samsung Electronics...

  • Page 123: Wiring Diagram

    ABL +16V GND HEAT 200V DOUBLE FOCUS 600V SC-I GND SY-I GND SC-O GND SY-O CN704 16.5VAC GND DOUBLE 16.5VAC GND DOUBLE CN501A B OUT G OUT R OUT CRT PCB SENSE TILT -16V ABL +16V GND HEAT 200V CN502A Samsung Electronics...
  • Page 124 MEMO Samsung Electronics...

  • Page 125: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 MAIN 1 TP07 TP01 TP10 TP08 TP02 TP09 TP03 TP09 TP01 TP06 TP10 TP04 TP05 TP03 TP08 TP05 TP02 TP04 TP06 TP07 Samsung Electronics 10-1...
  • Page 126 Schematic Diagrams 10-2 MAIN 2 TP11 TP12 TP13 TP12 TP13 TP14 TP11 TP25 TP15 TP14 TP25 TP15 10-2 Samsung Electronics...
  • Page 127 Schematic Diagrams 10-3 MAIN3 TP22 TP16 TP23 TP23 TP17 TP24 TP18 TP17 TP16 TP18 TP22 TP19 TP21 TP20 TP24 TP19 TP20 TP21 Samsung Electronics 10-3...
  • Page 128 Schematic Diagrams 10-4 MAIN 4 TP31 TP26 TP32 TP27 TP26 TP28 TP27 TP29 TP32 TP31 TP30 TP28 TP29 TP30 10-4 Samsung Electronics...
  • Page 129 Schematic Diagrams 10-5 PIP MODULE, SWITCH MODULE PIP MODULE SWITCH MODULE Samsung Electronics 10-5...
  • Page 130 Schematic Diagrams 10-6 CRT wtih out V/M wtih in V/M TP33 TP34 TP35 TP33 TP34 TP35 10-6 Samsung Electronics...
  • Page 131 Schematic Diagrams 10-7 SIDE AV, DOUBLE FOCUS SIDE AV DOUBLE FOCUS Samsung Electronics 10-7...
  • Page 132 ELECTRONICS © Samsung Electronics Co., Ltd. Aug 2002 Printed in Korea 3KS3A-SEH-0819...
