Summary of Contents for Orava LR-103
- Page 1 Lint remover LR-103...
-
Page 2: General Safety Instructions And Warnings
ORAVA electrical appliances are manufactured according to the state of the art and recognized safety-technical rules. Nevertheless, the use or use contrary to designation may result in the risk of injury or endanger the life of the user or third person, damage to the device and other material values. - Page 3 • Failure to follow the safety instructions and warnings is forbidden by the manufacturer for any damage to property or property! • Keep the operating instructions as close to the device as possible throughout its service life. Always keep the operating instructions together with the appliance for future use and use by new users.
- Page 4 • This degree of protection is not indicated on the product and on the technical parameters in the operating instructions. • If the protection class of the product is different from IPX0, this information is then displayed on the device label or in the technical manuals of the operating instructions.
- Page 5 • Only use a power cord with a plug (mains lead) supplied with the device and compatible with a wall outlet. Using another cable may result in fi re or electric shock. Always connect an electrical appliance to an easily accessible power socket.
- Page 6 • Do not expose the appliance to water or moisture. The ingress of water into the appliance increases the risk of electric shock. If the power cord is wet or the water has penetrated the water, disconnect it immediately from the mains. If the appliance is plugged into a mains socket and if possible, turn off the power supply before attempting to disconnect the power supply.
- Page 7 1.5 Cleaning, maintenance and repairs • Observe the normal user cleaning and maintenance of the appliance in the recommended way. Do not use solvents or harsh cleaners for cleaning. Pollution and visible stains from fi nger contact, respectively. hands can be cleaned using detergent detergents specially designed to clean household appliances.
- Page 8 2. Special Safety Instructions. Read carefully! • Electrical equipment is designed and manufactured in such a way as to allow for safe operation and use by persons without a professional qualifi cation. Despite all the measures taken by the manufacturer to ensure safe use, handling and use, it carries with it some residual risks and associated potential hazards.
- Page 9 Check/Comissioning • We recommend performing both initial and subsequent periodic inspections of the device. Only use the device with accessories supplied and approved by the manufacturer. • Never use the device if it is incomplete or damaged during use has been damaged parts or accessories (eg.
- Page 10 Caution! • Never use the appliance to remove hair from parts of the human body. There is a risk of serious injury! Caution! • Always make sure that the machine is switched off by the main switch before handling any equipment (common use, cleaning, etc.).
- Page 11 Caution! • Keep the device dry. The appliance must not be immersed in water or other liquids. Do not use the appliance in places where it could fall into a washbasin, bath, or other container containing water, including a swimming pool. •...
- Page 12 Charging the built-in battery. • The device comes with a non-fully charged built-in rechargeable battery. • To achieve the maximum capacity and the longest battery life, the battery needs to be fully discharged and then charged to its maximum level (it may take about 8 to 10 hours to charge before using it for the fi...
-
Page 13: Parts Description
Parts description 1 Protective cover 2 Planchet 3 Motor shaft 4 Knives 5 Lint tray 6 Power USB mini-connector (connection of the supplied cable and a suitable AC power adapter) 7 Switch 8 LED indicator light 9 Cleaning brush 10 USB charging cable 11 Clothes brush 12 Tank cover release button... - Page 14 Charging 1. Turn off the power switch. 2. Plug the mini connector of the supplied cable into the power mini connector on this device and the other USB connector into the USB connector on the optional AC adapter (DC output voltage 5 V, 500 - 1000 mA). Plug the AC adapter into an electrical outlet.
-
Page 15: Using The Device
Using the device 1. Remove the transparent protective cover from the device. 2. Slide the power switch to the ON position. turn on the device. 3. Hold the device at a slight angle against the stretched fabric. Gently press it against the garment and move it back and forth to remove lint. -
Page 16: Cleaning And Maintenance
Different ways to use the device 1. Quick removal: Remove lint from smaller sections by swiping left and right. 2. Removing tough lint: Remove lint by swiping left and right and up and down multiple times. 3. Removing lint from thin fabrics: Fold the garment into two layers and stretch it on a fi... - Page 17 7. After cleaning, reassemble all parts in the reverse order of disassembly. • To prevent damage to the planchet and internal knives, put a protective cover on the device. • Be careful when handling knives to avoid injury. • Do not press on the planchet. It can get damaged. •...
- Page 18 Producer: ORAVA retail 1, a.s. Seberíniho 2 821 03 Bratislava Slovenská republika Importer: ORAVA retail 1, a.s. ORAVA distribution CZ, s.r.o. Seberíniho 2 Ostravská 494 821 03 Bratislava 739 25 Sviadnov Slovenská republika Česká republika INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING Dispose of used packaging material at a municipal waste disposal site.
