LED TRACKLIGHT
Model
Wa�s Lumens Beam Angle PF
LED Chip Type
VT-407
7
490
24°
>0.5 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 180xØ40.5x50mm
VT-415
15
1200
24°
>0.5 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 200xØ50x50mm
VT-420
20
1600
24°
>0.9 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 220xØ60x50mm
CRI Body Type
Long Life
Input Power
Installation instructions:
1, Switch off the power.
2, Fix the lamp into the track and turn adaptor slide switch. (picture 1)
3, Ajust the illumination angle of the luminaire.(picture 2)
4, Switch on the power if above steps done properly without any mistakes.(picture 3)
ON
OFF
ON
Dimension
OFF
ON
350
90
OFF
1
2
3
