Asystems DMP Series Manual

DMP8800
8-in x 8-out Digital Matrix Processor
Overview
The Asystems DMP8800 digital matrix processor
promise simple integration into any live commercial
setup. These systems combine smart signal processing
with a flexible modular mixing matrix. Sound complex?
It's not, because all routing and processing is adjusted
through a simple, intuitive graphical user interface.
DMP8800 processors provide racks-full-o-gear in
a modest 2 unit construct. Combining many great
products into a simple design, the DMP8800 simplifies
your installation and saves you money. The input and
output count on the DMP8800 are ideal for small-to-
medium sized venues, with possible expansion for
larger venues through optional 8x8 networking.
With extensive onboard signal processing, flexible
matrix routing and optional Dante audio interface
capabilities, the DMP8800 matrix processors do
it all. Asystems engineers have also ingrained
each DMP8800 with versatile and extensive signal
processing, including full 31-band GEQs, 4-band
parametric EQs, compressors, limiters, gates, auto-
mixing and auto-leveling, and page ducking. All
control is accomplished through the included Windows
software that allows for remote operation through local
area networks or the internet. With password protected
user accounts, extensive scheduling capabilities, and
flexible audio networking (optional), the DMP8800
digital matrix processor is a flexible yet reliable center
for any commercial installation.
DMP808
12-in x 8-out Digital Matrix Processor
Overview
Designed specifically for installed sound, the Asystems'
DMP808 automatic mixers combine clean, simple
designs with smart signal processing. These systems
offer fast-acting, noise-free microphone normalization
that automatically adjusts to changes in background
room noise. This essentially helps maintain high
quality audio despite the number of open microphones.
Networking capabilities allow integration of any number
of DMP808 mixers for expanding the system to up to
400 microphones.
Input on the DMP808 is achieved through professional-
standard 3-pin euroblock connectors for balanced
connections. Two sets of stereo RCA connectors are
also included for extended application. All inputs and
outputs are utilized through the flexible matrix routing
system, controlled via the included user-intuitive PC
software. This software also allows you to control the
extensive on-board signal processing, including 4-band
parametric EQs, feedback silencers, duckers, noise-
gates, compressors, limiters and, of course, automatic
mixing including NOM (Number of Open Microphones)
compensation. With flexible networking capabilities
(including a Dante networking option) and highly
accurate automixing, the DMP808 automatic mixer is a
must-have for all large commercial installations.
Digital Matrix Processors and Automatic Mixers
4 8 input channels available via 3-pin euroblock connections and dual
RCA inputs
4 VGA and USB connectors enable use as a self-contained system
4 40-bit floating point processor with internal sampling selectable
between 44.1 and 48 kHz
4 Optional 8x8 networking capabilities through Dante audio streaming
card (model no. DT88)
4 Digital AES/EBU input and output connectors (plus BNC Word Clock in
and out)
4 Playback of digital audio files from SD cards on cue or on schedule
through pre-programmed events
4 10/100 Ethernet computer interface standard
4 Automatic DHCP network IP configuration
4 Easy and intuitive control Windows software from Asystems
4 Schedule system events down to the very second
4 4-band parametric EQs and 31-band graphic equalizers
4 Seamless automatic mixing through dynamic channel gating and
attenuation
4 Compressors, limiters and noise gates
4 Autoleveler (Loudness Control) and level ducking with trigger control
4 All signal processors flexible and user-controllable
4 8 balanced mic/line input channels via euroblock connections
4 8 output channels through euroblock connections
4 Non-automatic auxiliary input through unbalanced stereo RCA
connectors
4 Gain controls for each input available on front panel
4 Seamless automatic mixing through dynamic channel gating and
attenuation
4 Network up to 400 microphones for flexible, large-scale application
(Dante option required)
4 4-band parametric EQs with low-cut, high-cut and shelving boost/cut
4 Fully functional compressors on all input channels
4 Adjustable peak limiters available on outputs
4 Delay on each output with variable time/distance control
4 Accurate feedback silencing technology built-in
4 Program-intuitive ducking function
4 Ethernet connectivity for networking and control application
4 +48V phantom power on input channels
4 Easy and intuitive control software from Asystems
4 Compatible with Asystems' range of remote controls
DMP SERIES
