Specifications

Monitor Specifications
LCD Module
Viewable Image Size: 55.9 cm/22.0 inches
Native Resolution (Pixel Count): 1680 x 1050
Input Signal
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active
Landscape: Horiz.: 473.8 mm / 18.7 inches
Display Area
Portrait: Horiz.: 296.1 mm / 11.7 inches
USB Hub
Speakers
Practical Audio Output: 1.0 W + 1.0 W
Power Supply
Current Rating
Power
Maximun Operation: 42 W
Consumption
Normal Operation: 20 W
Dimensions
Height Adjustment: 110 mm/4.3 inches (Landscape condition)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C / 41°F to 95°F
Storage Temperature: -10°C to 60°C / 14°F to 140°F
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifications are subject to change without notice.
MultiSync EA221WMe
Diagonal: 55.9 cm/22.0 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
16,777,216
Horizontal: 31.5 kHz to 82.3 kHz (Analog)
31.5 kHz to 82.3 kHz (Digital)
Vertical: 56.0 Hz to 75.0 Hz
Left/Right: ±89° (CR > 5)
Up/Down: ±89° (CR > 5)
720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 864*
1152 x 870*
1280 x 960*
1280 x 1024*
1440 x 900*
1400 x 1050*
1680 x 1050 at 60 Hz.......................... resolution for optimal display performance.
Vert.: 296.1 mm / 11.7 inches
Vert.: 473.8 mm / 18.7 inches
I/P: USB Specification Revision 2.0
Port: Upstream 1
Downstream 4
Load Current: Maximum 0.5A per port
AC 100-240 V ~ 50/60 Hz
0.75-0.4 A
Landscape: 507.8 mm (W) x 382.0 - 492.0 mm (H) x 220.0 mm (D)
20.0 inches (W) x 15.0 - 19.4 inches (H) x 8.7 inches (D)
Portrait: 332.1 mm (W) x 522.8 - 579.5 mm (H) x 220.0 mm (D)
13.1 inches (W) x 20.6 - 22.8 inches (H) x 8.7 inches (D)
56.7 mm/2.2 inches (Portrait condition)
7.5 kg (16.5 lbs)
Humidity: 20% to 80%
Altitude: 0 to 6,562 Feet / 0 to 2,000 m
Humidity: 10% to 85%
Altitude: 0 to 40,000 Feet / 0 to 12,192 m
1
: VGA text
1
at 60 Hz to 75 Hz
1
at 56 Hz to 75 Hz
1
at 75 Hz
1
at 60 Hz to 75 Hz
1
at 75 Hz
1
at 75 Hz
1
at 60 Hz to 75 Hz
1
at 60 Hz to 75 Hz
1
at 60 Hz to 75 Hz
1
at 60 Hz to 75 Hz
English-14
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.282 mm dot pitch;
250 cd/m
2
white luminance; 1000:1 contrast ratio,
typical.
Digital Input: DVI-D with HDCP
Depends on display card used.
Automatically
Automatically
Automatically
Some systems may not support all modes listed.
NEC DISPLAY SOLUTIONS cites recommended
