Philips 32PFL4007D/78 Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. LCD TV
  5. 32PFL4007D/78
  6. Service manual
Philips 32PFL4007D/78 Service Manual

Philips 32PFL4007D/78 Service Manual

Chassis tpm9.2l la
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Color Television
Contents
400 32PFL4017G_78
©
Copyright 2012 Koninklijke Philips Electronics N.V.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic, mechanical,
photocopying, or otherwise without the prior permission of Philips.
Published by XjL/MjX/SC 1263 BG TV Quality, the Netherlands
Page
2
2
5
9
23
25
30
37
38
39
Drawing PWB
44-45
46
49-50
51
67-68
69
70
71
72
73
74
Chassis
TPM9.2L
Subject to modification
EN 3122 785 19260
LA
19260_000_120326.eps
19260_000_120326.eps
19260_000_120326.eps
120326
2012-Mar-30

Advertisement

Table of Contents
loading

Related Manuals for Philips 32PFL4007D/78

Summary of Contents for Philips 32PFL4007D/78

  • Page 1: Table Of Contents

    All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. Published by XjL/MjX/SC 1263 BG TV Quality, the Netherlands...

  • Page 2: Revision List

    & Notes: drivers. • Figures can deviate due to the different set executions. Table 2-1 Described Model Numbers and Diversity Mechanics Block Diagrams Schematics 32PFL4007D/78 10.1 10.3 10.4 10.5 11.1 32PFL4017G/78 10.1 10.3 10.4...
  • Page 3 Technical Specs, Diversity, and Connections TPM9.2L LA EN 3 Connections Rear connectors Side connectors CVBS AUDIO IN DVI/VGA USB 1 ANTENNA ANTENNA IN 1 IN 2 (AIR) (CABLE) USB 2 SERV .U NETWORK HDMI 3 SPDIF HDMI HDMI 19260_001_120317.eps 120323 Figure 2-1 Connection overview Note: The following connector color abbreviations are used 5, 6 - HDMI: Digital Video - In, Digital Audio - In/Out...
  • Page 4 EN 4 TPM9.2L LA Technical Specs, Diversity, and Connections 9 - PC IN:VGA 12 - Service / UART - Ground - UART_TX Transmit - UART_RX Receive 10000_002_090121.eps 090127 13 - EXT2: Video YPbPr - In, Audio - In Gn - Video - Y / 75 W Figure 2-4 VGA connector Bu - Video - Pb...

  • Page 5: Precautions, Notes, And Abbreviation List

    Spare Parts the following points: • Route the wire trees correctly and fix them with the For the latest spare part overview, consult your Philips Spare mounted cable clamps. Part web portal. • Check the insulation of the Mains/AC Power lead for external damage.
  • Page 6 EN 6 TPM9.2L LA Precautions, Notes, and Abbreviation List result in sets which have the same CTN (Commercial Type 6 = play 16 : 9 format, 12 = play 4 : 3 Number; e.g. 28PW9515/12) but which have a different B.O.M. format number.
  • Page 7 6.5 MHz. L' is Band (VESA standard for communication I, L is all bands except for Band I channel and display). Using E-DDC, LG.Philips LCD (supplier) the video source can read the EDID Loudspeaker information form the display.
  • Page 8 SOPS Self Oscillating Power Supply Serial Peripheral Interface bus; a 4-wire synchronous serial data link standard S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board Spread Spectrum Clocking, used to reduce the effects of EMI...

  • Page 9: Mechanical Instructions

    Mechanical Instructions TPM9.2L LA EN 9 4. Mechanical Instructions Index of this chapter: Notes: 4.1 Cable Dressing • Figures below can deviate slightly from the actual situation, 4.2 Service Positions due to the different set executions. 4.3 Assembly/Panel Removal 4.4 Set Re-assembly Cable Dressing 19260_100_120322.eps 120323...
  • Page 10 EN 10 TPM9.2L LA Mechanical Instructions 19260_101_120322.eps 120323 Figure 4-2 Cable dressing (42") Service Positions For easy servicing of a TV set, the set should be put face down on a soft flat surface, foam buffers or other specific workshop tools.
  • Page 11 Mechanical Instructions TPM9.2L LA EN 11 M3 × 8 3 × 10 M3 × 4 countersunk head M3 × 8 19260_102_120326.eps 120327 Figure 4-3 Rear cover removal 4.3.2 Stand Refer to Figure 4-3 for details. 1. Remove fixation screws [4] that secure the base assembly, pull the base assembly downwards away from the catches.
  • Page 12 EN 12 TPM9.2L LA Mechanical Instructions 4.3.5 Woofer 1. Gently release the tapes that holds the woofer cable. 2. Unplug the woofer connector from the SSB. 3. Take the woofer out. When defective, replace the both units. 4.3.6 Tweeters 1. Gently release the tapes that holds the tweeter cables. 2.

  • Page 13: Service Modes, Error Codes, And Fault Finding

    Service Modes, Error Codes, and Fault Finding TPM9.2L LA EN 13 5. Service Modes, Error Codes, and Fault Finding Index of this chapter: Life Timer 5.1 Test Points During the life time cycle of the TV set, a timer is kept (called 5.2 Service Modes “Op.
  • Page 14 EN 14 TPM9.2L LA Service Modes, Error Codes, and Fault Finding – Automatic user menu time-out (menu switches controls will not have I+ button, but an “INFO” button back/OFF automatically. instead. – Auto Volume levelling (AVL). How to Exit SDM How to Activate SDM •...
  • Page 15 Service Modes, Error Codes, and Fault Finding TPM9.2L LA EN 15 Main Menu Sub-menu 1 Sub-menu 2 Description Download from USB Copy Channel List from USB To download several settings from the USB stick to the TV Copy NVM from USB Copy Readable Info from USB Copy EDID from USB Initialize NVM...
  • Page 16 EN 16 TPM9.2L LA Service Modes, Error Codes, and Fault Finding Default value Item Item value 32" 37" 42" 47" Description CLR_TEMP_G Green colour temperature setting CLR_TEMP_B Red colour temperature setting AUTO_COLOR Press OK PC: any pattern that has black and white, YPbPr: SMPTE bar (colour bar), any timing. ADC_GAIN_R Red ADC gain ADC_GAIN_G...
  • Page 17 Service Modes, Error Codes, and Fault Finding TPM9.2L LA EN 17 5.2.5 Customer Service Mode (CSM) customer wants to make use of the HDMI functionality, the SSB has to be replaced. • 3.4 Ethernet MAC address A Media Access Control Purpose address (MAC address) is a unique identifier assigned to The Customer Service Mode shows error codes and...
  • Page 18 EN 18 TPM9.2L LA Service Modes, Error Codes, and Fault Finding Stepwise Start-up Standby Soft Mode Command Received, Switch previously in Standby Off(Mains Soft Mode (Power tact Standby Power Plug) switch) Digital Digital background background tasks started tasks completed TV Wakeup commands Received Standby...
  • Page 19 A description on how to upgrade the main 1. ComPair helps to quickly get an understanding on how to software can be found in the DFU or on the Philips website. repair the chassis in a short and effective way.
  • Page 20 EN 20 TPM9.2L LA Service Modes, Error Codes, and Fault Finding • FUS_clustername_version.zip: Contains the “autorun.upg” which is needed to upgrade the TV main software and the software download application. • NVM_clustername_version.zip: Default NVM content. Must be programmed via ComPair. 5.5.7 How to Copy NVM Data to/from USB When copying data to and from a USB memory stick, the folder...
  • Page 21 Service Modes, Error Codes, and Fault Finding TPM9.2L LA EN 21 – ERROR: 034 013 000 000 000: Error code 13 was Fault Finding and Repair Tips detected first and error code 34 is the last detected Note: (newest) error •...
  • Page 22 EN 22 TPM9.2L LA Service Modes, Error Codes, and Fault Finding 5.8.10 Display option code Attention: In case the SSB is replaced, always check the Panel Code in CSM, even when picture is available. Performance with the incorrect display option code can lead to unwanted side-effects for certain conditions.

  • Page 23: Alignments

    Alignments TPM9.2L LA EN 23 6. Alignments Index of this chapter: In case you have a color analyzer: 6.1 General Alignment Conditions • Measure with a calibrated (phosphor- independent) color 6.2 Hardware Alignments analyzer (e.g. Minolta CA-210) in the centre of the screen. 6.3 Software Alignments Consequently, the measurement needs to be done in a 6.4 Option Settings...
  • Page 24 EN 24 TPM9.2L LA Alignments Option Settings 6.5.1 SSB Identification 6.4.1 Introduction SSB’s of this chassis are identified by a “715” code on the SSB. 715Axxxx-Nnn-MMM-OOOO • 715 main category, Printed Wiring Board The microprocessor communicates with a large number of I •...

  • Page 25: Circuit Descriptions

    Circuit Descriptions TPM9.2L LA EN 25 7. Circuit Descriptions Index of this chapter: Introduction 7.1 Introduction The TPM9.2L LA platform is covering the 4000 series styling. It 7.2 Power Supply uses the MT5366 main microprocessor. The major differences 7.3 DC/DC Converters compared to its predecessors are the ISDB and LAN 7.4 Front-End Analogue and ISDB-T reception capabilities;...
  • Page 26 EN 26 TPM9.2L LA Circuit Descriptions 7.1.3 SSB Cell Layout DC/DC AV OUT AV IN MT5366 AUDIO AMP TUNER ANALOG I/O HDMI SWITCH SERVICE CONNECTOR HDMI 19260_200_120321.eps 120323 Figure 7-1 SSB layout cells (top view) back to 2012-Mar-30 div. table...
  • Page 27 The following displays can be distinguished: the regular market. • CCFL/EEFL backlight: power board is conventional IPB Consult the Philips Service web portal for the order codes of the • LED backlight: boards. - side-view LED without scanning: PSL power board - side-view LED with scanning: PSLS power board Important delta’s with the 4000 series platform are:...
  • Page 28 EN 28 TPM9.2L LA Circuit Descriptions Front-End Analogue and Connector ISDB-T reception 32PFLxxx7 42PFLxxx7 CN8101 CN9302 CN8503 CN902 7.4.1 Front-End Analogue Descr. to panel to SSB to panel to SSB CN8101 CN9302 CN8503 CN902 LED6 PS_ON LED-15 PS_ON The Front-End for the analogue tuner consist of the following LED2 +24V LED-14...
  • Page 29 Circuit Descriptions TPM9.2L LA EN 29 Integrated Backlight Tcon MT5366CVNG 50/60 Hz SIL9185A ASIC R3X R2X CN503 MT5366 Lamp-ON 19260_206_120327.eps 120328 19240_210_120224.eps Figure 7-6 HDMI input configuration 120328 The Sil9185ACTU has the following specifications: Figure 7-7 LED back lit power scheme. •...

  • Page 30: Ic Data Sheets

    EN 30 TPM9.2L LA IC Data Sheets 8. IC Data Sheets This chapter shows the internal block diagrams and pin configurations of ICs that are drawn as “black boxes” in the electrical diagrams (with the exception of “memory” and “logic” ICs).
  • Page 31 IC Data Sheets TPM9.2L LA EN 31 Diagram 10-3-9 Audio Amplifier/Headphone/Subwoofer B09, STA381BWTR (IC U603) Block diagram STA381BW OUT 1A OUT 1B 2.1 Channel Half MCLK OUT 2A Audio Processor Bridges OUT 2B Modulator STAudioFx FFX3A LRCKI STSpeakerSafe FFX3B Parametric EQ BICKI Binary Volume...
  • Page 32 EN 32 TPM9.2L LA IC Data Sheets Diagram 10-3-11 GPIO Interface & to IR/Keyboard control B13, MT5366SVOG/B PBGA-479 (IC U401) Block diagram VADC × 4 MT5366CV 19080_300_110316.eps 120102 Figure 8-3 Internal block diagram back to 2012-Mar-30 div. table...
  • Page 33 IC Data Sheets TPM9.2L LA EN 33 Pinning information MT5366CV [1/2] 19080_301_110316.eps 120102 Figure 8-4 Pin configuration [1/2] back to 2012-Mar-30 div. table...
  • Page 34 EN 34 TPM9.2L LA IC Data Sheets Pinning information MT5366CV [2/2] 19080_302_110316.eps 120102 Figure 8-5 Pin configuration [2/2] back to 2012-Mar-30 div. table...
  • Page 35 IC Data Sheets TPM9.2L LA EN 35 Diagram 10-3-15 ISDB-T Demodulator B15, CXD2828ER (IC U103) Block diagram TSCLK TSSYNC ISDB-T TSVALID TSDATA[7:0] TAINP TAINM Viterbi TSIF decoder decoder OFDM Demodulator TIFAGC Status Terrestrial TMCC Monitor Tuner Tuner I Host I CXD2828ER TTUSDA TTUSCL...
  • Page 36 EN 36 TPM9.2L LA IC Data Sheets Diagram 10-3-16 Ethernet B16, RTL8201EL-VC-GR (IC U4010) Block diagram RTL8201FL Pinning information RTL8201FL 19240_302_120221.eps 120221 Figure 8-7 Internal block diagram and pin configuration back to 2012-Mar-30 div. table...

  • Page 37: Block Diagrams

    Block Diagrams TPM9.2L LA EN 37 9. Block Diagrams Wiring diagram 4000 32" WIRING DIAGRAM 32" (4000) Board Level Repair See note in Chapter 7 about cable position numbers Component Level Repair Only for authorized workshops to panel LOUDSPEAKER (1185) CN8101 CN701 CN408...

  • Page 38: Wiring Diagram 4000 42

    Block Diagrams TPM9.2L LA EN 38 Wiring diagram 4000 42" WIRING DIAGRAM 42" (4000) Board Level Repair See note in Chapter 7 about cable position numbers. Component Level Repair Only For Authorized Workshop to panel CN8503 LOUDSPEAKER LOUDSPEAKER LOUDSPEAKER (1185) (1185) (1185) CN701...

  • Page 39: Block Diagram 4000

    Block Diagrams TPM9.2L LA EN 39 Block Diagram 4000 DC POWER IF(+/-) for PAL/SECAM SUT-RB211T H5TQ1G63DFR-H9C RF Tuner for IF(+/-) for ISDB_T HY27UF082G2B × 2 PAL/ISDB-T NAND FLASH 256 MB CN701 DDRIII/1 Gb/ 1333 MHz +24V(16V) TS DATA OUT(SERIAL) CXD2828 ISDB_T Demodulator MT5366CVNG...

  • Page 40: Circuit Diagrams And Pwb Layouts

    Circuit Diagrams and PWB Layouts TPM9.2L LA EN 40 10. Circuit Diagrams and PWB Layouts 10.1 A01 715G5194 PSU 32" & 37" 3500/4000 series 10-1-1 AC Side AC Side F9902 FB9901 T4.0AH/250V SG9901 C9905 SG9903 NR9902 SPG-201M-LF 470PF 250V SPG-201M-LF BEAD COLD FUSE-NC...
  • Page 41 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 41 10-1-2 IC8102 COMP C8119 1UF 16V COMP D8102 L8102 +12V2 ISET +24V1 VLED R8101 LED2 10K 1/8W 1% PF7700S C8108 L8101 SR510-22 150UF 35V 25UH R8121 C8125 R8120 100K R8122 C8109 R8109 12UF 160V 100K...
  • Page 42 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 42 10-1-3 Main Power Main Power B+_main COLD R9104 R9147 100 OHM 1/4W 2Mohm 1/4W +/-1%-NC R9103 100 OHM 1/4W B+_main R9105 +12V R9148 100 OHM 1/4W 2Mohm 1/4W +/-1%-NC +12V1 T9101 C9108 C9103 D9102...
  • Page 43 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 43 10-1-4 Standby Standby FB9304 C9137 C9139 CN9301 CN9303 BEAD +24V 470PF 250V-NC 220PF 250V COLD R9319 D9306 47 OHM 1/4W SJPW-T4VL-NC C9301 B+_main R9303 1.5NF FB9301 0.1R 47 OHM 1/4W R9302 R9304 BEAD 47 OHM 1/4W...
  • Page 44 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 44 10-1-5 Power layout top GND4 GND3 CN9301 CN8101 CN8102 L8102 CN9303 D8102 J937 J924 J938 J925 C8128 C8125 L8101 J939 C9101 J940 J927 R8116 C8132 J928 C8129 L9102 C8108 L9101 C9107 ZD9107 J922 J951...
  • Page 45 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 45 10-1-6 Power layout bottom R8121 R9141 R9143 C9111 R9140 RJ911 R8106 R9139 R8107 R8110 R9144 R8103 R8118 R9145 R8124 R8123 R9142 R9324 R9146 RJ905 R9165 R9138 R9166 R8109 R8112 R8101 R9159 R8104 R8134 R9161...

  • Page 46: A01 715G5246 Psu 42" 3500/4000 Series

    Circuit Diagrams and PWB Layouts TPM9.2L LA EN 46 10.2 A01 715G5246 PSU 42" 3500/4000 series 10-2-1 Power Circuit Power Circuit FB9803 D9802 1N5408-11 RV9902 FB902 FB9804 FB9801 CN903 TVR14561KFAOZF BEAD BEAD FMN-1106S BEAD R9330 L9801 D9801 R9329 T9301 47 OHM 1/4W 300UH 0.1R R9331...
  • Page 47 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 47 10-2-2 24 V to VLED 24 V to VLED 24V-LED VLED L8101 D8120 25UH MBRF10150CT R8154 R8155 C8118 C8108 100K 100K R8156 100K 100UF 100V 100UF 100V Q8101 R8145 270K 1/4W TK12A10K3 R8147 110K OHM 1%...
  • Page 48 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 48 10-2-3 LED Driver LED Driver IC8501 IC8502 IC8503 LED-COMP COMP FLAG COMP LED-COMP COMP LED-COMP 12V_LED ISET FLAG FLAG LED-1 12V_LED 12V_LED ISET ISET R8501 LED-6 LED-2 11K 1% C8501 R8502 R8503 PF7703S 1UF 16V...
  • Page 49 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 49 10-2-4 Power layout top J8536 J8540 CN8504 CN8503 CN8502 L8101 CN8501 J8533 J8532 J8534 J8531 D8120 J8537 J8538 J8539 J9118 J8501 J8504 J8507 J8510 J8514 J8517 J8521 J8524 HS9101 R8175 J8502 J8505 J8508 J8511...
  • Page 50 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 50 10-2-5 Power layout bottom R8145 R9315 JR8101 R8162 R8148 R8177 R9321 R9322 C9346 JR9102 R9313 R9163 C9158 R9159 R9151 R9156 JR9101 IC9101 R9177 R9145 C9145 C9146 R9175 R9149 C9155 R9153 R9176 R9174 R9102 C9162...

  • Page 51: B 715G5172 Ssb 3000/3500/4000 Series

    Circuit Diagrams and PWB Layouts TPM9.2L LA EN 51 10.3 B 715G5172 SSB 3000/3500/4000 series 10-3-1 System Power 1 System Power INVERTER_ON_OFF MAIN POWER +5V Switch BRIGHT ADJUST BRIGHT_ADJ +5V_SW DVDD3V3 +5V_SW DVDD3V3 CN701 +5VSB Bright_Adj R702 +12VSB Max:3.3V C1147 R724 0R05 4A 1/4W R725...
  • Page 52 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 52 10-3-2 +5V_SW +5V_SW +5V_SW +5V_SW VGA Input +5VSB +5VSB R1210 R1211 VGASCL NC/4K7 1/10W 5% VGASCL NC/10K 1/10W VGASDA VGASDA NC/100R 1/10W 5% VSYNC Video Input VSYNC R1209 VGA_UR_EN HSYNC +5V_SW HSYNC Q1153 TP05048...
  • Page 53 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 53 10-3-3 YPbPr YPbPr YPbPr1 Video Input Y_IN_1 VPORT0603100KV05 SOY0 C127 R192 R149 1.5nF 50V ZD117 PB_IN_1 Y_IN_1 R150 C129 10N 50V PR_IN_1 0R05 1/16W 18R 1/10W 5% 100R 1/16W 5% ZD118 PB_IN_1 C131 VPORT0603100KV05...
  • Page 54 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 54 10-3-4 Side AV/USB/PC Audio-in Side AV/USB/PC Audio-in DVDD3V3 DVDD3V3 +5V_SW +5V_SW Side AV(CVBS)Video & Audio input VGA Audio Input TP087 TP091 TP092 TP099 TP100 TP103 Side AV Video & Audio R202 CN128 CN102 SIDE_CVBS_IN...
  • Page 55 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 55 10-3-5 HDMI Connectors HDMI Connectors RR2X0- HDMI 1 OPWR2_5V OPWR2_5V RR2X0- RR2X0+ OPWR1_5V OPWR1_5V RR2X0+ RR2X1- PORT 1 OPWR0_5V OPWR0_5V RR2X1- RR2X1+ 3V3SB 3V3SB RR2X1+ RR2X2- +5VSB +5VSB RR2X2- RR2X2+ RR2X2+ RR2XC- RR2XC- CN504...
  • Page 56 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 56 10-3-6 HDMI Switch HDMI Switch HDMI 1 RR2X0- RR2X0- AVCC1V8 AVCC1V8 AVCC1V8 RR2X0+ TP158 RR2X0+ TP157 C1198 RR2X1- RR2X1- RR2X1+ R1043 100N 16V RR2X1+ SPDIF SPDIF_OUT RR2X2- RR2X2- R512 RR2X2+ 3V3SB_9185 3V3SB_9185 RR2X2+ TP141...
  • Page 57 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 57 10-3-7 DDR3 DRAM DDR3 DRAM MT5366 U401B DVDD3V3 DVDD3V3 U401B AVDD1V2 AVDD1V2 RDQ0 1_A0 RDQ6//RDQ0 RCAS_//RA0 RDQ1 1_A1 RDQ0//RDQ1 RA6//RA1 RDQ2 1_A2 RDQ1//RDQ2 RBA0//RA2 RDQ3 1_A3 U403 RDQ7//RDQ3 RA5//RA3 RDQ4 1_A4 U402 DDRV RDQ4//RDQ4...
  • Page 58 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 58 10-3-8 Flash/Xtal/JTAG/UART Flash/Xtal/JTAG/UART U401A U401A JTCK U0TX DVDD3V3 DVDD3V3 DVDD3V3 JTCK U0TX JTDI U0RX DVDD3V3 256MB +5VSB +5VSB VCCK JTDI U0RX JTDO U405 U405 DVDD3V3 3V3SB 3V3SB TP409 DVDD3V3 JTDO JTMS K9F2G08U0B-PIB0 R423 R424...
  • Page 59 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 59 10-3-9 Audio Amplifier/Headphone/Subwoofer Audio Amplifier/Headphone/Subwoofer FB600 220R/2000mA Earphone R/L output FB604 +24V(16V) 220R/2000mA PVDD AL0O C600 R600 R604 Audio Control 1UF 10V 20K 1/16W 5% 43K 1% +24V(16V) TP206 +24V(16V) +12V +12V C602 +5VSB...
  • Page 60 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 60 10-3-10 A/V Interface A/V Interface U401F U401F Analog Power AE25 AR0O AVDD3V3 AVDD3V3 AIN0_R_AADC AR0_ADAC TP381 TP382 AB21 AA25 AL0O ADAC_PWR AOLRCK AOLRCK_A AVDD1V2 AVDD1V2 AIN0_L_AADC AL0_ADAC AD25 +5V_SW AIN1_R_AADC +5V_SW AVDD33_DAC AVDD33_DAC1 AE22...
  • Page 61 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 61 10-3-11 GPIO Interface & to IR/Keyboard control GPIO Interface & to IR/Keyboard control DEMOD_RST DEMOD_RST U401E TP366 DEMOD_TSCLK GPIO0 DEMOD_TSCLK ARC_OE DEMOD_TSVAL GPIO1 DEMOD_TSVAL DEMOD_TSSYNC GPIO2 DEMOD_TSSYNC SYS_EEPROM_WP DEMOD_TSDATA0 GPIO3 DEMOD_TSDATA0 GPIO4 LVDS_PWR_EN GPIO5...
  • Page 62 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 62 10-3-12 LVDS Output LVDS Output U401D Analog Power AVDD33_USB_2P AVDD33_LVDSTX +12V +12V AVDD33_USB_2P AVDD33_LVDSA AVDD3V3 AVDD3V3 AVSS33_USB_2P AVDD33_LVDSA AVDD1V2 AVDD1V2 AVDD3V3 +5V_SW +5V_SW AVSS33_LVDSA USB_VRT TP361 USB_2P_VRT AVSS33_LVDSA AVDD1V2 AVDD1V2 AVDD33_LVDSTX R496 LVDSVDD LVDSVDD...
  • Page 63 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 63 10-3-13 RS-232 RS-232 U0TX U0TX U0RX U0RX 3V3SB 3V3SB 3V3SB 3V3SB BAV99 BAV99 +5VSB +5VSB D401 D405 R464 R466 4.7K1/16W 4.7K1/16W U0TX TP289 R480 CN410 U0TX CONN 100 OHM 1/10W R483 U0RX 100 OHM 1/10W U0RX...
  • Page 64 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 64 10-3-14 Tuner Tuner TUNER POWER +5V_TUNER TU103 form +12V/+12V_TUN TP352 SUT-RB211TV IFOUT1P+ C208 1UF 6.3V IFOUT1P TP353 +12V +5V_TUNER IFOUT1N- FB712 220R/2000mA IFOUT1N TP306 U755 AS7805DTR-E1 C205 1UF 6.3V TIFAGC TP305 IF1_P TP294 AVDD3V3...
  • Page 65 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 65 10-3-15 ISDB-T Demodulator ISDB-T Demodulator AVDD3V3 AVDD3V3 X101 AVDD1V2 AVDD1V2 DEMOD_TSCLK DEMOD_TSCLK DEMOD_TSVAL C215 41.0MHz DEMOD_TSVAL DEMOD_TSSYNC C217 DEMOD_TSSYNC DEMOD_TSDATA0 TP319 12P 50V DEMOD_TSDATA0 12P 50V DEMOD_RST R130 0R05 1/16W DEMOD_RST R102 OSDA2 470R 1/16W 5%...
  • Page 66 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 66 10-3-16 Ethernet ESD & Surge Protect ETRXDV ETRXDV ETTXCLK_REF_CLK ETTXCLK_REF_CLK ETRXCLK_C50M_O ETRXCLK_C50M_O PHY_REFCLK_E PHY_REFCLK_E U4011 PHYRST# NC/uClamp2512T.TCT PHYRST# DVDD3V3_MII ETCOL ETCOL MDI_TP MDI_TP DVDD3V3_MII ETTXD3 OUT1 ETTXD3 MDI_TN MDI_TN SMD/0402 ETTXD2 OUT2 R4157 ETTXD2...
  • Page 67 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 67 10-3-17 SSB layout top CN701 CN409 FB600 C1148 C489 FB604 R766 C688 C490 CN603 RP400 RP401 FB404 CN602 C607 C616 C703 Q705 CN408 RP402 RP403 C679 R724 RP404 RP405 C402 C608 C680 R737 C683...
  • Page 68 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 68 10-3-18 SSB layout bottom TP093 TP263 TP275 TP273 TP268 R4004 TP287 TP277 TP264 TP001 TP002 TP003 TP005 TP007 TP008 TP281 TP279 TP265 R4006 TP090 TP286 TP253 TP031 TP261 TP262 TP267 TP270 TP034 TP006 TP221...

  • Page 69: J 715G5251 Ir/Led 3500/4000 Series

    Circuit Diagrams and PWB Layouts TPM9.2L LA EN 69 10.4 J 715G5251 IR/LED 3500/4000 series 10-4-1 Power Circuit IR/LED board 3V3SB R301 2K2 1/10W 5% 3V3SB LED301 3V3SB R202 R201 100R 1/10W 5% NC/2K7 1/16W 5% D201 R302 1K 1/10W 5% BAV99 C204 Q301...
  • Page 70 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 70 10-4-2 IR/LED board layout Layout IR/LED Board (Top Side) D202 R202 U201 D201 LED301 R301 C204 Layout IR/LED Board (Bottom Side) ZD10 Q301 CN201 ZD12 2011-11-04 IR/LED board 715G5251 layout top/bottom 19240_512_120215.eps 120215 back to...

  • Page 71: E 715G5252 Keyboard Control Panel 3500/4000 Series

    Circuit Diagrams and PWB Layouts TPM9.2L LA EN 71 10.5 E 715G5252 Keyboard control panel 3500/4000 series 10-5-1 Keyboard Keyboard C024 100N 50V R023 CN016 KEY2 KEY1 0R05 1/10W SOURCE VOL- VOL+ CONN R025 C023 NC/1K 1/10W 1% 100N 50V R024 NC/0R05 1/10W POWER...
  • Page 72 Circuit Diagrams and PWB Layouts TPM9.2L LA EN 72 10-5-2 Key board layout Layout Key Board (Top Side) CN016 Layout Key Board (Bottom Side) 2012-01-09 Keyboard 715G5252 layout top/bottom 19240_514_120215.eps 120215 back to 2012-Mar-30 div. table...

  • Page 73: Styling Sheets

    Styling Sheets TPM9.2L LA EN 73 11. Styling Sheets 11.1 400 32PFL4017G_78 4000 series 32" 1053 0041 1185 1185 0050 0032 1057 1054 1185 1056 Pos No. Description Remarks 0031 Front bezel 0031 0032 Deco bezel 0041 Rear cover 0050 Stand Assy 1050 Display panel...

  • Page 74: 4000 42Pfl4007G_78

    Styling Sheets TPM9.2L LA EN 74 11.2 4000 42PFL4007G_78 4000 series 42" 1054 0041 1185 1053 1050 1185 1185 0050 1057 1056 0032 Pos No. Description Remarks 0031 Front bezel 0032 Deco bezel 0041 Rear cover 0050 Stand Assy 1050 Display Panel 0031 1053...

This manual is also suitable for:

4000 series32pfl4017g/7842pfl4007g/78

Table of Contents
