Summary of Contents for Merach MRK-T05
- Page 1 POWEREDBY USER MANUAL MERACH MRK-T05 PORTABLE TREADMILL Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com...
- Page 2 WE ARE Our customers aren’t just important; their health, fitness, and pure enjoyment of live are at the core of everything we do at MERACH. From innovative fitness research and cutting-edge product development, to our exceptional purchasing & after-sales service, we are our customers’...
-
Page 3: Table Of Contents
Packing List ..................04 Assembly Instructions ............... 05 Folding & Moving ................07 Instructions on Product Usage ............08 Instructions for [MERACH] App Connection and Use ..... 10 Instructions for [KINOMAP] App Connection and Use ...... 11 Warm-up ................... 12 Troubleshooting .................13 Warranty Information ............... -
Page 4: Safety Instructions
SafetyInstructions To ensure your safety and avoid accidents, please read the manual carefully before use and pay attention to the following safety matters. The treadmill must be placed on flat ground; the treadmill is suitable for placing indoors, avoiding moisture and not splashing water onto the treadmill. Do not place any foreign objects on the treadmill, both sides of the treadmill and the front end should be 1 meter and the back end should have 6.6*3.3ft of safe use space, so as to facilitate the emergency jump away. - Page 5 SafetyInstructions Use qualified sockets to avoid bringing danger. If the plug and socket are not compatible, please do not move the plug, ask a professional to handle it. The product is suitable for home use, not suitable for professional training and testing, and can not be used for medical purposes.
-
Page 6: Technical Details
TechnicalDetails iPadholder Frontarmrest Rightcolumn Leftcolumn Securitylock Powerswitch Remotecontrol Frontfootpad Runningbelt Columnknob Rear Adjustmentoffootpad shroud Sidebar Rearshockpad ProductName: Merachtreadmill Model: MRK-T05 Voltage: 110V~60Hz Maximumhorsepower: 2.5HP Runningarea: 43.3*16.5inch Speedrange: 0.6-7.5MPH Max.loadweight: 265lbs Foldingsize: 57.5*28.9*4.4inch Netweight: 70.5lbs Packingsize: 56.9*28.9*4.9inch Grossweight: 81.6lbs... -
Page 7: Packing List
USER MANUAL MERACH MR-T05 FOLDED TREADMILL Questions or Concerns? IMPORTANT! Please read all details before use, and keep this user manual for future reference. PLEASE CONTACT US BEFORE THE RETURN: Mon-Fri,9:00 am-5:00 pm PST/PDT support@merach.com | (213) 672-2298 Securitylock*1 Siliconoil*2 Instructionmanual*1... -
Page 8: Assembly Instructions
AssemblyInstructions Putallthepartsintheemptyareaandremovethepackagingmaterials,donotdiscardthe packagingmaterialsbeforefinishingtheassembly. Step1: Rotatethecolumntostandupinthedirectionshown. - Page 9 AssemblyInstructions Step2: 1.InserttheiPadholderintothefrontarmrestslot. 2.Inserttheredsafetylockintotheyellowmarkposition. 3.Pluginthepowercord,andturnonthepowerswitch, andthetreadmillcanbepoweredonandused. Step3: 1.Turnthecolumnknobcounterclockwiseinthe directionshown. 2.Putdownthecolumnandtightenthecolumn knobclockwise.
-
Page 10: Folding & Moving
Folding&Moving Folding 1.Turnthecolumnknobcounterclockwiseinthe directionshown. 2.Putdownthecolumnandtightenthecolumn knobclockwise. Moving Whenyouneedtomovethetreadmill,lifttherear ofthemachineandthenmove. -
Page 11: Instructions On Product Usage
InstructionsonProductUsage 1.Descriptionofthedisplaywindow (1)Timewindow:displaytimedata.Range:0:00-99:59. (2)Caloriewindow:displayingcaloriedata.Range:0-9999. (3)Distancewindow:displaydistancedata.Range:0.00-99.9km. (4)Speedwindow:displayspeeddata.Range:0.6-7.5MPHintreadmillmode,0.6-3.7MPHin walkermode. (5)Windowscycledisplaysevery5seconds:time,distance,calories,andspeed. Time Calorie Speed Distance 2.Hibernationfunction Whenstoppedwithoutanyoperationformorethan10minutes,thesystemturnsoffall displaysandentersthehibernationstate.Pressanybuttontowakeup. 3.Safetylockfunction Anytimethesafetylockisdisconnected,thetreadmillwillstoprunningquickly,alldatawill beclearedandthewindowwillshow"E14".Allnormaloperationsmustbeinthestateofthe safetylockbeingclosed. Note:Whenthetreadmillisrunning,pulloffthesafetylock,thetreadmillwillstoprunning immediately! 4.Functionbuttondescription(theremotecontrolfunctionis consistentwiththevitalpanel) （1） Speedshortcutbutton: Intherunningstate,pressthisbutton SPEED SPEED SPEED toreachthespecifiedspeed. （2） Speedplusorminusbutton: Intherunningstate,pressthisbuttonto increaseordecreasethespeed,andpressand holdittoincreaseordecreasecontinuously. - Page 12 InstructionsonProductUsage (3)Start/Pause/Stopkey. Start:Pressthisbuttoninthestandbyorpausestate,thewindowwillstartthemotorafter3 secondsofcountdown. Pause:Intherunningstateofthetreadmill,ashortpressofthisbuttonwillstoprunning,and themotorstopstodisplaythetimewhensuspended(flashing)andenterthesuspendedstate. Shortpressingthisbuttonagainwillresumethemovement,andthemovementdatato continuethedatabeforethesuspension. Stop:inthetreadmillrunningstateorpausestate,alongpressofthisbuttonfor3secondswill stoprunning,andthetreadmillwillresettozero. (4)Modebutton:thefollowingthreetargetsettingmodes:timesetting,distancesetting,and caloriesetting.Whenthesettime,setcalories,andsetdistanceinanymodedecreasesto zero,thespeedslowlydecreasesuntilitstops,andthedistancewindowdisplays “ END” ,the peakbeepersendsashortsoundBeep-Beep-Beepandreturnstostandbyafter5seconds. a.Inmanualmode,pressthemodebuttontoenterthetimecountdownmode,thetime windowshowsthetimeandflashing,theinitialtimeis:30:00,pressthespeedplusor minusbuttontosetthecountdown.Timesettingrange:5:00-99:00. b.Inthedistancecountdownmode,pressthemodebuttontoenterthedistancecountdown mode,theinitialdistancedisplay:0.6mile,pressthespeedplusorminusbuttontosetthe distance,thesettingrange:0.3-62miles,eachtimeincreaseordecrease0.6mile. c.Inthecaloriecountdownmode,pressthemodebuttontoenterthecaloriecountdown mode,theinitialcaloriedisplay:50.0kcal,pressthespeedplusorminusbuttontosetthe caloriesettingrange:10.0-999kcal,increaseordecreaseby1kcaleachtime. 5.Treadmillswitchwalkerinstructions: 1.Whenswitchingmode,firstensurethatthemachineisinthestopstate. 2.Counterclockwiserotationofthetwosidesofthecolumnknob,thecolumnfolded,the treadmillswitchintothewalkermode,thehighestspeedof3.7MPH. 3.Pullupthecolumn,clockwiserotationofbothsidesofthecolumnknob,andthewalker switchtotreadmillmode,thehighestspeedof7.5MPH.
-
Page 13: Instructions For [Merach] App Connection And Use
Instructions for [MERACH] App Connection and Use Download and use of MERACH Ourcustomercangeta180-dayMERACHmembership.Pleasecontactusthrough support@merach.comafterreceivingtheproducttogetanexclusiveredemption code.PleaseincludeyourorderIDandMERACHappUsername. 1.TodownloadtheMERACHapp,scantheQRcodeorsearch"MERACH"intheApple AppStore®orGooglePlayStore. MERACH APP Download APP Connection Guide 2.OpentheMERACHapp.LogInorSignUp. 3.Followthein-appinstructionstosetupyourdevice. -
Page 14: Instructions For [Kinomap] App Connection And Use
Instructions for [KINOMAP] App Connection and Use Download and use of KINOMAP 1.TodownloadtheKinomapapp,scantheQRcodeorsearch"Kinomap"inthe AppleAppStore®orGooglePlayStore. 2.OpentheKinomapapp.LogInorSignUp. 3.Selectthecorrespondingfitnessequipment 4.TurnonBluetooth,andchooseMerach. 5.Select “ PortableTreadmill",andfindyour"MRK-T05-XXXX". 6.Starttrainingandexploredifferentworkoutmethods. -
Page 15: Warm-Up
Warm-up Dostretchesbeforeexercising.Warmmusclesareeasiertostretch,sostartwitha 5-10minutewarm-up,thendosomestretchesshownbelow-5times,10seconds ormoreperleg.Doitagainaftertheworkout. 1.Stretchdown Bendyourkneesslightly,slowlybendyourbodyforward, relaxyourbackandshoulders,andtrytotouchyourtoes withyourhands.Holdfor10-15seconds,thenrelax. Repeat3times(seeFigure1). 2.Seatedhamstringstretch Sitwithonelegstraight.Bringtheotherleginsothatitissnug ontheinsideofthestraightenedleg.Trytotouchyourfeetwith yourhand'stoe.Holdfor10-15seconds,thenrelax. Repeat3timesforeachleg(seeFigure2). 3.CalfandAchillestendonstretch Standwithbothhandsagainstthewalloratree,putonefoot behindanother.Keepthebacklegstraightandyourheelonthe ground,leantowardawalloratree.Holdfor10-15seconds, thenrelax.Repeat3timesforeachleg(seeFigure3). 4.Quadricepsstretch Reachbackwithyourrighthand,grabyourrightfootand slowlypullittowardyourhipsuntilyoufeelthemusclesinthe frontofyourthightense.Holdfor10-15seconds,thenrelax. Repeat3timesforeachleg(seeFigure4). 5.Sartorius(innerthighmuscle)stretch Sitwithyourfeetfacingeachotherandyourkneesfacingout. Grabyourfeetwithbothhandsandpulltowardyourgroin. Holdfor10-15seconds,thenrelax. Repeat3times(seeFigure5). -
Page 16: Troubleshooting
Troubleshooting Faultcode Troubleshooting 1.DetectwhetherthemotorHalllineisoffordamaged. E02--Halldetection 2.Needtoreplacethecontrollerormotor,pleasecontactafter-sales error orprofessionaltechnicianstodealwithit. (Pleaseseelastpageforcontactinformation.) 1.Hardwarehasahighcurrentimpactinexcessofthesetvalue. 2.Shutdownandrestart. E03--hardware overcurrentprotection 3.Iftheerrorisstillreported,pleasecontacttheafter-salesor professionalandtechnicalpersonneltodealwithit. (Pleaseseelastpageforcontactinformation.) 1.Checkwhetherthepowerinputvoltagerangeisnormal. E04--Halldetection 2.Needtoreplacethecontroller,pleasecontacttheafter-salesor error professionalandtechnicalpersonneltodealwithit. (Pleaseseelastpageforcontactinformation.) 1.Checkwhetherthepowerinputvoltageisnormal. 2.Checkwhetherthecontrollerpowerinputterminalislooseand haspoorcontact. E05--Undervoltage 3.Checkwhetherthemachinepowersocketandterminallose protection contactpoor. 4.Iftheerrorisstillreported,pleasecontacttheafter-salesor professionalandtechnicalpersonneltodealwithit. (Pleaseseelastpageforcontactinformation.) 1.Motoroverloadoperation. 2.Checkwhetherthemotorisstuckorthedrivebeltisseriously misaligned,checkwhetherthemotorlinemaleandfemaleterminal E06--Overload connectionisloose. protection 3.Iftheerrorisstillreported,pleasecontacttheafter-salesor professionalandtechnicalpersonneltodealwithit. (Pleaseseelastpageforcontactinformation.) 1.Turnoffthepower,andletthemachinecooldownfor10minutes 2.Checkwhethertheresistanceoftherunningbeltisseverelyover... - Page 17 Troubleshooting Faultcode Troubleshooting 1.Checkwhetherthemotorlinemaleandfemaleterminalsareloose. E11--motoroutof 2.Iftheerrorisstillreported,pleasecontacttheafter-salesserviceor phaseerror professionalandtechnicalpersonneltodealwithit. (Pleaseseelastpageforcontactinformation.) E12--Controller 1.Needtoreplacethecontrollerormotor,pleasecontactafter-sales internalself-test orprofessionaltechnicianstodealwithit. errorreport (Pleaseseelastpageforcontactinformation.) 1.Detectwhetherthecommunicationlineisabnormal; E13--relaycannot 2.Pleasecontacttheafter-salesserviceorprofessionalandtechnical receivetheelectronic personneltodealwithit. metersignalerror (Pleaseseelastpageforcontactinformation.) 1.Detectwhetherthecommunicationlineisabnormal; E14--Safetylock-off 2.Pleasecontactafter-salesorprofessionaltechnicianstodealwithit. error (Pleaseseelastpageforcontactinformation.) 1.Detectwhetherthecommunicationlineisabnormal; E15--Receivingsignal 2.Pleasecontactafter-salesorprofessionaltechnicianstodealwithit. error (Pleaseseelastpageforcontactinformation.)
-
Page 18: Warranty Information
Unsupervised use by children under 18 years old. MERACH and its subsidiaries are only responsible for damages caused by the intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses, so the above disclaimer may not apply to you. -
Page 19: Fcc Statement
FCCStatement FCCStatement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 20 @merachfit @Merachfit @Merachfit @Merachfit Customer Service: support@merach.com Official Website: merachfit.com...
