DL1000 Standalone Digital Lock Product Manual Installation Instructions • Program Instructions • Read and follow all U.L. and Safety Standards before installing any access device. Please refer to this manual and qualified personnel for assistance. DO NOT install this device unless all entrapment and pinch points are eliminated. Revision 2.3...
DL1000 Product Manual Contents Important Safety Information Operating Instructions Important User Instructions ......... 3 Using Entry Codes ..........12 Restrictions & Warnings ........3 Entry Codes With Time Schedules ...... 12 Entry Codes With Sleep Mode ......12 Installation System Status & Clock ........12 Do Not Disturb (DND) Feature ......
DL1000 Product Manual Safety Information Installation Important User Information: Mounting The System: Automatic gate systems provide user convenience and limit The system can be mounted on a standard pedestal or vehicular traffic. Because these systems can produce high levels directly to a wall or flat surface. A 1/2” knockout is located of force, it is important that you are aware of the potential on the back of the box for conduit connections.
DL1000 Product Manual Installation Installation Powering The System: Gate Operator Wire Connection: Always use a good solid power source. To properly power the The system may be connected to an electric gate operator for gate system: access control. When connecting to an electric gate operator, always follow the safety guidelines and precautions supplied with Provide power from a dedicated power source for best results the gate operator.
DL1000 Product Manual Installation Event Input Wire Connections: Caution: The Event Input allows an external device such as a loop detector to control select entry codes when the external device is active. • Gate controls must be placed far enough from the gate to prevent the An entry code set to use the Event Input must route through this user from coming in contact with the gate while operating the controls.
DL1000 Product Manual Programming Programming System Status: Time Clock Programming: The current system status may be viewed at any time. The The DL1000 has a built-in 7-Day Plus time clock for time control of system status displays the current status of Relay 1, Relay 2, Do individual codes and relay open schedules.
DL1000 Product Manual Programming Programming Add Single Customized Code: Add Single Customized Code (Cont): When adding a new entry code, press # for each setting to accept h h m m s s # the system defaults. Codes may be 4-6 digits. To customize an 21.
DL1000 Product Manual Programming Programming Deleting Single Entry Codes: Add Customized Block Codes: To delete a single entry code: When adding a block of entry code, press # for each setting to accept the system defaults. Codes may be 4-6 digits. To customize an entry code settings, program each step as needed.
DL1000 Product Manual Programming Programming Add Customized Block Codes (Cont): Auxiliary Input Programming: This programming will set the Relay Functions, Event Control, and m m d d y y # Do Not Disturb (DND) control of the Auxiliary Inputs. All external 20.
DL1000 Product Manual Programming Programming Relay Activation Time Programming: Strikes Lockout Programming: The Relay Activation Time sets the amount of time each relay will Strikes Lockout helps prevent unauthorized users from using be activated when an entry code is entered. The Relay Timeout multiple codes to access the system.
DL1000 Product Manual Programming Programming Relay Time Schedule Programming: Relay Time Schedule Programming (Cont): Relay Time Schedules may be used to control the gate or door h h m m s s # without the use of an entry code during certain times of the day. 21.
DL1000 Product Manual Operating Instructions Operating Instructions Using Entry Codes: Do Not Disturb (DND) Feature: To use a programmed entry code: The Do Not Disturb (DND) mode puts the system into a sleep mode and does not allow entry code or relay activation while DND is On (active).
DL1000 Product Manual Troubleshooting YMPTOM OSSIBLE OLUTION System does not appear to have power Check to make sure the power supply/transformer is plugged in. Check the connections to the power supply for clean tight connections. Check the connections to the system PCB for clean tight connections. Test the power level using a VOM meter at the power supply.
You MUST read, understand and agree with ALL items in this limited warranty! Access One Technologies warrants this product to be free of defects in workmanship and materials for a period of (1) one year from the date of purchase. Access One Technologies reserves the right of final determination to the cause of any defect or failure. Access One Technologies shall, at its option, either repair or replace this product if returned freight prepaid to Access One Technologies during the warranty period.
