IPSW-400
Software rev: V 1.00 & above

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cole-Parmer IPSW-400 and is the answer not in the manual?

Questions and answers

Related Manuals for Antylia Scientific Cole-Parmer IPSW-400

Summary of Contents for Antylia Scientific Cole-Parmer IPSW-400

  • Page 1 IPSW-400 Software rev: V 1.00 & above...
  • Page 2 Easy Reference: Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place:...

  • Page 3: Table Of Contents

    CONTENTS P.N. 1.10.0.0.13103, Rev A4, October 2020 INTRODUCTION ........................... 4     SPECIFICATIONS ..........................5     INSTALLATION ............................. 6     LOCATING THE SCALE ........................6     LIST OF ACCESSORIES ........................6     KEY DESCRIPTIONS ..........................7  ...

  • Page 4: Introduction

    INTRODUCTION The IPSW-400 provides the user with the electronics necessary to build • an accurate, fast, versatile weighing system. • Functions include, weighing, check weighing, parts counting, animal weighing and percent weighing. • The system includes automatic zero tracking, audible alarm for check- weighing, semi-automatic tare and an accumulation facility that allows individual weights or counts to be stored and the total recalled.

  • Page 5: Specifications

    SPECIFICATIONS IPSW-400 Series Models Model IPSW-400-30 IPSW-400-50 IPSW-400-100 IPSW-400-150 IPSW-400-300 Maximum 30lb / 15kg 50lb / 25kg 100lb / 50kg 150lb / 75kg 300lb / 150kg Capacity 0.002kg / 0.001kg 0.002lb / 0.001kg 0.001lb / 0.005kg 0.01lb / 0.005kg 0.02lb / 0.01kg Readability 23.6”x17.7”...

  • Page 6: Installation

    INSTALLATION LOCATING THE SCALE  The scale should not be placed in a location that will reduce the accuracy.  Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents.  Avoid unsuitable tables or surfaces. ...

  • Page 7: Key Descriptions

    4.0 Key Specifications Sets the zero point for all subsequent weighing. The display shows zero. [Tare/↵] Tares the scale. Stores the weight currently on the scale as tare value, subtracts the tare value from the gross weight and shows the results. A secondary function, is of “Enter”...

  • Page 8: Displays

    DISPLAYS The LCD display will show a value and a unit to the right of the digits. In addition the LED’s above the display will show when a weight is below or above check-weighing limits. Other symbols will show when a weight has been tared (NET) the scale is at zero and stable, if a value has been stored in memory or when the animal weighing function has been enabled.

  • Page 9: Taring

    TARING  Zero the scale by pressing the [0/Esc] key if necessary. The “ZERO” indicator will be ON. 0  Place a container on the platform, a value for its weight will be displayed.  Press the [Tare/↵] key to tare the scale. The weight that was displayed is stored as the tare value and that value is subtracted from the display, leaving zero on the display.

  • Page 10: Weighing A Sample

    WEIGHING A SAMPLE To determine the weight of a sample, first tare the empty container if it is to be used and then place the sample in the container. The display will show the net weight of the sample and the units of weight currently in use. CHANGING THE WEIGHING UNITS To change the weighing units, press the [Unit/Mode] key.

  • Page 11: Check-Weighing

     The display will now show a flashing unit which can be increased or decreased using the ⭡ or ⭣ directional keys. Once you have set the desired sample size, press the [Tare/↵] key.  From here you will return to the main piece counting display which will show the number of pieces assigned to the weight on the scale.

  • Page 12: Relay Outputs And Checkweighing

    For checkweighing in parts counting mode, use the directional buttons ⭡ or ⭣, scroll through to the parts counting mode, “Count” will be shown on the display. Press [Tare/↵] to confirm and follow the same process as outlined above. 6.7.1 Relay outputs and checkweighing The relay outputs are open collector drivers to control an external relay.

  • Page 13: Accumulated Total

    The Check-weighing function can be set up during Weighing or Parts Counting by entering values as Low or/and High Limits keyed in by the user. The limits are displayed in kg (or Lb) or pcs respectively. Checkweighing during Parts Counting To disable the Check-Weighing function enter zero into both limits by pressing the [Func/Set] key when the current limits values are displayed during the setting procedure, then pressing [Tare/↵] to store the zero values.

  • Page 14: Percent Weighing

    PERCENT WEIGHING The scale can be set to perform percent weighing. The scale will use a mass on the platform as the 100% reference weight.  Press the [Func/Set] key to select the weighing mode. Using the directional buttons ⭡ or ⭣, scroll through to the percentage ...

  • Page 15: Animal (Dynamic) Weighing

    6.10 ANIMAL (D ) WEIGHING YNAMIC The scale can be set to animal (dynamic) weighing for weighing any items that are unstable or may move. The scale will use a special filter to minimise the effects of any movement while the moving animal or unstable samples are on the scale.

  • Page 16: Animal 2 (Dynamic 2) Weighing

     To weigh a second subject press the [0/Esc] key and the display will show “LOAD” and the function will be ready for a new measurement, if necessary to zero the display, press the [0/Esc] key again, and then place the next animal on the scale. The scale will detect the new weight and hold it as before.

  • Page 17: Hold/ Peak Function

    be locked for 2 seconds. The display will show the “Hold” symbol while the display is locked.  After the 2 seconds delay, the display will now show “UNLOAD”. Remove one of the animal or items, and press [Tare/↵] key to calculate the weight of the removed animal or item.

  • Page 18: User Parameters

    USER PARAMETERS Pressing the [Func/Set] key and holding for 2 seconds during normal operation allows the user to access the parameters for customising the scale. The parameters are split into 2 groups: Scale parameters (pressing [Func/Set] will access this automatically). RS-232 parameters (can be accessed by selecting the ‘rs 1’...

  • Page 19: Command Settings

    Parameter Description Options Default setting Time Set Time. Enter the time manually. 00:00:00 Date Set date format and settings. Enter the date format and mm:dd:yy Format date then the numeric value changed when the display manually. shows mmddyy, ddmmyy or yymmdd pressing [Pcs/ ] key, then enter the...

  • Page 20: Rs-232 Parameters

    RS-232 PARAMETERS This group of parameters can be set by the user for setting the RS-232 active or not, baud rate, printing mode, accumulation mode, RS-232 language, and user or scale ID numbers.  Pressing the [Func/Set] key and holding for 2 seconds during normal operation allows the user to access the parameters.
  • Page 21 7.2.1 Print settings Parameter Description Options Default Values or setting [baud rate] Baud Rate 1200 9600 2400 4800 9600 19200 38400 57600 115200 [Language] Select Language EnGLis (English) EnGLis FrEnCH (French) GErmAn (German) SPAn (Spanish) Portug (Portuguese) Itail (Italian) [Accumulation] Enable or disable the Accumulation [Printing Printing Mode- Manual...

  • Page 22: Print Settings

    Scale will perform the following, depending on the Accumulation and Print Settings: ACCUMULATION AC on AC Off SETTINGS PRINT SETTINGS Accumulate print Print automatically, AUto automatically Do not accumulate Accumulate and Print only Print when [Print/M+/Esc] key is when [Print/M+/Esc] key pressed, pressed.

  • Page 23: Battery Operation

    BATTERY OPERATION • The scale can be operated from the battery if desired. The battery life can be up to 90 hours depending on the load cells used and how the backlight is used. • When the battery needs charging a symbol on the display will show less bars in the battery symbol.

  • Page 24: Rs-232 Interface

    RS-232 INTERFACE The IPSW-400 is supplied with bi-directional RS-232 interface as standard. The scale when connected to a printer or computer outputs the weight with the selected weighing unit through the RS-232 interface. Specifications: RS‐232 output of weighing data ASCII code  9600 Baud (user selectable)  8 data bits  No Parity  RS-232 serial interface is a plug as figure 1 shows: 1: Pin GND, Signal Ground 2: Pin RXD, Received Data...
  • Page 25 DATA FORMAT - COMPLETE WEIGHT <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> If ID is zero, it is left blank Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Net Wt. (or Gross Wt.) Net Wt 1.234 Kg <cr><lf>...
  • Page 26 DATA FORMAT – PEAK HOLD <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Peak Holt Wt. 1.500 Kg <cr><lf> <cr><lf> <cr><lf> <cr><lf> <cr><lf> DATA FORMAT – ANIMAL <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf>...
  • Page 27 DATA FORMAT – SIMPLE <cr><lf> <cr><lf> Net Wt. 1.500 Kg <cr><lf> <cr><lf> Hold Wt. 1000kg Peak holt wt. 1000kg Animal wt. 1000kg Ref. wt. 1000kg Percent 150.00% <cr><lf> Unit wt. 1.0234g Pieces 1000 <cr><lf> <cr><lf> <cr><lf> DATA FORMAT- CONTINUOUS OUTPUT- NORMAL WEIGHING: ST or US for STable or UnStable, ST,GROSS 1.234 Kg <cr><lf>...
  • Page 28 NOTE: 1. The accumulated total will not be sent to the RS-232 when the continuous print is turned on. 2. The continuous print will only be for the current weight and the display data. 3. In other languages the format is the same but the text will be in the language selected.

  • Page 29: Input Commands Format

    INPUT COMMANDS FORMAT The scale can be controlled with the following commands. Press the [Enter] key on the PC after each command. T<cr><lf> Tares the scale to display the net weight. This is the same as pressing [Tare/↵]. Z<cr><lf> Sets the zero point for all subsequent weighing. The display shows zero.

  • Page 30: Calibration

    10.0 CALIBRATION IPSW-400 scales can be calibrated using either metric or pound weights, depending on the weighing unit in use before calibration. The display will show either "kg" or "lb" to identify the weights expected. The scale can be calibrated using the following procedure: ...

  • Page 31: Error Codes

    11.0 ERROR CODES ERROR DESCRIPTION SUGGESTIONS CODES - -oL - - Over-range Remove weight from the scale. If the problem persists contact your dealer or Adam Equipment for assistance. Err 1 Time Setting Error Enter time using correct format and reasonable values. Format: hh:mm:ss Err 2 Date Setting Error...

  • Page 32: Replacement Parts And Accessories

    12.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows-   Power Supply Module Printer, etc.  Replacement Battery 13.0 SERVICE INFORMATION This manual covers the details of operation.

  • Page 33: Warranty Statement

    WARRANTY STATEMENT Cole Parmer offers Limited Warranty (Parts and Labour) for any components that fail due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Cole Parmer Company.
  • Page 34 WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the  EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws  and restrictions.  Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit  être effectuée conformément aux lois et restrictions locales.  Dieses Gerät nicht mit dem Hausmüll entsorgt.  Dispositivo no puede ser desechado junto con los residuos domésticos  Dispositivo non può essere smaltito nei rifiuti domestici.  FCC / IC CLASS A DIGITAL DEVICE EMC VERIFICATION STATEMENT NOTE: This equipment has been tested and found to comply with the limits for a Class A digital  device, pursuant to Part 15 of the FCC rules and Canadian ICES‐003/NMB‐003 regulation. These  limits  are  designed  to  provide  reasonable  protection  against  harmful  interference  when  the  equipment is operated in a commercial environment. This equipment generates, uses and can  radiate radio frequency energy and, if not installed and used in accordance with the instruction  manual, may cause harmful interference to radio communications. Operation of this  equipment in a residential area is likely to cause harmful interference in which case the user will ...
  • Page 35 ISO 9001:2015 certified global company with more than 40 years’ Cole Parmer experience in the production and sale of electronic weighing equipment. Cole Parmer products are predominantly designed for the Laboratory, Educational, Health and Fitness, Retail and Industrial Segments. The product range can be described as follows: -Analytical and Precision Laboratory Balances -Compact and Portable Balances -High Capacity Balances...
