Summary of Contents for Shenzhen Hongdian Technologies H93080
- Page 1 www.hongdian.com CLI User Manual H9380/H9380E Android IPC...
- Page 2 H9380 Android IPC CLI User Manual Shenzhen Hongdian Technologies Corporation provides customers with a full range of technical supports, and the users can contact headquarter of Hongdian directly. Shenzhen Hongdian Technologies Corporation F14-16,Headquarter Economic Center, Zhonghaixin Science&Tech Park, Bulan Road,...
- Page 3 H9380 Android IPC CLI User Manual Foreword Overview This document describes Hongdian Android IPC CLI commonly used functions and commands. Product Version The product version corresponding to this document is shown below. Product name product version H9380 V16 or higher H9380E V12 or higher (embeded version) Revision Record...
-
Page 4: Table Of Contents
H9380 Android IPC CLI User Manual Contents Foreword..............................3 Overview ............................3 Product Version ..........................3 Revision Record ..........................3 Contents..............................4 1 Instruction ............................1 1.1 Overview .............................1 1.2 CLI Mode .............................1 1.3 Public commands .........................1 1.3.1 Shortcut commands ..............................2 1.3.2 Function commands..............................3 1.3.3 Command prompts ..............................3 1.3.4 Invalid prompts ................................4 1.4 Login CLI ............................5 2 CLI Command Reference.........................7... - Page 5 H9380 Android IPC CLI User Manual 3 FAQ ..............................15 3.1 Upgrade ............................ 15 3.1.1 H9380..................................15 3.1.2 H9380E ................................... 15 3.1.3 Upgrade failed to check............................15 3.2 UI ............................. 15 3.2.1 Mouse drift ................................15 3.2.2 Display is not clear/not covered ........................15 3.3 Modem dail up ...........................
-
Page 6: Instruction
H9380 Android IPC CLI User Manual Instruction 1.1 Overview CLI (command-line interface) refers to the interface where executable instructions can be typed at the user prompt. It usually does not support the mouse. The user inputs instructions through the keyboard, and the computer executes the instructions after receiving the instructions. -
Page 7: Shortcut Commands
H9380 Android IPC CLI User Manual Shortcut commands Function commands Command prompts Invalid prompts The characters # and ! are the annotation marks. 1.3.1 Shortcut commands Shortcut commands include quick jump commands and keyboard shortcuts, which make the operation of the CLI more quick and easy. -
Page 8: Foreword
H9380 Android IPC CLI User Manual Quick Command Description command help View CLI operation reference help information 1.3.2 Function commands Examples of common function commands are as follows: Table 1-2 Command Description show history View the history commands in current login show running-config View all the parameters currently running by the CLI... -
Page 9: Contents
H9380 Android IPC CLI User Manual Negate a command or set its defaults ping Send icmp echo message quit Exit current mode and down to previous mode reboot Reboot system save Save configuration show Show running system information telnet Open a telnet connection terminal Set terminal line parameters tftp... -
Page 10: Login Cli
H9380 Android IPC CLI User Manual Unrecognized command The input command was not found Did not find the input command keyword The command type entered in the command is incorrect Commands entered in the command length exceeds the specified range Command incomplete Enter the command is not complete (usually not enter the child times the error) - Page 11 H9380 Android IPC CLI User Manual Figure 1-2 Step 3 Input your password to login CLI, default password is “super”. Figure 1-3 Step 4 After login, you can input “enable” to enter super mode, and further enter “configure terminal” (or "conf t") to enter the configuration mode. Wherein, press the key “Tab” to auto complete instructions.
-
Page 12: Cli Command Reference
H9380 Android IPC CLI User Manual Router# configure t Router# configure terminal CLI Command Reference 2.1 Ethernet/Bridge Interface Config 2.1.1 Ethernet port config The LAN corresponds to the interface BR0 configured for the CLI. The Ethernet interface configuration command is shown in the table below. Table 2-1 Command Description... -
Page 13: Routing Configuration
H9380 Android IPC CLI User Manual Command Description Remarks Configure dns Available for modem, ip dns server A.B.C.D/WORD br0 and so on [Config example] localhost (config) #ip dns server 114.114.114.114//Configure dns 2.3 Routing configuration The routing configuration commands are shown in the following table. Table 2-3 Command Description... -
Page 14: Nat Configuration
H9380 Android IPC CLI User Manual 2.5 NAT configuration The NAT function can perform IP conversion for message protocol, message port, message destination address and source address, and can also perform IP conversion on the preset interface. The command parameters for NAT and DNAT configuration are shown in the following table. -
Page 15: Firewall Configuration
H9380 Android IPC CLI User Manual Command Description Remarks first WORD axb Configure the first screen Optional resolution interface and resolution. second WORD axb Configure the second screen Optional resolution interface and resolution. Backlight (WORD) Configure the backlight. on/off direction WORD Configure the screen orientation. - Page 16 H9380 Android IPC CLI User Manual Command Description Remarks (A.B.C.D/M|any|host A.B.C.D) protocol data packets. The [<1-65535> | [<1-65535>|PORTLIST] filtering type is forwarding PORTLIST] is the (A.B.C.D/M|any|host A.B.C.D) and the filtering action is configuration source [PORTLIST] accepted or discarded. port and the second set of PORTLIST is ...
-
Page 17: Monitor Service
H9380 Android IPC CLI User Manual 2.8 Monitor service Monitor service including APP monitoring ,status bar&vrtual button hidden. The configuration commands are shown in the following table. Table 2-8 Command Description Remarks prop-list monitor-service WORD Monitoring and management on/off of the switch prop-list monitor-app WORD Configure the main APP name prop-list statusbar WORD... -
Page 18: Query Delete Cli Configuration
H9380 Android IPC CLI User Manual Command Description Remarks network setting global preferred-network-mode Configure the WORD priority network type setting global wifi-on WORD Configure WiFi on/off setting global bluetooth-on WORD Configure Bluetooth on/off setting system screen-brightness <0-255> Configure screen brightness setting system screen-brightness-mode WORD Configure the screen on/off... - Page 19 H9380 Android IPC CLI User Manual After each increase and delete cli configuration, to save the configuration --- wr Hongdian Corporation...
-
Page 20: Upgrade
H9380 Android IPC CLI User Manual 3.1 Upgrade 3.1.1 H9380 Currently there are two kinds of local upgrade for H9380: The first is bin package upgrade, bin program and cfg files, plug in the device, the second is the recovery upgrade is a zip package, you need to click on the UI operation. -
Page 21: Modem Dail Up
H9380 Android IPC CLI User Manual 3.3 Modem dail up 3.3.1 Log logcat -b radio -v time The general cycle of CSQ and status query on behalf of dial-up success 3.3.2 Dialup failure Please check the following items. Settings - More - Mobile Networks - Enable Data Network is on APN access point whether there ---- ---- Try for other cards SIM card arrears --- try for other cards Ethernet is open --- Please turn off the open, it will affect the dial -up... - Page 22 Create smart things F14 - F16, Tower A, Building 14, No.12, Ganli 6th Road, Longgang District, Shenzhen 518112, China. +86-755-88864288-5 +86-755-83404677 hongdianchina www.hongdian.com sales@hongdian.com Hongdian_China...
