DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.whirlpool.eu/register
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
6
8
9
10
12
Service:
0000 000 00000
13
CONTROL PANEL
1. On-Off/Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
1
2
3
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
http://docs.whirlpool.eu and following the Instructions
on the back of this booklet.
1
1.Upper rack
2. Foldable flaps
3.Upper rack height adjuster
2
4.Upper spray arm
5.Lower rackSpace Zone
6.Lower spray arm
7.Space Zone
3
8.Cutlery basket
9.Filter Assembly
4
10.Salt reservoir
11.Detergent and Rinse Aid dispensers
5
12.Rating plate
13.Control panel
7
11
4
5
6 7
8
9
1011
12
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
12. Power Clean button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
13
14
EN
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WUC 3C24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Whirlpool WUC 3C24

Summary of Contents for Whirlpool WUC 3C24

  • Page 1 DAILY REFERENCE GUIDE THANK YOU FOR BUYING A WHIRLPOOL PRODUCT. You can download the Safety Instructions and the Use In order to receive a more complete assistance, please and Care Guide, by visiting our website register your appliance on: http://docs.whirlpool.eu and following the Instructions www.whirlpool.eu/register...

  • Page 2: First Time Use

    FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER After installation, remove the stoppers from the racks and the retaining Rinse aid makes dish DRYING easier. The rinse aid dispenser A should elastic elements from the upper rack.

  • Page 3: Programs Table

    PROGRAMS TABLE Detergent Duration of Water Energy container Program Available options wash program consumption consumption (h:min) (litres/cycle) (kWh/cycle) 1. Eco 50° 3:10 0,93 2. 6 50-60° 1:25 - 3:00 7,0 - 14,0 0,9 - 1,40 Sense 3. Intensive 65° 2:50 14,0 1,50 4.
  • Page 4 OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding DELAY button . The start of the program may be delayed for a period of time between 0:30 and 24 hours. If an option is not compatible with the selected program , the 1.Select the program and any desired options.

  • Page 5: Daily Use

    DAILY USE 1. CHECK WATER CONNECTION MODIFYING A RUNNING PROGRAM Check that the dishwasher is connected to the water supply and If a wrong program was selected, it is possible to change it, provided that the top is open. that it has only just begun: press and hold the ON/OFF button, the 2.

  • Page 6: Loading The Racks

    LOADING THE RACKS UPPER RACK LOWER RACK For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should Load delicate and light dishes: glasses, cups, saucers, low salad bowls. ideally be placed at the sides to avoid interferences with the spray arm. (loading example for the lower rack) The lower rack has tip-up supports which can be used in a vertical po- (loading example for the upper rack)

  • Page 7: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water.

  • Page 8: Troubleshooting

    • After-Sales Service; phone number see in warranty booklet. inside the door of the dishwasher. The • download from website: http://docs.whirlpool.eu phone number is listed in the warranty • use QR code...
