- Page 1 OWNER’S MANUAL LED TV * LG LED TVs are LCD TVs with LED backlighting. Click! User Guide Please read this manual carefully before operating your set and retain it for future reference. LB63** LB72** LB65** LB87** LB67** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS REMOTE CONTROL LICENSES OPEN SOURCE SOFTWARE MAGIC REMOTE FUNCTIONS NOTICE Registering Magic Remote How to use Magic Remote Precautions to Take when Using the EXTERNAL CONTROL DEVICE Magic Remote SETUP USING THE USER GUIDE SAFETy INSTRUCTIONS Viewing 3D Imaging (Only 3D models) MAINTENANCE... -
Page 3: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS SAFETy INSTRUCTIONS Please read these safety precautions carefully before using the product. WARNING y Make sure to connect Mains cable to y Do not place the TV and/or remote control in compliant AC mains socket with Grounded the following environments: earth pin. - Page 5 SAFETY INSTRUCTIONS y When mounting TV onto wall make sure to y Dispose of used batteries carefully to neatly install and isolate cabling from rear ensure that a small child does not consume of TV as to not create possibility of electric them.
- Page 6 SAFETY INSTRUCTIONS y Do not allow any impact, shock or any y Unplug the TV from AC mains wall socket objects to fall into the unit, and do not drop if you do not intend to use the TV for a long anything onto the screen.
- Page 7 SAFETY INSTRUCTIONS y If you install the TV on a stand, you need y Do not place non-rechargeable batteries in to take actions to prevent the product from charging device. overturning. Otherwise, the product may fall over, which may cause injury. y Make sure there are no objects between the remote control and its sensor.
- Page 8 SAFETY INSTRUCTIONS y Take care not to touch the ventilation y When cleaning the product and its openings when watching the TV for long components, unplug the power first and wipe periods as the ventilation openings may it with a soft cloth. Applying excessive force become hot.
- Page 9 SAFETY INSTRUCTIONS y Contact the service centre once a year to y You may find different brightness and colour clean the internal parts of the product. of the panel depending on your viewing Accumulated dust can cause mechanical position(left/right/top/down). failure. This phenomenon occurs due to the characteristic of the panel.
-
Page 10: Viewing 3D Imaging (Only 3D Models)
Cautions when using the 3D glasses y Do not watch 3D contents when you feel y Make sure to use LG 3D glasses. Otherwise, fatigue from lack of sleep, overwork or you may not be able to view 3D videos drinking. -
Page 11: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING NOTE y Image shown may differ from your TV. y Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. y The available menus and options may differ from the input source or product model that you are using. y New features may be added to this TV in the future. - Page 12 ASSEMBLING AND PREPARING ENERGY AV MODE INPUT ENERGY AV MODE INPUT SAVING SAVING FLASHBK FLASHBK LIST MARK LIST MARK MUTE MUTE MENU INFO Q.MENU MENU INFO Q.MENU ENTER ENTER BACK EXIT BACK EXIT L/R SELECT L/R SELECT FREEZE FREEZE RATIO RATIO Remote Control, Batteries Magic Remote, Batteries...
- Page 13 ASSEMBLING AND PREPARING Cable Holder Cable Managements Stand Screws (Depending on model) 4EA, M4 x L20 (See p.25) (Only LB63**, LB65**, LB67**, (Only 32LB65**) LB72**) (See p.18) (See p.25) Stand Screws Stand Bases Stand Assys 4EA, M4 x L14 (Only LB63**, LB65**) (Stand Body/Stand Base) (Only LB63**, (See p.18)
-
Page 14: Separate Purchase
Contact your dealer to buy these items. These devices only work with certain models. AG-F***DP AG-F*** AN-MR500 Dual Play Glasses Cinema 3D Glasses Magic Remote Tag on AN-VC5** LG Audio Device Video Call Camera Wall Mount Bracket Compatibility LB63** LB65**, LB67**, LB72** LB87** AG-F***DP • •... -
Page 15: Parts And Buttons
Joystick Button Joystick Button C type : LB87** Built-in Camera Screen Speakers LG Logo light Remote control and Intelligent sensors Joystick Button 1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment. 2 Joystick Button - This button is located below the TV screen. -
Page 16: Using The Joystick Button
ASSEMBLING AND PREPARING NOTE y You can set the LG Logo light or Power indicator Light to on or off by selecting General in the main menus. (Depending on model) Using the Joystick button You can simply operate the TV functions by pressing to turn On/Off or sliding your finger over joystick button moving up, down, left or right. -
Page 17: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV y When transporting a large TV, there should be at least 2 people. Please note the following advice to prevent the y When transporting the TV by hand, hold the TV from being scratched or damaged and for TV as shown in the following illustration. -
Page 18: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV LB67**, LB72** Stand Body Image shown may differ from your TV. Attaching the stand LB63**, LB65** A stand base Stand Base A stand base B stand base B stand base 1 Attach the stand to the TV using the upper mounting hole on the back of the TV. - Page 19 ASSEMBLING AND PREPARING LB87** Sound Bar Stand Assy Right Stand Assy Left M4 x L14 M4 x L14 Screw Cover...
-
Page 20: Attaching The Sound Bar Supporter
ASSEMBLING AND PREPARING Attaching the Sound Bar Supporter CAUTION (In case of mounting on a wall) y When attaching the stand to the TV set, place the screen facing down on a LB87** cushioned table or flat surface to protect the screen from scratches. - Page 21 ASSEMBLING AND PREPARING CAUTION y When attaching the Sound Bar Supporter to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches. y Make sure that the screws are inserted correctly and fastened securely.
-
Page 22: Mounting On A Table
ASSEMBLING AND PREPARING Using the Kensington security system NOTE (This feature is not available for all models.) y Remove the sound bar supporter before y Image shown may differ from your TV. installing the stand by performing the The Kensington security system connector sound bar supporter attachment in is located at the rear of the TV. -
Page 23: Mounting On A Wall
We recommend the use of LG’s wall mount bracket. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices. - Page 24 If you install the TV on a ceiling or slanted Separate purchase (Wall Mounting Bracket) wall, it may fall and result in severe injury. 42/47LB63** Use an authorised LG wall mount and Model 32LB65** 42/47/50LB65** contact the local dealer or qualified 49/55LB87** personnel.
-
Page 25: Tidying Cables
ASSEMBLING AND PREPARING Tidying cables CAUTION Image shown may differ from your TV. y Do not move the TV by holding the cable holder, as the cable holder may break, 1 Gather and bind the cables with the cable and injuries and damage to the TV may holder. -
Page 26: Using Built-In Camera
ASSEMBLING AND PREPARING Using Built-in Camera Preparing Built-in Camera (Only LB87**) 1 Pull up the slide at the back of the TV. You can make a Skype video call or use the motion recognition function using the built-in Angle camera of the TV. Adjustment This TV does not support the use of an external Lever... -
Page 27: Name Of Parts Of Built-In Camera
ASSEMBLING AND PREPARING Push down the built-in camera when you are not using it. Name of Parts of Built-in Camera Camera Lens Protective Film Microphones Checking the Camera’s Shooting Range Press the (Home) button on the remote control to display the Home menu. Select CAMERA and then press the Wheel(OK) button. -
Page 28: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Antenna connection Connect the TV to a wall antenna socket with an RF cable (75 Ω). This section on MAKING CONNECTIONS mainly uses diagrams for the 42LB65** models. Connect various external devices to the TV and switch input modes to select an external device. -
Page 29: Hdmi Connection
MAKING CONNECTIONS HDMI connection (Only LB87**) Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown. Choose any HDMI input port to connect. It does not matter which port you use. -
Page 30: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI connection (Only LB87**) Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown. To transmit an audio signal, connect an audio cable. -
Page 31: Component Connection
MAKING CONNECTIONS Component connection (Only LB87**) Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown. (Only LB63**, LB65**, LB67**, LB72**) COMPONENT VIDEO AUDIO YELLOW GREEN (Use the... -
Page 32: Composite Connection
MAKING CONNECTIONS Composite connection (Only LB87**) Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown. (Only LB63**, LB65**, LB67**, LB72**) COMPONENT COMPONENT VIDEO AUDIO YELLOW (Use the composite... -
Page 33: Headphone Connection
MAKING CONNECTIONS Headphone connection Audio connection Transmits the headphone signal from the TV to You may use an optional external audio system an external device. Connect the external device instead of the built-in speaker. and the TV with the headphone. Digital optical audio connection Transmits a digital audio signal from the TV to an external device. -
Page 34: Usb Connection
MAKING CONNECTIONS MHL connection USB connection Mobile High-definition Link (MHL) is an interface Connect a USB storage device such as a USB for transmitting digital audiovisual signals from flash memory, external hard drive, or a USB mobile phones to television sets. memory card reader to the TV and access the SmartShare menu to use various multimedia files. -
Page 35: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. -
Page 36: Magic Remote Functions
MAGIC REMOTE FUNCTIONS MAGIc REMOTE FUNcTIONS This item is not included for all models. When the message “Magic Remote battery is low. Change the battery.” is displayed, replace the battery. To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching ends to the label inside the compartment, and close the battery cover. -
Page 37: Registering Magic Remote
MAGIC REMOTE FUNCTIONS How to use Magic Remote Voice recognition (Depending on model) Network connection is required to use the y Shake the Magic Remote voice recognition function. slightly to the right and left or press (Home), 1 Press the Voice recognition button. INPUT, buttons to make 2 Speak when the voice display window... -
Page 38: Using The User Guide
USING THE USER GUIDE / MAINTENANCE USING THE USER GUIDE MAINTENANcE cleaning your TV User Guide allows you to more easily access the detailed TV information. Clean your TV regularly to keep the best performance and to extend the product lifespan. 1 Press the (Home) button to access the Home menu. -
Page 39: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Solution y Check the remote control sensor on the product and try again. Cannot control y Check if there is any obstacle between the product and the remote control. the TV with the y Check if the batteries are still working and properly installed ( remote control. -
Page 40: Specifications
SPECIFICATIONS SPECIFICATIONS Wireless module(LGSBW41) Specifications Wireless LAN Bluetooth Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0 2400 to 2483.5 MHz Frequency Frequency 5150 to 5250 MHz 2400 to 2483.5 MHz ragne ragne 5725 to 5850 MHz 802.11a: 13 dBm 802.11b: 15 dBm Output power Output power 802.11g: 14 dBm... - Page 41 SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. For the power supply and power consumption, refer to the label attached to the product. 42LB63** 47LB63** 32LB65** MODELS 42LB6310-CC 47LB6310-CC 32LB6500-CA 960 x 610 x 218 1072 x 677 x 247 731 x 484 x 207 Dimensions...
- Page 42 SPECIFICATIONS 55LB72** 65LB72** MODELS 55LB7200-CA 65LB7200-CA 1231 x 769 x 247 1449.5 x 883.7 x 313.9 Dimensions With stand (mm) (W x H x D) Without stand (mm) 1231 x 718 x 55.1 1449.5 x 840.8 x 58.1 27.9 Weight With stand (kg) 18.5 26.5...
- Page 44 Record the model number and serial number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL...
- Page 45 OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com...
- Page 46 KEY CODES KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button...
- Page 47 (TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals.
- Page 48 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...
- Page 49 EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA...
- Page 50 EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99.
- Page 51 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 52 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 * (Depending on model) Ack [i][ ][Set ID][ ][OK/NG][Data][x] 14. Bass (Command: k s) 09. Tint (Command: k j) ► To adjust Bass. ► To adjust the screen tint. You can also adjust in the AUDIO menu.
- Page 53 EXTERNAL CONTROL DEVICE SETUP Set ID = All = 00 5th Band 20(decimal) Data 00 & 01 = Channel Data is 10 = 00 0a Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] Data 02 = Analog Antenna TV = 00 Result = ma 00 00 0a 00 * It depends on model, and can adjust when sound mode is EQ adjustable value.
- Page 54 EXTERNAL CONTROL DEVICE SETUP Number Data 05 = Digital Antenna TV = 02 - 22 : Antenna TV (DTV) – Don’t Use Physical Total = ma 00 00 00 11 00 01 02 Channel Number - 26 : Cable TV (CADTV) - Don’t Use Physical 2.
- Page 55 11 11 EXTERNAL CONTROL DEVICE SETUP 24. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data X : don’t care 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02] ISDB-BS (Japan)
- Page 56 EXTERNAL CONTROL DEVICE SETUP 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
