Summary of Contents for Shenzhen Hongdian Technologies H9380P
- Page 2 Shenzhen Hongdian Technologies Corporation provides customers with a full range of technical supports, and the users can contact headquarter of Hongdian directly. Shenzhen Hongdian Technologies Corporation Tower A, Hongdian Building, 100 Huabao Road, Pinghu, Longgang Address District, Shenzhen, China Website http: //www.hongdian.com...
-
Page 3: Table Of Contents
Contents 1 Product Introduction ..................4 1.1 H9380P ......................4 1.1.1 Front panel .................... 4 1.1.2 Rear panel ..................... 4 1.1.3 Side panel ....................5 1.1.4 Specifications ..................5 2 Installation ..................... 9 2.1 Unpacking and attachment inspection ............9 2.2 The introduction of serial port ................. -
Page 4: Product Introduction
Product Introduction H9380P 1.1.1 Front panel 1.1.2 Rear panel... -
Page 5: Side Panel
1.1.3 Side panel 1.1.4 Specifications... - Page 6 Number of interfaces Interface Introduction H9380P 4Pin power connector Used to power the device Used to return to the previous level, exit from Custom button the main APP and enter maintenance mode and other functions Power switch button Used to control device switches...
- Page 7 Indicator status table Indicator description Status light power Power off the device Extinguished supply Power on the device Constantly bright Dialing was not successful(Module not found Network Extinguished /Module is dialing) light 4G/3G/2G dialing succeeded Constantly bright No dialing, no signal or weak signal (less than 4 Fast flashing Signal light cells)
- Page 8 extinguished for 1.75s) Successful upgrade All indicators except the power supply are always on Failed upgrade All indicators except the power supply flash quickly(Lighted up for 0.25s,extinguished for 0.25s)
-
Page 9: Installation
The introduction of serial port The serial port of the IPC device of the H9380P series is shown in the following figure.The H9380P device has three sets of RS232 interfaces with DB9 structure (the wiring mode is the same as the tty05 interface... -
Page 10: Use Of Device
Use of device Installation check Is the SIM card and TF card plugged in tightly. Whether the serial port and network port on the panel are tight. Check if the 3G/4G antenna and WIFI antenna on the panel are loose. ... -
Page 11: Use Of Device
Use of device Power-on operation Powering on the device and the power indicator (PWR) is steady on,indicating that the device is powered on successfully.After 20-30 seconds,the system/self-starting APP indicator (SYS/APP) lights up every 4 seconds,indicating that the device is operating normally. Audio video service According to the business needs to connect HDMI or LVDS display, you can use one screen or two screens to display the output separately or simultaneously.The output can be displayed normally,indicating that... -
Page 12: Usb Peripheral
USB peripheral If you need to use a general-purpose USB peripheral such as a mouse and keyboard,you can plug and playif;you need to use special USB peripherals (such as USB printer,ID card),you need to provide USB driver, or PID,VID number for us, it can be used normally after writing to the system. -
Page 13: Daily Maintenance
Daily maintenance Keep the equipment ventilated and dry. Do not stack other objects at will, keep the equipment away from heat, dust and strong magnetic fields. Make sure that the equipment is not wet or damaged when in the field or in an open field. ...
