When all lights flash and the wash cycle stops on a Hotpoint FDL 9640, it indicates a problem has occurred. This may be due to selecting a function that is incompatible with the wash cycle. The machine may still function during rinse and spin if those parts of the cycle are unaffected. Try switching off the machine, unplugging it for about 1 minute, then restarting it. If the issue continues, refer to troubleshooting steps.

This answer is automatically generated

Summary of Contents for Hotpoint FDL 9640

Page 1: Table Of Contents
Cleaning the pump Checking the water inlet hose Precautions and tips, 7 General safety Disposal Description of the washer-dryer and FDL 9640 starting a wash cycle, 8-9 Control panel Indicator lights Starting a wash cycle Wash cycles, 10 Table of wash cycles...
Page 2: Installation
Installation ! Keep this instruction manual in a safe place ning the adjustable front feet (see figure); the for future reference. Should the appliance be angle of inclination, measured according to the worktop, must not exceed 2°. sold, transferred or moved, make sure the Levelling your appliance correctly will provide instruction manual accompanies the washer- it with stability and avoid any vibrations, noise...
Page 3 Connecting the drain hose • the supply voltage is included within the values indicated on the Technical Data Plate Connect the drain fixed on the machine. hose, without ben- • the socket is compatible with the washer- ding it, to a draining dryer’s plug.
Page 4: The First Wash Cycle
As the colours of the wires in the lead may not ! The power supply cable must only be repla- correspond with the coloured markings iden- ced by an authorised serviceman. tifying the terminals in your plug, proceed as follows: Warning! The company denies all liability if and Connect Green &...
Page 5: Technical Data
Technical data Model FDL 9640 width 59.5 cm Dimensions height 85 cm depth 54 cm from 1 to 9 kg for the wash programme Capacity from 1 to 6 kg for the drying programme Electrical please refer to the technical...
Page 6: Care And Maintenance
Care and maintenance Cutting off the water and electri- Cleaning the pump city supplies The washer-dryer is fitted with a self-cleaning • Turn off the water tap after every wash cycle. pump which does not require any maintenan- This will limit wear on the hydraulic system ce.
Page 7: Precautions And Tips
Precautions and tips • During the drying phase, the door tends to get quite This washer-dryer was designed and constructed in hot. accordance with international safety regulations. The fol- • Do not use the appliance to dry clothes that lowing information is provided for safety reasons and must have been washed with flammable solvents therefore be read carefully.
Page 8: Description Of The Washer-Dryer And Starting A Wash Cycle
Description of the washer-dryer and starting a wash cycle Control panel WASH CYCLE PROGRESS indicator lights DRYING knob DOOR ON/OFF button LOCKED TEMPERATURE indicator light knob START/PAUSE button with indicator light FUNCTION Detergent dispenser drawer buttons with indicator lights WASH CYCLE knob Detergent dispenser drawer: used to dispense START/PAUSE button with indicator light: starts or tem-...
Page 9: Indicator Lights
Indicator lights Door locked indicator light If this indicator light is on, the appliance door is locked to The indicator lights provide important information. prevent it from being opened accidentally; to avoid any This is what they can tell you: damage, wait for the indicator light to switch off before you open the appliance door (wait approximately 3 minutes).
Page 10: Wash Cycles
Wash cycles Table of wash cycles Detergents Max. Max. Max. Cycle Description of the wash cycle temp. speed Drying load duration (kg) (°C) (rpm) Fabric Wash softener CLEAN Plus 1 Anti-Stain 40° 1400 185’    40° 1200 60’ 2 Anti-Stain Quick ...
Page 11: Personalisation
Personalisation Setting the temperature Turn the TEMPERATURE knob to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash ( ). The washer-dryer will automatically prevent you from selecting a temperature which is higher than the maximum value set for each wash cycle. ! Exception: if the 3 programme is selected, the temperature can be increased up to a value of 90°C.
Page 12: Detergents And Laundry
Detergents and laundry Detergent dispenser drawer of dust in the air. Drying cycles can only be selected on a level basis. Dryness level “ ” recommended. Successful washing results also depend on the correct Anti-Stain Quick: this programme is ideal for washing dose of detergent: adding too much detergent will not the most difficult daily stains in 1 hour.
Page 13: Troubleshooting
Troubleshooting Your washer-dryer could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. • The appliance is not plugged into the socket fully, or not enough to make contact. •...
Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
Page 15: Product Guarantee And Repair Information
Product Guarantee and Repair Information Guarantee Recycling and Disposal Information As part of Hotpoint’s continued commitment to 12 Months Parts and Labour Guarantee helping the environment, Hotpoint reserves the right Your appliance has the benefit of our manufacturer’s to use quality, recycled components to keep down guarantee, which covers the cost of breakdown customer costs and minimise material wastage.
Page 16 11111588 04/2017 Whirlpool EMEA S.p.A. - Socio Unico via Carlo Pisacane n.1, 20016 Pero (MI) Italy www.hotpoint.co.uk...
