Page 1: Parts List
PART # 624212 NORCOLD 04/26/2007 PARTS LIST DC39 & DC73 SERIES (L5) VOLVO MODELS DC3984 DC7341... - Page 2 FRONT VIEW - DOOR AND CABINET PARTS - DC3984/DC7341 (VOLVO MODEL) PART # DESCRIPTION 323010900 FRAME-CABINET/COVER/UPPER 160945200 HINGE ASSY-UPPER 323011000 FRAME-CABINET/COVER/RH 160119300 DOOR ASSEMBLY-GRAY 160119310 DOOR ASSEMBLY-TAN 414803610 DOOR GASKET-FRESH FOOD DOOR 322065900 PLATE-DOOR LATCH 422511700 DOOR POCKET-DOOR SHELF BIN 160945300 HINGE ASSY-LOWER 323011600...
- Page 3 FRONT VIEW - INNER CABINET PARTS - DC3984/DC7341 (VOLVO MODEL) PART # DESCRIPTION 422603000 FRAME-EVAPORATOR 160119210 THERMOSTAT 545088300 MARK-EVAPORATOR FRAME 160206700 KNOB-THERMOSTAT/61729422 160203000 ICE CUBE TRAY 433004600 DRAINAGE PAN ASSY 523004300 SHELF 160946100 EVAPORATOR DOOR ASSY 160904800 HINGE-EVAPORATOR DOOR 322397410 SUPPORT-RAIL/CABINET/RH 360907100 SPACER-BOTTOM SUPPORT RAIL...
- Page 4 PART # DESCRIPTION 161013300 COOLING UNIT 605505450 THERMISTER-EVAPORATOR 422305000 HOLDER-THERMISTER/AT EVAPORATOR 439014800 HEAT INSULATOR 160928900 FAN ONLY-50 CYCLE/40 WATT (3 PER REFRIGERATOR) 163011000 POWER SUPPLY-DC/NO COUPLER ASSY 190279810 COUPLER ASSY-DC INPUT DC7341 PARTS LIST - PAGE 4 DC39 SERIES DC73 SERIES...
