1
Connect the RV50 cable to the AGI 4 via the
adapter cable and black connector on the back of
the receiver
2
Navigate to the Wrench icon, then System, then Correction level
3
Select Cellular Network; checkmark "Use external radio"; then select the checkmark on the right
4
Set the Correction type to
"RTCM3.X"; Serial Port to "D"; Baud
Rate to match the Beacon; Parity to
"None"; & NMEA Rate to 10
seconds
MD5007
Quick Reference Card
AGCO C1000 Display Setup
rev 6
DigiFarm
AGCO C1000 & RV50
DigiFarm Technical Support
319.531.7574
support@digifarm.com
Advertisement
Table of Contents
Related Manuals for DigiFarm AGCO C1000
Summary of Contents for DigiFarm AGCO C1000
- Page 1 DigiFarm Quick Reference Card AGCO C1000 & RV50 AGCO C1000 Display Setup Connect the RV50 cable to the AGI 4 via the adapter cable and black connector on the back of the receiver Navigate to the Wrench icon, then System, then Correction level Select Cellular Network;...
- Page 2 DigiFarm Quick Reference Card AGCO C1000 & RV50 *Note- If this unit was ordered with a subscription, it will be preprogrammed and plug and play ready. The following instructions will not be needed. Log into the device via WAN static IP (166.XXX.XXX.XXX:8080) or LAN connection (192.168.1.1:8080) on Port 8080.
