PARTS LIST

M
DC254A
DC254A PARTS LIST
NORCOLD 10/30/2002

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC-254A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Norcold DC-254A

Summary of Contents for Norcold DC-254A

  • Page 1: Parts List

    PARTS LIST DC254A DC254A PARTS LIST NORCOLD 10/30/2002...
  • Page 2 CABINET ASSEMBLY - DC254A DC254A PARTS LIST - PAGE 2...
  • Page 3 CABINET ASSEMBLY - DC254A PART # DESCRIPTION 304300220 BLIND PLATE 439003700 HEAT INSULATOR-AT BLIND PLATE 430301900 PLATE-"I"/CABINET 416004200 BUSHING-FOR BLIND PLATE 80830441210 SCREW-TRUSS TAPPING/M4x12 645100510 FASTENER-PLASTIC RIVET 80500401040 SCREW-M4x10 83400400010 WASHER-TEETH LOCK 160201440 TRAVEL PIN ASSY (USE 160207600) 160207600 TRAVEL PIN ASSY-0.75" 160207610 TRAVEL PIN ASSY-WHITE 322118720...
  • Page 4 THERMOSTAT & POWER SUPPLY - DC254A PART # DESCRIPTION 603200921 THERMOSTAT (USE 603200910) 603200910 THERMOSTAT 603604000 CIRCUIT BREAKER 191214900 CORD ASSY (THERMOSTAT TO POWER SUPPLY) 191212910 CORD ASSY (CIRCUIT BREAKER TO POWER SUPPLY) 422501700 COVER-THERMOSTAT 545020730 MARK-THERMOSTAT HOLDER 160203200 KNOB-THERMOSTAT/BLACK 16011395008 KIT-POWER SUPPLY 160102990...
  • Page 5 COOLING UNIT AREA - DC254A PART # DESCRIPTION 161005010 COOLING UNIT 403001700 WASHER-"I" 80800441620 SCREW-TAPPING/M4x16 320200001 HOLDER-THERMOSTAT BULB 8080043082 SCREW-TAPPING 500800400 SCREW-TAPPING 322132800 HOLDER-CONDENSER 322005310 HOLDER-CONDENSER WASHER 8320042003 WASHER-SPRING LOCK 8080043163 SCREW-TAPPING 80830431210 SCREW-TAPPING/M4x12 422000700 COLLAR-"I"/AT EVAPORATOR 8073044121 SCREW-TAPPING/WITH TEETH LOCK WASHER 192116604 CORD WITH TERMINAL-GROUND CORD 80840430810...
  • Page 6 DOOR ASSEMBLY - DC254A PART # DESCRIPTION 160017600 DOOR ASSY-BLACK (USE 160031620) 160017640 DOOR ASSY-WHITE (USE 160031620) 302308310 DOOR PANEL-BLACK 302303260 DOOR PANEL-WHITE 160907510 DOOR FRAME ASSY-BLACK/3 SIDES (USE 160031620) 160907530 DOOR FRAME ASSY-WHITE/3 SIDES (USE 160031620) 404004700 HINGE BUSHING-POINTED 439003610 CUSHION-DOOR SHELF 433100510...
